LEESON LM24787 SSA2S1.5TZ1C6027L14MB6TP2 Agricultural Motor, 1.50 HP, 1 Phase, 60 Hz, 115/230V, 3600 RPM
Get it by Tuesday, May 19
€611.85 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Amps | 8.4/16.8A |
| Assembly/box Mounting | F1 Only |
| Cc Number | Exempt |
| Code | H |
| De Bearing Type | Ball |
| Design Code | No Design Code |
| Drive End Bearing Size | 205 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 70% |
| Efficiency @ 100% | 70% |
| Electrical Type | Capacitor Start, Induction Run |
| Enclosure Type | Teao |
| Frame | 143TZ |
| Frame Length | 7 14/25" |
| Frame Material | Rolled Steel |
| Frame Size | 143TZ |
| Frequency | 60 Hz |
| Full Load Amps | 8.4A |
| Hazardous Location | Not Available |
| Height | 9.38" |
| Hp | 1 1/2 hp |
| Insulation Class | Class F |
| Ip Code | 43 |
| Kw | 1.1 kW |
| Length | 15.82" |
| Lubrication | Standard |
| Motor Mounting Type | Rigid Base |
| Motor Orientation | Horizontal |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Type | CTR |
| Mounting Type | Rigid |
| Nema Design | H |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Opp. Drive End Bearing Size | 203 |
| Opp. Drive End Bearing Type | Ball |
| Outline | A-105335LN-756 |
| Output Kw | 1.1 kW |
| Overall Length | 11.49" |
| Packaging | B |
| Paint | Standard |
| Phase | 1 |
| Power | 1.12 kW |
| Power Factor | 79 |
| Resistance Main | 0 ohms |
| Rotation Type | Selective CCW |
| Rpm | 3475 RPM |
| Service Factor | 1 |
| Shaft Dia. | 7/8" |
| Shaft Extension | 2 1/4" |
| Shaft Type | T |
| Speed Range | Not Available |
| Starting Method | Across The Line |
| Thermal Protection | Automatic |
| Type | CTR |
| Voltage | 115-230V |
| Winding | ZC212 |
Shipping Info:
| Ship weight (kg) | 15.75 |
| Ship height (cm) | 23.83 |
| Ship length (cm) | 40.18 |
| Ship width (cm) | 31.9 |
| Country of Origin | MX |
Product Details:
- Eff 100%: 70
- Bearing OPE: 203
- CC Number: EXEMPT
- Bearing PE: 205
- Winding: ZC212
- GROUP: 3
- Paint: VERIFY
Product Variants
| Product | Model | Voltage | Hp | Frame | Phase | Nameplate Rpm | Motor Shaft Design | Motor Mounting Type | Motor Thermal Protection | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KHC39QN9575T | 115/208-230V AC | 1/4 hp | 48 | 1 | 1725 RPM | Flat | Cradle Base | Auto | €273.49 | |
 |
5KH49MN6057S | 115V AC | 1/4 hp | 56 | 1 | 1140 RPM | Keyed | Cradle Base | Auto | €508.80 | |
 |
5KH33JNA500S | 115V AC | 1/3 hp | 48Z | 1 | 1725 RPM | Flat | Cradle Base | Automatic | €266.17 | |
 |
5KH42JN0328S | 115/208-230V AC | 1/2 hp | 56 | 1 | 1725 RPM | Keyed | Cradle Base | Auto | €457.32 | |
 |
5KCP36NNB059S | 115/230V AC | 1/2 hp | 48Z | 1 | 1075 RPM | Flat | Cradle Base | Auto | €280.72 | |
 |
5KCP49UN9837S | 208-230V AC | 1/2 hp | 56Y | 1 | 850 RPM | Keyed | Face | Automatic | €433.09 | |
 |
5KCR49SN0493S | 115/208-230V AC | 1 hp | 56 | 1 | 1725 RPM | Keyed | Cradle Base | Automatic | €543.50 |
