WEG 00158ES1B56-S Electric Motor, 1.5Hp, 60Hz, 1800 Rpm | BB9TTW

WEG 00158ES1B56-S 14798928 General Purpose Motor, TEAO/TEFC RolLED Steel 56H Frame, 1.5 HP, 1745 RPM, 115/208-230 V

Item: BB9TTWModel: 00158ES1B56-SCross Ref: 14798928
Check Availability
In Stock

Get it by Tuesday, Apr 7

€544.04 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

Item General Purpose Motor
Altitude 1000 M.A.S.L. , 1000 MASL
Ambient Temp. -20°C to +40°C
Balancing Method 1/2" Key
Bearing Cap No
Bolt Material Carbon Steel
Break-down Torque 270%
Breakdown Torque 270%
Cold Locked Rotor Time 14 sec.
Composition Steel
Design L
Drain Rubber, Automatic
Drip Cover Without
Duty Cycle S1
Efficiency @ 100% 77%
Efficiency @ 50% 69%
Efficiency @ 75% 75%
Efficiency At 1 % 83%
Efficiency At 50 % 68%
Efficiency At 75 % 78%
Enclosure IC411
Enclosure Type Tefc
Fan Cover Material Polymer , Steel
Fan Material Plastic
Flange Without
Flange Type Without
Frame 56H
Frame Material Rolled Steel
Frame Size 56H
Frequency 60 Hz
Grounding Lugs Single
Hot Locked Rotor Time 8 sec.
Hp 1 1/2 hp
Impregnation Method Dip And Bake Polyester
Insulation Class Class F
L. R. Amps 120/66.2-59.8A
L.r. Amperes 59.8-66.2/120A
Locked Rotor Time 8 sec.
Locked Rotor Time (cold) 14 sec.
Locked Rotor Torque 250%
Lrc 8.0X(Code L)
Main Terminal Box Hole 0.881"
Main Terminal Box Hole Size 0.881"
Moment Of Inertia 0.1426 lbs.-sq. ft.
Moment Of Inertia (j) 0.1426 lbs.-sq. ft.
Motor Enclosure Design Totally Enclosed Fan Cooled
Motor Speed 1745 RPM
Mounting F-1 , Foot Mounted
No Load Amps 3.71-4.3/8.6A , 8.6/3.71-4.3A
No. Of Poles 4
Noise Level 54 dBA
Output 1 1/2 hp
Output Rating 1 1/2 hp
Overload Protection No
Overload Protector Without Overload Protector
Painting Only Primer
Phase 1
Power Factor 50% 0.68
Power Factor 75% 0.78
Power Factor At 1 % 77
Power Factor At 50 % 69
Power Factor At 75 % 75
Power Factor_100% 0.83
Product Datasheet weg-00158es1b56-s.pdf
Rated Current 15/8.27-7.48A , 7.48-8.27/15A
Rated Speed 1745 RPM
Rated Torque 4.51 lbs.-ft.
Rated Voltage 115/208-230V , 115/208-230V AC
Resilient Base Without
Rotation CW/CCW
Rpm 1700-1800 RPM
Screw Cap Carbon Steel
Service Factor 1.15
Shaft Material Carbon Steel
Shaft Material Grade Grade 1040/45
Slip 3.06%
Starting Method Direct On Line
Synchronous Speed 1800 RPM
Temp. Rise 80 K
Terminal Block Without
Terminal Box Left Position
Tropicalized Painting Without
Voltage 115/208-230V AC

Shipping Info:

Ship weight (kg) 24.3
Ship height (cm)2.54
Ship length (cm)38.3
Ship width (cm)2.54
Country of OriginMX

Documentation:

Datasheet

Product Variants

ProductModelVoltageHpNameplate RpmFull Load AmpsFrameRpmDuty CycleNo Load AmpsPrice
WEG 00158ES1B56C-S Electric Motor, 1 1/2Hp, 60 HzHz, 1800 Rpm | BB2CJB 00158ES1B56C-S115/208-230V AC-1745 RPM-56HC1700-1800 RPMS18.6/3.71-4.3A€781.20
WEG 00218ES1RFD56H-S Electric Motor, 2Hp, 60Hz, 1800 Rpm | BB4XPH 00218ES1RFD56H-S115/230V AC2 hp--56H1700-1800 RPMS112.2/6.1A€631.13
WEG .5018ES1BCH56 Electric Motor, 1/2Hp, 60Hz, 1800 Rpm | BB6UNY .5018ES1BCH56115/208-230V---561700-1800 RPMContinuous6.4/0-3.2A€342.43
WEG 00156ES1B56-S Electric Motor, 1 1/2Hp, 60Hz, 3600 Rpm | BB7FCT 00156ES1B56-S115/208-230V AC1 1/2 hp--563400-3600 RPMS14.6/1.98-2.3A€515.42
WEG .7518ES1RFD56-S Electric Motor, 0.75Hp, 60Hz, 1800 Rpm | BB7QGN .7518ES1RFD56-S115/230V AC3/4 hp--561700-1800 RPMS18/4A€425.94
WEG .5018ES1BW56-S Electric Motor, 1/2Hp, 60 HzHz, 1730 Rpm | BB7RJG .5018ES1BW56-S115/208-230V AC1/2 hp--W561700-1800 RPMS16.6/2.85-3.3A€372.25
WEG 00118ES1EOL143T Electric Motor, 1Hp, 60Hz, 1800 Rpm | BB8APV 00118ES1EOL143T208-230/460V---143T1700-1800 RPMS12.75/4.74-5.5A€440.02
