WEG Three Phase Close Coupled Pump Motors, TEFC
Filter
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U| Style | Model | Voltage | Frame | Service Factor | Hp | Efficiency | Output Hp | Synchronous Speed | No Load Amps | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 02012ET3E286JP-W22 | 208-230/460/380V AC | 284JP | 1 | - | 50% | 20 hp | 1200 RPM | 9.5/16.4-19A | €5,745.04 | |
| B | 01512ET3E284JP-W22 | 208-230/460V | 284JP | 1 | - | 50% | 15 hp | - | 7.5/15A | €4,591.73 | |
| C | 00312ET3E213JP-W22 | 208-230/460V | 215JP | 1 | - | 50% | 3 hp | - | 2.75/5.5A | €1,728.77 | |
| D | 00512ET3E215JP-W22 | 208/230/460V AC | 213JP | 1.25 | - | 50% | 5 hp | 1200 RPM | 3.45/6.9A | €2,082.00 | |
| E | 00236ET3E145JM-W22 | 208/230/460V AC | 143JM | 1 | 2 hp | 50% | 2 hp | 3600 RPM | 0.99/1.98A | €814.87 | |
| F | 06012ET3E404JP-W22 | 208/230/460V AC | 405JP | 1.25 | 60 hp | 50% | 60 hp | 1200 RPM | 25/50A | €14,255.50 | |
| G | 00712ET3E254JM-S | 208/230/460V AC | 254JM | 1.15 | 7 1/2 hp | 91% | 7 1/2 hp | 1200 RPM | 5.03/10.1A | €2,838.04 | |
| H | 00536ET3E184JM-S | 208/230/460V AC | 184JM | 1.15 | 5 hp | 88.5% | 5 hp | 3600 RPM | 2.2/4.4A | €1,282.55 | |
| I | 01536ET3E254JP-S | 208/230/460V AC | 254JP | 1.15 | - | 91% | 15 hp, 12 1/2 hp | 3600 RPM | 6.5/13A | €3,039.19 | |
| J | 00318ET3E182JP-S | 208/230/460V AC | 184JP | 1.15 | - | 89.5% | 3 hp | 1800 RPM | - | €1,241.99 | |
| A | 03012ET3E326JP-W22 | 208/230/460V AC | 324JP | 1.25 | 30 hp | 50% | 30 hp | 1200 RPM | 16.4/32.8A | €7,663.88 | |
| I | 01518ET3E254JP-S | 208/230/460V AC | 254JP | 1.15 | - | 92.4% | 15 hp | 1800 RPM | 8.65/17.3A | €3,066.92 | |
| K | 00112ET3E145JP-S | 208/230/460V AC | 143JP | 1.15 | - | 82.5% | 1 hp | 1200 RPM | 1.01/2.03A | €851.86 | |
| L | 00212ET3E184JP-W22 | 208/230/460V AC | 182JP | 1.25 | - | 50% | 2 hp | 1200 RPM | 1.9/3.8A | €1,240.80 | |
| M | 00118ET3E143JM-S | 208/230/460V AC | 145JM | 1.15 | 1 hp | 85.5% | 1 hp | 1800 RPM | 0.89/1.78A | €731.35 | |
| N | 01536EP3E254JM-W22 | 208/230/460V AC | 254JM | 1.25 | 15 hp | 50% | - | 3600 RPM | 4.6/9.2A | €2,345.57 | |
| H | 00518ET3E184JM-S | 208/230/460V AC | 184JM | 1.15 | 5 hp | 89.5% | 5 hp | 1800 RPM | 3.44/6.88A | €1,361.31 | |
| A | 00712ET3E254JP-W22 | 208/230/460V AC | 254JP | 1.25 | 7 1/2 hp | 50% | 7 1/2 hp | 1200 RPM | 4.5/8.1-9A | €2,884.28 | |
| F | 04012ET3E364JP-W22 | 208/230/460V AC | 365JP | 1.25 | 40 hp | 50% | 40 hp | 1200 RPM | 16.5/33A | €10,617.16 | |
| A | 02512ET3E324JP-W22 | 208/230/460V AC | 326JP | 1.25 | 25 hp | 50% | 25 hp | 1200 RPM | 14/28A | €6,841.36 | |
| M | 00236ET3E145JM-S | 208/230/460V AC | 145JM | 1.15 | - | 85.5% | 2 hp | 3600 RPM | 1.06/2.13A | €814.87 | |
| O | 05012ET3E365JM-W22 | 208/230/460V AC | 365JM | 1.25 | 50 hp | 50% | 50 hp | 1200 RPM | 20/40A | €12,086.92 | |
| K | 00218ET3E145JP-S | 208/230/460V AC | 143JP | 1.15 | - | 86.5% | 2 hp | 1800 RPM | 1.4/2.8A | €856.62 | |
| L | 00152ET3E182JP-W22 | 208/230/460V AC | 184JP | 1.25 | 1 1/2 hp | 50% | 1 1/2 hp | 1200 RPM | 1.63/3.25A | €1,102.39 | |
| I | 00712ET3E254JP-S | 208/230/460V AC | 256JP | 1.15 | 7 1/2 hp | - | - | 1200 RPM | 5.03/10.1A | €2,884.28 | |
| H | 00212ET3E184JM-S | 208/230/460V AC | 184JM | 1.15 | - | 88.5% | 2 hp | 1200 RPM | - | €1,218.14 | |
| I | 01012ET3E256JP-S | 208/230/460V AC | 254JP | 1.15 | - | 91% | 10 hp, 7 1/2 hp | 1200 RPM | 7.12/14.2A | €3,587.14 | |
| K | 00152ET3E182JP-S | 230/460/190-220/380-415V AC | 184JP | 1.15 | 1 1/2 hp | 87.5% | 1 1/2 hp | 1200 RPM | 1.36/2.73A | €1,102.39 | |
| G | 02018ET3E256JM-S | 230/460/190-220/380-415V AC | 254JM | 1.15 | 20 hp | 93% | 20 hp, 15 hp | 1800 RPM | 11.1/22.2A | €3,302.77 | |
| M | 00158ET3E145JM-S | 230/460/190-220/380-415V AC | 145JM | 1.15 | 1 1/2 hp | 86.5% | 1 1/2 hp | 1800 RPM | 1.08/2.17A | €767.14 | |
| K | 00212ET3E184JP-S | 230/460/190-220/380-415V AC | 182JP | 1.15 | - | 88.5% | 2 hp | 1200 RPM | 1.87/3.74A | €1,240.80 | |
| G | 01536ET3E254JM-S | 230/460/190-220/380-415V AC | 254JM | 1.15 | - | 91% | 15 hp, 12 1/2 hp | 3600 RPM | 6.5/13A | €2,559.44 | |
| G | 02036ET3E256JM-S | 230/460/190-220/380-415V AC | 256JM | 1.15 | 20 hp | 91% | 20 hp, 15 hp | 3600 RPM | 6.88/13.8A | €3,427.62 | |
| I | 01018ET3E215JP-S | 230/460/190-220/380-415V AC | 213JP | 1.15 | - | 91.7% | 10 hp, 7 1/2 hp | 1800 RPM | 5.54/11.1A | €2,120.59 | |
| M | 00156ET3E143JM-S | 230/460/190-220/380-415V AC | 145JM | 1.15 | 1 1/2 hp | 84% | 1 1/2 hp | 3600 RPM | 0.859/1.72A | €847.08 | |
| H | 00336ET3E182JM-S | 230/460/190-220/380-415V AC | 184JM | 1.15 | 3 hp | 86.5% | 3 hp | 3600 RPM | 1.7/3.4A | €1,095.24 | |
| H | 00318ET3E182JM-S | 230/460/190-220/380-415V AC | 184JM | 1.15 | 3 hp | 89.5% | 3 hp | 1800 RPM | - | €1,219.32 | |
| K | 00118ET3E143JP-S | 230/460/190-220/380-415V AC | 145JP | 1.15 | - | 85.5% | 1 hp | 1800 RPM | 0.89/1.78A | €744.48 | |
| G | 01518ET3E254JM-S | 230/460/190-220/380-415V AC | 254JM | 1.15 | 15 hp | 92.4% | 15 hp | 1800 RPM | 8.65/17.3A | €3,016.06 | |
| P | 00212ET3E184JM-W22 | 230/460/380V AC | 184JM | 1.25 | 2 hp | 50% | 2 hp | 1200 RPM | 1.9/3.8A | €1,218.14 | |
| F | 05012ET3E365JP-W22 | 230/460/380V AC | 364JP | 1.25 | 50 hp | 50% | 50 hp | 1200 RPM | 20/40A | €12,312.60 | |
| N | 01512ET3E284JM-W22 | 230/460/380V AC | 286JM | 1.25 | - | 50% | 15 hp | 1200 RPM | 7/14A | €4,522.38 | |
| E | 00112ET3E145JM-W22 | 230/460/380V AC | 143JM | 1.25 | 1 hp | 50% | 1 hp | 1200 RPM | 1.1/2.2A | €835.15 | |
| P | 00152ET3E182JM-W22 | 230/460/380V AC | 182JM | 1.25 | 1 1/2 hp | 50% | 1 1/2 hp | 1200 RPM | 1.63/3.25A | €1,084.51 | |
| N | 02512ET3E324JM-W22 | 230/460/380V AC | 326JM | 1.25 | 25 hp | 50% | 25 hp, 20 hp | 1200 RPM | 14/28A | €6,353.33 | |
| O | 04012ET3E364JM-W22 | 230/460/380V AC | 364JM | 1.25 | 40 hp | 50% | 40 hp | 1200 RPM | 16.5/33A | €10,089.05 | |
| N | 03012ET3E326JM-W22 | 230/460/380V AC | 324JM | 1.25 | 30 hp | 50% | 30 hp | 1200 RPM | 16.4/32.8A | €7,659.29 | |
| N | 02012ET3E286JM-W22 | 230/460/380V AC | 284JM | 1.25 | - | 50% | 20 hp | 1200 RPM | 9.5/19A | €5,659.13 | |
| N | 00712ET3E254JM-W22 | 230/460/380V AC | 256JM | 1.25 | 7 1/2 hp | 50% | 7 1/2 hp | 1200 RPM | 5.3/10.6A | €2,838.04 | |
| F | 07512ET3E405JP-W22 | 230/460/380V AC | 405JP | 1.25 | 75 hp | 50% | 75 hp | 1200 RPM | 30/60A | €16,043.73 | |
| Q | 00112ET3E145JP-W22 | 230/460/380V AC | 145JP | 1.25 | - | 50% | 1 hp | 1200 RPM | 1.1/2.2A | €851.86 | |
| R | 01012ET3E256JP-W22 | 230/460/380V AC | 254JP | 1.25 | - | 50% | 10 hp | 1200 RPM | 6/12A | €3,587.14 | |
| S | 00158ET3E145JP-S | 230/460V | 145JP | 1.15 | 1 1/2 hp | 86.5% | 1 1/2 hp | - | - | €779.07 | |
| T | 00218ET3E145JM-S | 230/460V | 143JM | 1.15 | 2 hp | 86.5% | 2 hp | - | - | €843.51 | |
| T | 00152ET3E182JM-S | 230/460V | 182JM | 1.15 | 1 1/2 hp | 87.5% | 1 1/2 hp | - | - | €1,084.51 | |
| S | 00736ET3E213JP-S | 230/460V | 215JP | - | 7 1/2 hp | - | - | - | - | €1,724.00 | |
| S | 00236ET3E145JP-S | 230/460V | 145JP | 1.15 | - | 85.5% | 2 hp | - | - | €828.00 | |
| S | 00518ET3E184JP-S | 230/460V | 182JP | - | - | - | - | - | - | €1,385.17 | |
| U | 02018ET3E256JP-S | 230/460V | 254JP | 1.15 | - | 93% | 20 hp, 15 hp | - | - | €3,361.71 | |
| S | 00718ET3E213JP-S | 230/460V | 215JP | 1.15 | 7 1/2 hp | 91.7% | 7 1/2 hp | - | - | €1,794.88 | |
| S | 00156ET3E143JP-S | 230/460V | 145JP | 1.15 | 1 1/2 hp | 84% | 1 1/2 hp | - | - | €774.31 |
