MARTIN SPROCKET 140S54 Sprocket, 140 Chain, 54 Teeth, 30.097 Inch Pitch Dia., 31.096 Inch O.D., Steel
31.096"
Get it by Friday, Jul 10
€2,201.87 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Roller Chain Sprocket |
| Bore Dia. | 1.875" to 4.188" |
| Bore Type | Bushed |
| Bushing Part Number | S2 |
| Bushing Size | S2 |
| Bushing Type | MST S2 |
| Chain Number | 140 |
| Chain Pitch | 1 3/4" |
| Chain Size | #140 |
| Construction | Welded With Lightening Holes |
| Construction Type | Welded With Lightening Holes |
| For Chain Number | 140 |
| For Chain Pitch | 1 3/4" |
| Hub Configuration | C |
| Hub Dia. | 6 1/2" |
| Hub Outside Dia. | 6 1/2" |
| Individually Packaged | No |
| Key Way Size | 3/4" |
| Keyway Width | 3/4" |
| Length Through Bore | 5 11/16" |
| Material | Steel |
| Max. Bore Size | 4 3/16" |
| Min. Bore Size | 1 7/8" |
| No. Of Chain Rows | 1 |
| No. Of Teeth | 54 |
| Outside Dia. | 31.096" |
| Pitch | 1 3/4" |
| Pitch Dia. | 30.0973" |
| Single Strand Tooth Thickness | 0.924" |
| Storage Dimension Height | 5.69" |
| Storage Dimension Length | 31.096" |
| Storage Dimension Width | 31.096" |
| Type | Type 6 Single Strand Welded Bushed |
Shipping Info:
| Ship weight (kg) | 72.03 |
| Ship height (cm) | 14.45 |
| Ship length (cm) | 78.99 |
| Ship width (cm) | 78.99 |
| Country of Origin | US |
Product Variants
| Product | Model | Bore Dia. | Pitch Dia. | Outside Dia. | Keyway Width | Hub Dia. | Length Through Bore | Bushing Type | For Chain Number | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
140R35 | 1 3/8" to 3 3/8" | 19.5227" | 20.494" | 3/4" | 5 1/2" | 4" | MST R2 | 140 | €1,385.40 | |
|
140R36 | 1 3/8" to 3 3/8" | 20.079" | 21.053" | 3/4" | 5 1/2" | 4" | MST R2 | 140 | €1,458.82 | |
 |
140S36 | 1.688" to 4.25" | 20.079" | 21.053" | 3/4" | 6 1/2" | 3 5/16" | MST S1 | 140 | €1,458.82 | |
 |
140R40 | 1 3/8" to 3 3/8" | 22.3046" | 23.286" | 3/4" | 5 1/2" | 4" | MST R2 | 140 | €1,601.71 | |
 |
140S40 | 1.688" to 4.25" | 22.3046" | 23.286" | 3/4" | 6 1/2" | 3 5/16" | MST S1 | 140 | €1,601.71 | |
 |
140S45 | 1.688" to 4.25" | 25.0873" | 26.076" | 3/4" | 6 1/2" | 3 5/16" | MST S1 | 140 | €1,708.38 | |
 |
140S60 | 1.875" to 4.188" | 33.4378" | 34.442" | 3/4" | 6 1/2" | 5 11/16" | MST S2 | 140 | €2,308.54 |
