LEESON 5K49NN4052T K1438 General Purpose Farm Duty Motor, 1.50 HP, 3 Phase, 60 Hz, 460/380V, 1800 RPM
Get it by Tuesday, Dec 23
€163.56 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Farm Duty Motor |
| Bearing Type | Ball |
| Bolt Circle Dia. | 5 7/8" |
| Duty Cycle | Continuous |
| Frame | 56C |
| Full Load Amps | 2.4A |
| Hp | 1 1/2 hp |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Length Less Shaft | 10 3/16" |
| Max. Ambient Temp. | 104°F |
| Motor Application | Farm Duty |
| Motor Bearings | Ball |
| Motor Design | 3 Phase |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame Material | Rolled Steel |
| Motor Mounting Type | Face |
| Motor Service Factor | 1 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | Automatic |
| Nameplate Rpm | 1725/1425 RPM |
| Number Of Speeds | 2 |
| Overall Length | 6 3/16" |
| Phase | 3 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 7/8" |
| Standards | Csa, Ul Recognized |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 380/460V AC |
| Weight | 29 lbs. |
Shipping Info:
| Ship weight (kg) | 13.05 |
| Ship height (cm) | 24.13 |
| Ship length (cm) | 38.46 |
| Ship width (cm) | 25.88 |
| HS code | 8501524000 |
| Country of Origin | MX |
Product Variants
| Product | Model | Voltage | Hp | Motor Shaft Design | Nameplate Rpm | Frame | Motor Enclosure Design | Motor Mounting Type | Phase | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
C039A | 115/230V AC | 1/2 hp | Double Flat | 825 RPM | F48Z | Totally Enclosed Air Over | Resilient Base | Single | €606.82 | |
 |
C319V1 | 230V AC | 2 hp | Keyed | 1725 RPM | 56HZ | Totally Enclosed Fan Cooled | Rigid Base | Single | €846.20 | |
 |
C313C | 115/230V AC | 1 hp | Keyed | 1725 RPM | L56 | Totally Enclosed Fan Cooled | Rigid Base | Single | €692.05 | |
 |
117883.00 | 115-230V | 1 hp | Keyed | 1800 RPM | 56YZ | Totally Enclosed Fan Cooled | Face | Single | €506.92 | |
 |
117888.00 | 115-230V | 1/2 hp | Flat | 1800 RPM | 56YZ | - | Face | Single | €375.24 | |
 |
117884.00 | 115/208-230V | 1 1/2 hp | Keyed | 1800 RPM | 56YZ | Totally Enclosed Fan Cooled | - | - | €2,648.56 | |
 |
117889.00 | 115-230V | 3/4 hp | Flat | 1800 RPM | 56YZ | Totally Enclosed Fan Cooled | Face | Single | €1,302.04 |
