LEESON 119228.00 C6C34WK25D General Purpose Farm Duty Motor, 1 HP, 1 Phase, 60 Hz, 115/230V, 3600 RPM
Get it by Wednesday, May 20
€724.98 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | General Purpose Motor |
| Ambient Temp. | 40°C |
| Amps | 12/6A |
| Code | J |
| Design | J, L |
| Design Code | L |
| Drive End Bearing Size | 6205 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 70% |
| Electrical Type | Capacitor Start, Induction Run |
| Enclosure Type | Tefc |
| Frame | 56CZ |
| Frame Length | 6 1/2" |
| Frame Material | Rolled Steel |
| Frame Type | 56CZ |
| Frequency | 60 Hz |
| Full Load Amps | 12/6.2-6A |
| Grease Type | Polyrex EM |
| Height | 10 22/25" |
| Hp | 1 hp |
| Insulation Class | Class F |
| Ip Code | IP43 |
| Kva Code | J |
| Kw | 0.75 kW |
| Length | 14 11/25" |
| Lubrication | Polyrex EM |
| Max. Rpm | 3450 RPM |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Type | Rigid Base |
| Motor Orientation | Horizontal |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Type | Capacitor Start |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 3600 RPM |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Opp. Drive End Bearing Size | 6203 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 0.75 kW |
| Packaging | B |
| Phase | 1 |
| Power | 0.75 kW |
| Power Factor | 76 |
| Product Datasheet | leeson-119228-00.pdf |
| Resistance Main | 1.92 ohms |
| Rpm | 3400-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2.19" |
| Shaft Type | Single Special Extension |
| Starting Method | Across The Line |
| Thermal Protection | No Protection |
| Type | CF |
| Voltage | 115/208-230V |
| Width | 10 11/25" |
Shipping Info:
| Ship weight (kg) | 13.5 |
| Ship height (cm) | 27.64 |
| Ship length (cm) | 36.68 |
| Ship width (cm) | 26.52 |
| Country of Origin | US |
Product Details:
- Eff 100%: 70
- Bearing OPE: 6203
- CC Number: EXEMPT
- Bearing PE: 6205
- Nameplate: 080279
- Winding: C632211
- GROUP: 3
- Paint: GRAY - LIGHT (EPOXY)
- S. F Amps: 13.6 / 7-6.8
Documentation:
Product Variants
| Product | Model | Voltage | Hp | Frame | Phase | Nameplate Rpm | Motor Shaft Design | Motor Mounting Type | Motor Thermal Protection | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KHC39QN9575T | 115/208-230V AC | 1/4 hp | 48 | 1 | 1725 RPM | Flat | Cradle Base | Auto | €273.49 | |
 |
5KH49MN6057S | 115V AC | 1/4 hp | 56 | 1 | 1140 RPM | Keyed | Cradle Base | Auto | €508.80 | |
 |
5KH33JNA500S | 115V AC | 1/3 hp | 48Z | 1 | 1725 RPM | Flat | Cradle Base | Automatic | €266.17 | |
 |
5KH42JN0328S | 115/208-230V AC | 1/2 hp | 56 | 1 | 1725 RPM | Keyed | Cradle Base | Auto | €457.32 | |
 |
5KCP36NNB059S | 115/230V AC | 1/2 hp | 48Z | 1 | 1075 RPM | Flat | Cradle Base | Auto | €280.72 | |
 |
5KCP49UN9837S | 208-230V AC | 1/2 hp | 56Y | 1 | 850 RPM | Keyed | Face | Automatic | €433.09 | |
 |
5KCR49SN0493S | 115/208-230V AC | 1 hp | 56 | 1 | 1725 RPM | Keyed | Cradle Base | Automatic | €543.50 |
