LINN GEAR -

Type A Sprockets, 120 Chain

Style	Model	Pitch Dia.	Price
A	120a10h	-	€115.39
A	120a12h	-	€133.18
A	120a24h	-	€270.63
A	120a23h	-	€256.94
A	120a22h	-	€241.74
A	120a21h	-	€228.06
A	120a20h	-	€217.41
A	120a19h	-	€208.29
A	120a18h	-	€197.64
A	120a17h	-	€179.40
A	120a16h	-	€168.76
A	120a15h	-	€161.16
A	120a14h	-	€150.06
A	120a11h	-	€124.82
A	120a13h	-	€141.24
A	120a28h	-	€339.04
A	120a27h	-	€329.92
A	120a25h	-	€281.27
A	120a30h	-	€357.28
A	120a26h	-	€297.99
A	120a32	15.303"	€349.68
A	120a34	16.257"	€372.49
A	120a35	16.734"	€375.53
A	120a36	17.211"	€390.73
A	120a38	18.164"	€424.18

MARTIN SPROCKET -

Duplex Stock Bore B Type Metric Roller Chain Sprockets, 24B-2 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	D24B11	32 mm to 63 mm	135.235 mm	157.46 mm	89.992 mm	100 mm	38.1 mm	€1,111.56
B	D24B12	32 mm to 72 mm	147.207 mm	169.432 mm	102.006 mm	100 mm	38.1 mm	€1,095.43
C	D24B13	32 mm to 78 mm	159.204 mm	181.429 mm	113.995 mm	100 mm	38.1 mm	€1,175.50
D	D24B14	32 mm to 90 mm	171.22 mm	193.445 mm	127.991 mm	100 mm	38.1 mm	€1,256.44
A	D24B15	32 mm to 99 mm	183.251 mm	205.476 mm	140.005 mm	100 mm	38.1 mm	€1,309.61
E	D24B16	32 mm to 106 mm	195.294 mm	217.519 mm	150.012 mm	100 mm	38.1 mm	€1,362.79
F	D24B17	40 mm to 106 mm	207.347 mm	229.572 mm	150.012 mm	100 mm	38.1 mm	€1,443.05
G	D24B28	40 mm to 110 mm	340.287 mm	362.512 mm	159.995 mm	102.006 mm	38.1 mm	€2,546.98
G	D24B29	40 mm to 110 mm	352.389 mm	374.614 mm	159.995 mm	102.006 mm	38.1 mm	€2,604.60
H	D24B22	40 mm to 110 mm	267.716 mm	289.941 mm	159.995 mm	102.006 mm	38.1 mm	€2,004.23
I	D24B27	40 mm to 110 mm	328.185 mm	350.41 mm	159.995 mm	102.006 mm	38.1 mm	€2,489.22
J	D24B26	40 mm to 112 mm	316.086 mm	338.311 mm	159.995 mm	102.006 mm	38.1 mm	€2,431.63
A	D24B18	40 mm to 112 mm	219.409 mm	241.634 mm	159.995 mm	100 mm	38.1 mm	€1,575.99
K	D24B21	40 mm to 112 mm	255.632 mm	277.857 mm	159.995 mm	100 mm	38.1 mm	€1,870.12
G	D24B23	40 mm to 112 mm	279.804 mm	302.029 mm	159.995 mm	102.006 mm	38.1 mm	€2,244.34
L	D24B20	40 mm to 113 mm	243.552 mm	265.777 mm	159.995 mm	100 mm	38.1 mm	€1,763.60
M	D24B19	40 mm to 113 mm	231.478 mm	253.703 mm	162.535 mm	100 mm	38.1 mm	€1,683.50

MARTIN SPROCKET -

Duplex Stock Bore B Type Metric Roller Chain Sprockets, 32B-2 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	D32B12	40 mm to 94 mm	196.276 mm	230.566 mm	132.994 mm	119.99 mm	50.8 mm	€1,631.79
B	D32B13	40 mm to 102 mm	212.272 mm	246.562 mm	145.009 mm	119.99 mm	50.8 mm	€1,831.24
A	D32B14	40 mm to 108 mm	228.293 mm	262.583 mm	154.991 mm	119.99 mm	50.8 mm	€2,030.72
C	D32B15	40 mm to 108 mm	244.335 mm	278.625 mm	159.995 mm	119.99 mm	50.8 mm	€2,090.19
A	D32B16	40 mm to 125 mm	260.392 mm	294.682 mm	178.003 mm	119.99 mm	50.8 mm	€2,242.72
D	D32B19	40 mm to 125 mm	308.637 mm	342.927 mm	178.003 mm	119.99 mm	50.8 mm	€2,687.58
A	D32B18	40 mm to 126 mm	292.546 mm	326.836 mm	178.003 mm	119.99 mm	50.8 mm	€2,539.56
E	D32B17	40 mm to 126 mm	276.463 mm	310.753 mm	178.003 mm	119.99 mm	50.8 mm	€2,390.89
F	D32B25	40 mm to 134 mm	405.319 mm	439.609 mm	191.008 mm	119.99 mm	50.8 mm	€4,408.93
G	D32B30	40 mm to 134 mm	485.992 mm	520.282 mm	191.008 mm	119.99 mm	50.8 mm	€5,389.01
G	D32B26	40 mm to 134 mm	421.448 mm	455.738 mm	191.008 mm	119.99 mm	50.8 mm	€4,633.59
G	D32B23	40 mm to 134 mm	373.072 mm	407.362 mm	191.008 mm	119.99 mm	50.8 mm	€3,807.04
H	D32B21	40 mm to 134 mm	340.843 mm	375.133 mm	191.008 mm	119.99 mm	50.8 mm	€3,285.47
G	D32B28	40 mm to 134 mm	453.715 mm	488.005 mm	191.008 mm	119.99 mm	50.8 mm	€5,011.31
G	D32B27	40 mm to 134 mm	437.581 mm	471.871 mm	191.008 mm	119.99 mm	50.8 mm	€4,822.38
G	D32B22	40 mm to 134 mm	356.955 mm	391.245 mm	191.008 mm	119.99 mm	50.8 mm	€3,510.33
G	D32B24	40 mm to 134 mm	389.194 mm	423.484 mm	191.008 mm	119.99 mm	50.8 mm	€4,112.39
A	D32B20	40 mm to 134 mm	324.737 mm	359.027 mm	191.008 mm	119.99 mm	50.8 mm	€2,988.77

MARTIN SPROCKET -

Simplex Stock Bore A Type Metric Roller Chain Sprockets, 32B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Length Through Bore	Pitch	Price
A	32A11	32 mm	180.313 mm	214.603 mm	80 mm	50.8 mm	€541.13
B	32A13	32 mm	212.272 mm	246.562 mm	70 mm	50.8 mm	€536.74
C	32A15	40 mm	244.335 mm	278.625 mm	70 mm	50.8 mm	€630.47
D	32A45	40 mm	728.248 mm	762.538 mm	127 mm	50.8 mm	€2,865.99
E	32A57	40 mm	922.165 mm	956.455 mm	127 mm	50.8 mm	€4,516.17
F	32A29	40 mm	469.853 mm	504.143 mm	76 mm	50.8 mm	€1,285.51
G	32A20	40 mm	324.737 mm	359.027 mm	70 mm	50.8 mm	€841.06
H	32A16	40 mm	260.392 mm	294.682 mm	70 mm	50.8 mm	€678.64
B	32A27	40 mm	437.581 mm	471.871 mm	76 mm	50.8 mm	€1,155.69
I	32A40	40 mm	647.471 mm	681.761 mm	114 mm	50.8 mm	€2,324.73
B	32A68	40 mm	1099.961 mm	1134.251 mm	127 mm	50.8 mm	€6,030.52
J	32A18	40 mm	292.546 mm	326.836 mm	70 mm	50.8 mm	€767.87
K	32A24	40 mm	389.194 mm	423.484 mm	76 mm	50.8 mm	€986.64
L	32A48	40 mm	776.721 mm	811.011 mm	127 mm	50.8 mm	€3,278.47
M	32A19	40 mm	308.637 mm	342.927 mm	70 mm	50.8 mm	€816.00
N	32A26	40 mm	421.448 mm	455.738 mm	76 mm	50.8 mm	€1,102.46
O	32A30	40 mm	485.992 mm	520.282 mm	76 mm	50.8 mm	€1,346.31
P	32A17	40 mm	276.463 mm	310.753 mm	70 mm	50.8 mm	€720.31
Q	32A32	40 mm	518.277 mm	552.567 mm	76 mm	50.8 mm	€1,541.76
B	32A72	40 mm	1164.62 mm	1198.91 mm	152 mm	50.8 mm	€6,580.66
R	32A23	40 mm	373.072 mm	407.362 mm	70 mm	50.8 mm	€957.80
B	32A42	40 mm	679.78 mm	714.07 mm	114 mm	50.8 mm	€2,541.42
B	32A76	40 mm	1229.281 mm	1263.571 mm	152 mm	50.8 mm	€7,130.57
S	32A21	40 mm	340.843 mm	375.133 mm	70 mm	50.8 mm	€900.05
T	32A22	40 mm	356.955 mm	391.245 mm	70 mm	50.8 mm	€914.30

MARTIN SPROCKET -

Simplex Stock Bore B Type Metric Roller Chain Sprockets, 32B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	32B11	40 mm to 83 mm	180.313 mm	214.603 mm	119.99 mm	80 mm	50.8 mm	€765.13
B	32B12	40 mm to 94 mm	196.276 mm	230.566 mm	132.994 mm	80 mm	50.8 mm	€778.89
C	32B13	40 mm to 105 mm	212.272 mm	246.562 mm	151.994 mm	70 mm	50.8 mm	€869.91
D	32B17	40 mm to 125 mm	276.463 mm	310.753 mm	178.003 mm	70 mm	50.8 mm	€1,128.63
E	32B18	40 mm to 125 mm	292.546 mm	326.836 mm	178.003 mm	70 mm	50.8 mm	€1,209.81
F	32B20	40 mm to 125 mm	324.737 mm	359.027 mm	178.003 mm	70 mm	50.8 mm	€1,373.36
G	32B28	40 mm to 125 mm	453.715 mm	488.005 mm	180.619 mm	76 mm	50.8 mm	€2,039.90
H	32B15	40 mm to 125 mm	244.335 mm	278.625 mm	178.003 mm	70 mm	50.8 mm	€1,030.15
I	32B16	40 mm to 125 mm	260.392 mm	294.682 mm	178.003 mm	70 mm	50.8 mm	€1,117.08
J	32B19	40 mm to 125 mm	308.637 mm	342.927 mm	178.003 mm	70 mm	50.8 mm	€1,292.16
K	32B21	40 mm to 125 mm	340.843 mm	375.133 mm	178.003 mm	70 mm	50.8 mm	€1,454.89
L	32B30	40 mm to 126 mm	485.992 mm	520.282 mm	180.619 mm	76 mm	50.8 mm	€2,311.36
M	32B22	40 mm to 126 mm	356.955 mm	391.245 mm	178.003 mm	70 mm	50.8 mm	€1,577.00
N	32B26	40 mm to 126 mm	421.448 mm	455.738 mm	180.619 mm	76 mm	50.8 mm	€1,781.31
O	32B25	40 mm to 126 mm	405.319 mm	439.609 mm	178.003 mm	76 mm	50.8 mm	€1,739.20
N	32B27	40 mm to 126 mm	437.581 mm	471.871 mm	180.619 mm	76 mm	50.8 mm	€1,971.25
N	32B23	40 mm to 126 mm	373.072 mm	407.362 mm	178.003 mm	70 mm	50.8 mm	€1,632.30
P	32B24	40 mm to 126 mm	389.194 mm	423.484 mm	178.003 mm	76 mm	50.8 mm	€1,686.43
N	32B32	40 mm to 140 mm	518.277 mm	552.567 mm	202.997 mm	76 mm	50.8 mm	€2,458.38

MARTIN SPROCKET -

Simplex Taper Bushed Metric Roller Chain Sprockets, 32B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Bushing Type	Pitch	Price
A	32BTB11H	63.5 mm	180.31 mm	214.6 mm	108 mm	44.45 mm	2517 Taper	50.8 mm	€982.16
A	32BTB12H	76.2 mm	196.28 mm	230.57 mm	133 mm	50.8 mm	3020 Taper	50.8 mm	€931.40
A	32BTB14H	76.2 mm	228.29 mm	262.58 mm	133 mm	50.8 mm	3020 Taper	50.8 mm	€1,104.43
A	32BTB13H	76.2 mm	212.27 mm	246.56 mm	133 mm	50.8 mm	3020 Taper	50.8 mm	€1,004.99
B	32BTB20H	88.9 mm	324.74 mm	359.03 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,539.08
A	32BTB30	88.9 mm	485.99 mm	520.28 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€2,386.21
A	32BTB15H	88.9 mm	244.33 mm	278.62 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,145.52
C	32BTB17H	88.9 mm	276.46 mm	310.75 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,238.39
A	32BTB19H	88.9 mm	308.64 mm	342.93 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,492.63
D	32BTB18H	88.9 mm	292.55 mm	326.84 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,307.52
A	32BTB27	88.9 mm	437.58 mm	471.87 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€2,098.22
A	32BTB32	88.9 mm	518.28 mm	552.57 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€2,578.33
A	32BTB16H	88.9 mm	260.39 mm	294.68 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,191.95
A	32BTB23H	88.9 mm	373.07 mm	407.36 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,752.07
A	32BTB22H	88.9 mm	356.96 mm	391.25 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,668.71
E	32BTB24H	88.9 mm	389.19 mm	423.48 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,835.45
A	32BTB25H	88.9 mm	405.32 mm	439.61 mm	165 mm	88.9 mm	3535 Taper	50.8 mm	€1,918.81
F	32CTB48	101.6 mm	776.72 mm	811.01 mm	219 mm	101.6 mm	4040 Taper	50.8 mm	€4,115.89
F	32CTB45	101.6 mm	728.25 mm	762.54 mm	219 mm	101.6 mm	4040 Taper	50.8 mm	€3,929.15
F	32CTB54	101.6 mm	873.68 mm	907.97 mm	219 mm	114.3 mm	4040 Taper	50.8 mm	€5,407.25
F	32CTB60	114.3 mm	970.65 mm	1004.94 mm	248 mm	114.3 mm	4545 Taper	50.8 mm	€5,653.17
F	32CTB57	114.3 mm	922.16 mm	956.45 mm	248 mm	114.3 mm	4545 Taper	50.8 mm	€5,600.70
G	32CTB70	114.3 mm	1132.29 mm	1166.58 mm	248 mm	114.3 mm	4545 Taper	50.8 mm	€7,376.80

MARTIN SPROCKET -

Simplex Stock Bore C Type Metric Roller Chain Sprockets, 32B-1 Chain Number

Style	Model	Pitch Dia.	Outside Dia.	Length Through Bore	Bore Dia.	Hub Dia.	Pitch	Price
A	32C38	615.166 mm	649.456 mm	114 mm	40 mm to 140 mm	202.997 mm	50.8 mm	€2,857.48
A	32C42	679.78 mm	714.07 mm	114 mm	40 mm to 140 mm	202.997 mm	50.8 mm	€3,490.61
A	32C45	728.248 mm	762.538 mm	127 mm	40 mm to 140 mm	202.997 mm	50.8 mm	€3,781.46
A	32C48	776.721 mm	811.011 mm	127 mm	40 mm to 140 mm	202.997 mm	50.8 mm	€4,369.83
B	32C54	873.68 mm	907.97 mm	127 mm	40 mm to 140 mm	202.997 mm	50.8 mm	€5,083.00
A	32C68	1099.961 mm	1134.251 mm	127 mm	40 mm to 140 mm	202.997 mm	50.8 mm	€6,946.00
A	32C72	1164.62 mm	1198.91 mm	152 mm	40 mm to 140 mm	202.997 mm	50.8 mm	€7,733.82
A	32C76	1229.281 mm	1263.571 mm	152 mm	40 mm to 140 mm	202.997 mm	50.8 mm	€8,132.91

MARTIN SPROCKET -

Duplex Stock Bore C Type Metric Roller Chain Sprockets, 28B-2 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	D28C48	40 mm to 133 mm	679.631 mm	707.254 mm	190.983 mm	159.004 mm	44.45 mm	€5,147.83
A	D28C45	40 mm to 133 mm	637.217 mm	664.839 mm	190.983 mm	159.004 mm	44.45 mm	€4,835.81
A	D28C38	40 mm to 135 mm	538.27 mm	565.893 mm	190.983 mm	159.004 mm	44.45 mm	€4,109.52
A	D28C72	40 mm to 166 mm	1019.042 mm	1046.665 mm	240.995 mm	181.762 mm	44.45 mm	€7,644.09
A	D28C57	40 mm to 166 mm	806.894 mm	834.517 mm	240.995 mm	181 mm	44.45 mm	€6,083.86
B	D28C54	40 mm to 170 mm	764.47 mm	792.093 mm	240.995 mm	181 mm	44.45 mm	€5,771.84

MARTIN SPROCKET -

Duplex Stock Bore B Type Metric Roller Chain Sprockets, 28B-2 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	D28B12	40 mm to 88 mm	171.742 mm	199.364 mm	124.993 mm	119.99 mm	44.45 mm	€1,149.89
B	D28B14	40 mm to 90 mm	199.756 mm	227.379 mm	129.997 mm	119.99 mm	44.45 mm	€1,309.61
B	D28B15	40 mm to 95 mm	213.793 mm	241.415 mm	134.976 mm	119.99 mm	44.45 mm	€1,575.99
B	D28B16	40 mm to 102 mm	227.843 mm	255.466 mm	144.983 mm	119.99 mm	44.45 mm	€1,683.50
C	D28B17	40 mm to 112 mm	241.905 mm	269.528 mm	159.995 mm	119.736 mm	44.45 mm	€1,763.60
B	D28B18	40 mm to 125 mm	255.977 mm	283.6 mm	178.003 mm	119.99 mm	44.45 mm	€1,976.80
D	D28B26	40 mm to 126 mm	368.767 mm	396.39 mm	178.003 mm	119.99 mm	44.45 mm	€2,861.47
E	D28B20	40 mm to 126 mm	284.145 mm	311.767 mm	178.003 mm	119.99 mm	44.45 mm	€2,270.27
D	D28B24	40 mm to 126 mm	340.545 mm	368.167 mm	178.003 mm	119.99 mm	44.45 mm	€2,715.56
D	D28B28	40 mm to 126 mm	397.001 mm	424.623 mm	178.003 mm	119.99 mm	44.45 mm	€3,069.44
D	D28B30	40 mm to 126 mm	425.243 mm	452.866 mm	178.003 mm	119.99 mm	44.45 mm	€3,277.39
D	D28B32	40 mm to 126 mm	453.492 mm	481.115 mm	178.003 mm	119.99 mm	44.45 mm	€3,485.50
B	D28B19	40 mm to 126 mm	270.057 mm	297.68 mm	178.003 mm	119.99 mm	44.45 mm	€2,084.31
F	D28B21	40 mm to 126 mm	298.238 mm	325.86 mm	178.003 mm	120.015 mm	44.45 mm	€2,461.64
D	D28B22	40 mm to 126 mm	312.336 mm	339.958 mm	178.003 mm	119.99 mm	44.45 mm	€2,495.14

MARTIN SPROCKET -

Simplex Stock Bore C Type Metric Roller Chain Sprockets, 28B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	28C45	40 mm to 126 mm	637.217 mm	664.839 mm	177.978 mm	102 mm	44.45 mm	€1,936.75
B	28C57	40 mm to 126 mm	806.894 mm	834.517 mm	177.978 mm	127 mm	44.45 mm	€3,059.75
A	28C40	40 mm to 126 mm	566.537 mm	594.16 mm	177.978 mm	102 mm	44.45 mm	€1,857.00
A	28C54	40 mm to 126 mm	764.47 mm	792.093 mm	177.978 mm	127 mm	44.45 mm	€2,948.78
A	28C48	40 mm to 126 mm	679.631 mm	707.254 mm	177.978 mm	102 mm	44.45 mm	€2,440.97
A	28C38	40 mm to 126 mm	538.27 mm	565.893 mm	177.978 mm	102 mm	44.45 mm	€1,658.55
A	28C68	40 mm to 135 mm	962.466 mm	990.088 mm	191.008 mm	127 mm	44.45 mm	€4,077.37
C	28C76	40 mm to 135 mm	1075.621 mm	1103.243 mm	191.008 mm	127 mm	44.45 mm	€4,898.02

MARTIN SPROCKET -

Simplex Stock Bore A Type Metric Roller Chain Sprockets, 28B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Length Through Bore	Pitch	Price
A	28A11	32 mm	157.774 mm	185.396 mm	70 mm	44.45 mm	€379.35
A	28A12	32 mm	171.742 mm	199.364 mm	70 mm	44.45 mm	€403.69
A	28A14	32 mm	199.756 mm	227.379 mm	60 mm	44.45 mm	€473.30
A	28A24	40 mm	340.545 mm	368.167 mm	64 mm	44.45 mm	€778.00
A	28A25	40 mm	354.655 mm	382.277 mm	64 mm	44.45 mm	€798.84
A	28A21	40 mm	298.238 mm	325.86 mm	64 mm	44.45 mm	€634.92
B	28A29	40 mm	411.121 mm	438.744 mm	64 mm	44.45 mm	€903.04
C	28A32	40 mm	453.492 mm	481.115 mm	76 mm	44.45 mm	€1,111.56
A	28A22	40 mm	312.336 mm	339.958 mm	64 mm	44.45 mm	€684.15
C	28A45	40 mm	637.217 mm	664.839 mm	102 mm	44.45 mm	€1,683.50
C	28A48	40 mm	679.631 mm	707.254 mm	102 mm	44.45 mm	€1,924.29
C	28A68	40 mm	962.466 mm	990.088 mm	127 mm	44.45 mm	€3,757.78
A	28A16	40 mm	227.843 mm	255.466 mm	64 mm	44.45 mm	€463.43
A	28A19	40 mm	270.057 mm	297.68 mm	64 mm	44.45 mm	€566.37
A	28A20	40 mm	284.145 mm	311.767 mm	64 mm	44.45 mm	€598.02
A	28A27	40 mm	382.883 mm	410.505 mm	64 mm	44.45 mm	€826.34
A	28A18	40 mm	255.977 mm	283.6 mm	64 mm	44.45 mm	€527.34
A	28A15	40 mm	213.793 mm	241.415 mm	60 mm	44.45 mm	€434.09
C	28A57	40 mm	806.894 mm	834.517 mm	127 mm	44.45 mm	€2,677.96
A	28A30	40 mm	425.243 mm	452.866 mm	64 mm	44.45 mm	€932.09
A	28A26	40 mm	368.767 mm	396.39 mm	64 mm	44.45 mm	€761.40
C	28A40	40 mm	566.537 mm	594.16 mm	102 mm	44.45 mm	€1,349.33
C	28A72	40 mm	1019.042 mm	1046.665 mm	127 mm	44.45 mm	€4,111.99

MARTIN SPROCKET -

Simplex Stock Bore B Type Metric Roller Chain Sprockets, 28B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	28B11	40 mm to 76 mm	157.774 mm	185.396 mm	111.989 mm	70 mm	44.45 mm	€605.75
B	28B12	40 mm to 88 mm	171.742 mm	199.364 mm	124.993 mm	70 mm	44.45 mm	€671.61
C	28B14	40 mm to 95 mm	199.756 mm	227.379 mm	140.005 mm	60 mm	44.45 mm	€804.46
D	28B13	40 mm to 95 mm	185.738 mm	213.36 mm	140.005 mm	70 mm	44.45 mm	€738.98
C	28B23	40 mm to 108 mm	326.438 mm	354.061 mm	159.995 mm	64 mm	44.45 mm	€1,057.45
C	28B26	40 mm to 108 mm	368.767 mm	396.39 mm	159.995 mm	64 mm	44.45 mm	€1,078.83
C	28B20	40 mm to 108 mm	284.145 mm	311.767 mm	159.995 mm	64 mm	44.45 mm	€983.73
E	28B18	40 mm to 108 mm	255.977 mm	283.6 mm	159.995 mm	64 mm	44.45 mm	€884.28
C	28B27	40 mm to 108 mm	382.883 mm	410.505 mm	159.995 mm	64 mm	44.45 mm	€1,112.33
C	28B28	40 mm to 108 mm	397.001 mm	424.623 mm	159.995 mm	64 mm	44.45 mm	€1,135.46
F	28B17	40 mm to 108 mm	241.905 mm	269.528 mm	159.995 mm	64 mm	44.45 mm	€854.70
C	28B30	40 mm to 108 mm	425.243 mm	452.866 mm	159.995 mm	64 mm	44.45 mm	€1,175.50
G	28B21	40 mm to 108 mm	298.238 mm	325.86 mm	159.995 mm	64 mm	44.45 mm	€1,005.80
C	28B19	40 mm to 108 mm	270.057 mm	297.68 mm	159.995 mm	64 mm	44.45 mm	€941.02
H	28B16	40 mm to 108 mm	227.843 mm	255.466 mm	159.995 mm	64 mm	44.45 mm	€882.37
I	28B25	40 mm to 108 mm	354.655 mm	382.277 mm	159.995 mm	64 mm	44.45 mm	€1,119.78
C	28B22	40 mm to 108 mm	312.336 mm	339.958 mm	159.995 mm	64 mm	44.45 mm	€1,030.85
C	28B32	40 mm to 126 mm	453.492 mm	481.115 mm	179.984 mm	76 mm	44.45 mm	€1,229.85

MARTIN SPROCKET -

Bushed QD Type Roller Chain Sprockets, Hardened Teeth, 140 Chain Number

Style	Model	Pitch Dia.	Outside Dia.	Bore Dia.	Hub Dia.	Length Through Bore	Bushing Type	For Chain Number	For Chain Pitch	Price
A	140SF12H	6.762"	7.581"	-	4 3/4"	2 1/16"	Type SF QD	140	1 3/4"	€555.21
A	140SF11H	6.2116"	7.01"	-	4.493"	2 1/16"	Type SF QD	140	1 3/4"	€468.50
B	140SF13H	7 5/16"	8.15"	0.5" to 2.938"	4 3/4"	1 1/4"	QD SF	140	1 3/4"	€584.97
A	140E14H	7.864"	8.717"	-	6 1/4"	2 5/8"	Type E QD	140	1 3/4"	€522.45
A	140E15H	8.417"	9.283"	-	6 1/4"	2 5/8"	Type E QD	140	1 3/4"	€551.98
B	140E16H	8.9702"	9.848"	0.875" to 3.313"	6.26"	1 5/8"	QD E	140	1 3/4"	€588.69
B	140E17H	9.5238"	10.412"	0.875" to 3.313"	6 1/4"	1 5/8"	QD E	140	1 3/4"	€653.27
B	140E18H	10.0778"	10.975"	0.875" to 3.313"	6 1/4"	1 5/8"	QD E	140	1 3/4"	€685.28
A	140E19H	10.6322"	11.537"	-	6 1/4"	2 5/8"	Type E QD	140	1 3/4"	€722.91
A	140E21H	11.742"	12.66"	-	6 1/4"	2 5/8"	Type E QD	140	1 3/4"	€822.39
A	140E20H	11.1868"	12.099"	0.875" to 3.313"	6 1/4"	1 5/8"	QD E	140	1 3/4"	€805.17
A	140E22H	12.297"	13.222"	-	6 1/4"	2 5/8"	Type E QD	140	1 3/4"	€774.05
A	140F23H	12.8519"	13.782"	1" to 4"	7"	2 1/2"	QD F	140	1 3/4"	€784.31
A	140F24H	13.4073"	14.343"	1" to 4"	7"	2 1/2"	QD F	140	1 3/4"	€805.11
A	140F25H	13.9628"	14.903"	1" to 4"	7"	2 1/2"	QD F	140	1 3/4"	€828.33
B	140F26H	14.5184"	15.463"	1" to 4"	7"	2 1/2"	QD F	140	1 3/4"	€851.79
B	140F30H	16.7419"	17.7"	1" to 4"	7"	2 1/2"	QD F	140	1 3/4"	€1,001.87

MARTIN SPROCKET -

MST Bushed Type Roller Chain Sprockets, 140 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Keyway Width	Hub Dia.	Length Through Bore	Bushing Type	For Chain Number	Price
A	140Q12H	0.75" to 2.688"	6.7615"	7.581"	1/2"	4 1/8"	1 3/4"	MST Q1	140	€642.43
B	140Q11H	0.75" to 2.688"	6.2116"	7.01"	1/2"	4 1/8"	2 1/2"	Type Q1 Split Taper	140	€540.47
C	140R14H	1 1/8" to 3 3/4"	7.8644"	8.717"	3/4"	5 1/2"	2"	MST R1	140	€593.64
D	140R13H	1 1/8" to 3 3/4"	7.313"	8.15"	3/4"	5 1/2"	2 7/8"	Type R1 Split Taper	140	€660.99
E	140R20H	1 1/8" to 3 3/4"	11.1868"	12.099"	3/4"	5 1/2"	2"	MST R1	140	€818.07
F	140R25H	1 1/8" to 3 3/4"	13.9628"	14.903"	3/4"	5 1/2"	2"	MST R1	140	€1,071.12
A	140R22H	1 1/8" to 3 3/4"	12.2967"	13.222"	3/4"	5 1/2"	2"	MST R1	140	€862.50
G	140R16H	1 1/8" to 3 3/4"	8.9702"	9.848"	3/4"	5 1/2"	2"	MST R1	140	€665.90
H	140R18H	1 1/8" to 3 3/4"	10.078"	10.975"	3/4"	5 1/2"	2 7/8"	Type R1 Split Taper	140	€769.82
I	140R26H	1 1/8" to 3 3/4"	14.5184"	15.463"	3/4"	5 1/2"	2"	MST R1	140	€1,096.59
J	140R23H	1 1/8" to 3 3/4"	12.8519"	13.782"	3/4"	5 1/2"	2"	MST R1	140	€1,026.79
A	140R19H	1 1/8" to 3 3/4"	10.6322"	11.537"	3/4"	5 1/2"	2"	MST R1	140	€811.94
A	140R36	1 3/8" to 3 3/8"	20.079"	21.053"	3/4"	5 1/2"	4"	MST R2	140	€1,458.82
A	140R35	1 3/8" to 3 3/8"	19.5227"	20.494"	3/4"	5 1/2"	4"	MST R2	140	€1,385.40
K	140R40	1 3/8" to 3 3/8"	22.3046"	23.286"	3/4"	5 1/2"	4"	MST R2	140	€1,601.71
L	140R30H	1 3/8" to 3 5/8"	16.742"	17.7"	3/4"	5 1/2"	4"	Type R2 Split Taper	140	€1,163.45
M	140S36	1.688" to 4.25"	20.079"	21.053"	3/4"	6 1/2"	3 5/16"	MST S1	140	€1,458.82
N	140S45	1.688" to 4.25"	25.0873"	26.076"	3/4"	6 1/2"	3 5/16"	MST S1	140	€1,708.38
O	140S40	1.688" to 4.25"	22.3046"	23.286"	3/4"	6 1/2"	3 5/16"	MST S1	140	€1,601.71
P	140S54	1.875" to 4.188"	30.0973"	31.096"	3/4"	6 1/2"	5 11/16"	MST S2	140	€2,201.87
Q	140S48	1.875" to 4.188"	26.7571"	27 3/4"	3/4"	6 1/2"	5 11/16"	MST S2	140	€1,776.36
R	140S70	1.875" to 4.188"	39.0061"	40.017"	3/4"	6 1/2"	5 11/16"	MST S2	140	€3,568.09
S	140S60	1.875" to 4.188"	33.4378"	34.442"	3/4"	6 1/2"	5 11/16"	MST S2	140	€2,308.54
K	140S80	1.875" to 4.188"	44.5748"	45.59"	3/4"	6 1/2"	5 11/16"	MST S2	140	€4,398.60

MARTIN SPROCKET -

Triplex Stock Bore C Type Metric Roller Chain Sprockets, 12B-3 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	E12C68	32 mm to 90 mm	412.485 mm	424.233 mm	129.997 mm	84.988 mm	19.05 mm	€1,729.87
B	E12C57	32 mm to 91 mm	345.812 mm	357.559 mm	129.997 mm	84.988 mm	19.05 mm	€1,413.92
C	E12C80	40 mm to 95 mm	485.229 mm	496.976 mm	140.005 mm	84.988 mm	19.05 mm	€2,173.15
D	E12C95	40 mm to 97 mm	576.166 mm	587.914 mm	138.836 mm	100 mm	19.05 mm	€2,798.03
E	E12C76	40 mm to 98 mm	460.98 mm	472.728 mm	140.005 mm	84.988 mm	19.05 mm	€2,005.05

MARTIN SPROCKET -

Duplex Stock Bore C Type Metric Roller Chain Sprockets, 24B-2 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	D24C48	40 mm to 134 mm	582.541 mm	604.766 mm	189.992 mm	151.994 mm	38.1 mm	€3,860.04
A	D24C40	40 mm to 134 mm	485.603 mm	507.828 mm	189.992 mm	151.994 mm	38.1 mm	€3,040.38
A	D24C42	40 mm to 134 mm	509.835 mm	532.06 mm	189.992 mm	151.994 mm	38.1 mm	€3,135.07
B	D24C54	40 mm to 161 mm	655.26 mm	677.485 mm	238.379 mm	159.004 mm	38.1 mm	€4,832.36
C	D24C57	40 mm to 161 mm	691.624 mm	713.849 mm	238.379 mm	159.004 mm	38.1 mm	€5,318.52
D	D24C72	40 mm to 161 mm	873.465 mm	895.69 mm	238.379 mm	159.004 mm	38.1 mm	€7,746.68

MARTIN SPROCKET -

Simplex Stock Bore C Type Metric Roller Chain Sprockets, 24B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	24C45	40 mm to 104 mm	546.186 mm	568.411 mm	151.994 mm	95 mm	38.1 mm	€1,542.85
B	24C57	40 mm to 126 mm	691.624 mm	713.849 mm	177.8 mm	102 mm	38.1 mm	€1,959.57
C	24C76	40 mm to 133 mm	921.961 mm	944.186 mm	190.983 mm	114 mm	38.1 mm	€3,498.65

MARTIN SPROCKET -

MST Bushed Type Roller Chain Sprockets, 35 Chain Number

Style	Model	Pitch Dia.	Outside Dia.	Length Through Bore	Hub Dia.	Bushing Type	For Chain Number	For Chain Pitch	Bore Dia.	Price
A	35H20	2.397"	2.593"	1 1/4"	2.51"	Type H Split Taper	35	3/8"	3/8" to 1 1/2"	€87.45
B	35H22	2.635"	2.833"	1 1/4"	2.51"	Type H Split Taper	35	3/8"	3/8" to 1 1/2"	€90.80
C	35H23	2.754"	2.953"	7/8"	2.51"	MST H	35	3/8"	3/8" to 1 1/2"	€103.01
D	35H24	2.873"	3.073"	7/8"	-	-	35	3/8"	-	€104.81
E	35H25	2.992"	3.193"	7/8"	2.51"	MST H	35	3/8"	3/8" to 1 1/2"	€109.18
C	35H19	2.2783"	2.472"	7/8"	2.51"	MST H	35	3/8"	3/8" to 1 1/2"	€83.90
C	35H21	2.5161"	2.713"	7/8"	2.51"	MST H	35	3/8"	3/8" to 1 1/2"	€90.81
F	35H28	3.349"	3.553"	1 1/4"	2 1/2"	Type H Split Taper	35	3/8"	3/8" to 1 1/2"	€110.58
G	35H32	3.826"	4.032"	1 1/4"	2 1/2"	Type H Split Taper	35	3/8"	3/8" to 1 1/2"	€117.71
E	35H26	3.1111"	3.313"	7/8"	0.251"	MST H	35	3/8"	3/8" to 1 1/2"	€113.08
H	35H30	3.5875"	3.793"	7/8"	-	-	35	3/8"	-	€111.79
I	35H40	4.78"	4.99"	1 1/4"	2 1/2"	Type H Split Taper	35	3/8"	3/8" to 1 1/2"	€128.27
J	35H35	4.183"	4.392"	1 1/4"	2 1/2"	Type H Split Taper	35	3/8"	3/8" to 1 1/2"	€121.37
E	35H36	4.3026"	4.511"	7/8"	-	-	35	3/8"	-	€127.83
E	35H42	5.0181"	5.229"	1 1/4"	2 1/2"	MST H	35	3/8"	3/8" to 1 1/2"	€130.25
K	35H45	5.376"	5.588"	1 1/4"	2 1/2"	Type H Split Taper	35	3/8"	3/8" to 1 1/2"	€133.70
E	35H48	5.7337"	5.946"	7/8"	-	-	35	3/8"	-	€141.44
L	35H54	6.449"	6.664"	1 1/4"	2.51"	Type H Split Taper	35	3/8"	3/8" to 1 1/2"	€156.32
M	35H60	7.1652"	7.38"	7/8"	-	-	35	3/8"	-	€196.54
E	35H70	8.3584"	8.575"	7/8"	2 1/2"	MST H	35	3/8"	3/8" to 1 1/2"	€213.72
N	35H72	8.5971"	8.814"	7/8"	2 1/2"	MST H	35	3/8"	3/8" to 1 1/2"	€220.29
O	35H80	9.552"	9.769"	1 1/4"	2 1/2"	Type H Split Taper	35	3/8"	3/8" to 1 1/2"	€234.76
E	35H84	10.0291"	10.247"	7/8"	2 1/2"	MST H	35	3/8"	3/8" to 1 1/2"	€239.91
P	35H96	11.4612"	11 17/25"	7/8"	2 1/2"	MST H	35	3/8"	3/8" to 1 1/2"	€274.30
Q	35H112	13.3708"	13.591"	7/8"	2.51"	MST H	35	3/8"	3/8" to 1 1/2"	€313.80

MARTIN SPROCKET -

Simplex Stock Bore B Type Metric Roller Chain Sprockets, 24B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Pitch	Price
A	24B10	20 mm to 56 mm	123.294 mm	145.519 mm	79.883 mm	45 mm	38.1 mm	€422.16
B	24B11	25 mm to 63 mm	135.235 mm	157.46 mm	89.992 mm	50 mm	38.1 mm	€466.80
C	24B12	25 mm to 72 mm	147.207 mm	169.432 mm	102.006 mm	50 mm	38.1 mm	€528.26
C	24B13	25 mm to 80 mm	159.204 mm	181.429 mm	113.995 mm	50 mm	38.1 mm	€506.88
C	24B15	32 mm to 96 mm	183.251 mm	205.476 mm	138.659 mm	60 mm	38.1 mm	€613.46
D	24B16	32 mm to 97 mm	195.294 mm	217.519 mm	140.005 mm	60 mm	38.1 mm	€658.66
C	24B18	32 mm to 98 mm	219.409 mm	241.634 mm	140.005 mm	60 mm	38.1 mm	€744.77
C	24B17	32 mm to 98 mm	207.347 mm	229.572 mm	138.659 mm	60 mm	38.1 mm	€704.41
E	24B20	32 mm to 98 mm	243.552 mm	265.777 mm	140.005 mm	60 mm	38.1 mm	€814.28
F	24B19	32 mm to 98 mm	231.478 mm	253.703 mm	138.354 mm	60 mm	38.1 mm	€782.99
C	24B21	32 mm to 99 mm	255.632 mm	277.857 mm	140.005 mm	60 mm	38.1 mm	€778.38
G	24B25	32 mm to 99 mm	303.99 mm	326.215 mm	140.005 mm	60 mm	38.1 mm	€923.34
C	24B22	32 mm to 99 mm	267.716 mm	289.941 mm	140.005 mm	60 mm	38.1 mm	€823.02
C	24B23	32 mm to 99 mm	279.804 mm	302.029 mm	140.005 mm	60 mm	38.1 mm	€866.45
H	24B9	40 mm to 48 mm	111.397 mm	133.622 mm	68.986 mm	45 mm	38.1 mm	€330.01
I	24B32	40 mm to 104 mm	388.708 mm	410.933 mm	150.012 mm	65 mm	38.1 mm	€1,082.30
I	24B31	40 mm to 104 mm	376.6 mm	398.825 mm	150.012 mm	65 mm	38.1 mm	€1,124.15
I	24B35	40 mm to 104 mm	425.037 mm	447.262 mm	150.012 mm	65 mm	38.1 mm	€1,148.60
I	24B33	40 mm to 104 mm	400.816 mm	423.041 mm	150.012 mm	65 mm	38.1 mm	€1,122.66
I	24B29	40 mm to 104 mm	352.389 mm	374.614 mm	150.012 mm	65 mm	38.1 mm	€1,050.43
J	24B26	40 mm to 105 mm	316.086 mm	338.311 mm	150.012 mm	65 mm	38.1 mm	€941.02
K	24B27	40 mm to 105 mm	328.185 mm	350.41 mm	150.012 mm	65 mm	38.1 mm	€976.72
L	24B36	40 mm to 105 mm	437.148 mm	459.373 mm	151.994 mm	65 mm	38.1 mm	€1,188.65
M	24B30	40 mm to 105 mm	364.494 mm	386.719 mm	150.012 mm	65 mm	38.1 mm	€1,083.17
N	24B28	40 mm to 105 mm	340.287 mm	362.512 mm	150.012 mm	65 mm	38.1 mm	€1,012.12

MARTIN SPROCKET -

Simplex Stock Bore A Type Metric Roller Chain Sprockets, 12B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Length Through Bore	Hub Dia.	Pitch	Bore Type	Price
A	12A19	14 mm	115.739 mm	127.486 mm	35 mm	-	19.05 mm	-	€107.34
A	12A14	14 mm	85.61 mm	97.357 mm	35 mm	-	19.05 mm	-	€93.62
A	12A17	14 mm	103.674 mm	115.421 mm	11.1 mm	80 mm	19.05 mm	-	€100.73
A	12A11	14 mm	67.617 mm	79.365 mm	35 mm	-	19.05 mm	-	€90.71
A	12A13	14 mm	79.602 mm	91.349 mm	35 mm	-	19.05 mm	-	€89.84
A	12A16	14 mm	97.647 mm	109.395 mm	35 mm	-	19.05 mm	-	€97.07
A	12A20	14 mm	121.776 mm	133.524 mm	35 mm	-	19.05 mm	-	€111.00
A	12A15	14 mm	91.625 mm	103.373 mm	11.1 mm	70 mm	19.05 mm	-	€97.15
A	12A18	14 mm	109.705 mm	121.452 mm	35 mm	-	19.05 mm	-	€103.67
A	12A12	14 mm	73.604 mm	85.351 mm	35 mm	-	19.05 mm	-	€92.34
A	12A21	16 mm	127.816 mm	139.564 mm	40 mm	-	19.05 mm	-	€113.93
A	12A23	16 mm	139.902 mm	151.65 mm	11.1 mm	100 mm	19.05 mm	-	€113.67
A	12A22	16 mm	133.858 mm	145.606 mm	40 mm	-	19.05 mm	-	€110.22
B	12A37	19 mm	224.631 mm	236.378 mm	40 mm	-	19.05 mm	-	€168.52
C	12A36	19 mm	218.574 mm	230.322 mm	40 mm	-	19.05 mm	-	€135.60
A	12A24	19 mm	145.948 mm	157.695 mm	40 mm	-	19.05 mm	-	€117.07
D	12A35	19 mm	212.518 mm	224.266 mm	40 mm	-	19.05 mm	-	€153.25
E	12A26	19 mm	158.043 mm	169.791 mm	40 mm	-	19.05 mm	-	€123.26
F	12A34	19 mm	206.463 mm	218.21 mm	40 mm	-	19.05 mm	-	€152.16
G	12A25	19 mm	151.995 mm	163.742 mm	40 mm	-	19.05 mm	-	€119.84
H	12A32	19 mm	194.354 mm	206.101 mm	40 mm	-	19.05 mm	-	€120.12
I	12A27	19 mm	164.093 mm	175.84 mm	40 mm	-	19.05 mm	-	€127.59
J	12A30	19 mm	182.247 mm	193.995 mm	40 mm	-	19.05 mm	-	€130.86
K	12A33	19 mm	200.408 mm	212.156 mm	40 mm	-	19.05 mm	-	€150.03
L	12A28	19 mm	170.143 mm	181.891 mm	40 mm	-	19.05 mm	-	€121.80

MARTIN SPROCKET -

Simplex Taper Bushed Metric Roller Chain Sprockets, 24B-1 Chain Number

Style	Model	Bore Dia.	Pitch Dia.	Outside Dia.	Hub Dia.	Length Through Bore	Bushing Type	Pitch	Price
A	24BTB12H	50.8 mm	147.21 mm	169.43 mm	91 mm	31.75 mm	2012 Taper	38.1 mm	€632.14
B	24BTB15H	63.5 mm	183.25 mm	205.48 mm	108 mm	44.45 mm	2517 Taper	38.1 mm	€804.55
C	24BTB14H	63.5 mm	171.22 mm	193.44 mm	108 mm	44.45 mm	2517 Taper	38.1 mm	€778.34
D	24BTB13H	63.5 mm	159.2 mm	181.43 mm	108 mm	44.45 mm	2517 Taper	38.1 mm	€715.70
D	24BTB23H	76.2 mm	279.8 mm	302.03 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€930.70
E	24CTB38	76.2 mm	461.37 mm	483.6 mm	140 mm	76.2 mm	3030 Taper	38.1 mm	€1,479.33
F	24BTB26H	76.2 mm	316.09 mm	338.31 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€1,085.10
D	24BTB29H	76.2 mm	352.39 mm	374.61 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€1,156.15
E	24CTB42	76.2 mm	509.83 mm	532.06 mm	140 mm	76.2 mm	3030 Taper	38.1 mm	€1,664.46
G	24BTB25H	76.2 mm	303.99 mm	326.21 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€1,018.06
H	24BTB32	76.2 mm	388.71 mm	410.93 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€1,294.02
I	24BTB24H	76.2 mm	291.9 mm	314.12 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€950.47
J	24CTB40	76.2 mm	485.6 mm	507.83 mm	140 mm	76.2 mm	3030 Taper	38.1 mm	€1,571.91
K	24BTB18H	76.2 mm	219.41 mm	241.63 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€769.64
L	24CTB45	76.2 mm	546.19 mm	568.41 mm	140 mm	76.2 mm	3030 Taper	38.1 mm	€1,813.32
M	24BTB28H	76.2 mm	340.29 mm	362.51 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€1,109.86
N	24BTB21H	76.2 mm	255.63 mm	277.86 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€890.77
O	24BTB20H	76.2 mm	243.55 mm	265.78 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€852.09
P	24BTB19H	76.2 mm	231.48 mm	253.7 mm	132 mm	50.8 mm	3020 Taper	38.1 mm	€817.41
Q	24BTB17H	76.2 mm	207.35 mm	229.57 mm	132 mm	50.8 mm	3020 Taper	38.1 mm	€808.49
R	24BTB16H	76.2 mm	195.29 mm	217.52 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€827.02
D	24BTB27H	76.2 mm	328.19 mm	350.41 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€1,063.57
S	24BTB30H	76.2 mm	364.49 mm	386.72 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€1,201.45
T	24BTB22H	76.2 mm	267.72 mm	289.94 mm	133 mm	50.8 mm	3020 Taper	38.1 mm	€910.74
U	24CTB76	88.9 mm	921.96 mm	944.19 mm	165 mm	88.9 mm	3535 Taper	38.1 mm	€3,238.81

12...104 105

Popular Search Queries

Keyed Shaft

Strictly Necessary Cookies

Advertising

Recommendations

Functionality

Analytics

Categories

Brands

Sprockets

Type A Sprockets, 120 Chain

Duplex Stock Bore B Type Metric Roller Chain Sprockets, 24B-2 Chain Number

Duplex Stock Bore B Type Metric Roller Chain Sprockets, 32B-2 Chain Number

Simplex Stock Bore A Type Metric Roller Chain Sprockets, 32B-1 Chain Number

Simplex Stock Bore B Type Metric Roller Chain Sprockets, 32B-1 Chain Number

Simplex Taper Bushed Metric Roller Chain Sprockets, 32B-1 Chain Number

Simplex Stock Bore C Type Metric Roller Chain Sprockets, 32B-1 Chain Number

Duplex Stock Bore C Type Metric Roller Chain Sprockets, 28B-2 Chain Number

Duplex Stock Bore B Type Metric Roller Chain Sprockets, 28B-2 Chain Number

Simplex Stock Bore C Type Metric Roller Chain Sprockets, 28B-1 Chain Number

Simplex Stock Bore A Type Metric Roller Chain Sprockets, 28B-1 Chain Number

Simplex Stock Bore B Type Metric Roller Chain Sprockets, 28B-1 Chain Number

Bushed QD Type Roller Chain Sprockets, Hardened Teeth, 140 Chain Number

MST Bushed Type Roller Chain Sprockets, 140 Chain Number

Triplex Stock Bore C Type Metric Roller Chain Sprockets, 12B-3 Chain Number

Duplex Stock Bore C Type Metric Roller Chain Sprockets, 24B-2 Chain Number

Simplex Stock Bore C Type Metric Roller Chain Sprockets, 24B-1 Chain Number

MST Bushed Type Roller Chain Sprockets, 35 Chain Number

Simplex Stock Bore B Type Metric Roller Chain Sprockets, 24B-1 Chain Number

Simplex Stock Bore A Type Metric Roller Chain Sprockets, 12B-1 Chain Number

Simplex Taper Bushed Metric Roller Chain Sprockets, 24B-1 Chain Number

Popular Search Queries

Explore More

Select your cookie preferences

Strictly Necessary Cookies

Advertising

Recommendations

Functionality

Analytics

Categories

Brands

Sprockets

Popular Search Queries

Explore More
