LEESON E119362.00 C6K17DR44A General Purpose Motor, 0.75 HP, 1 Phase, 60 Hz, 115/230V, 1800 RPM
Get it by Monday, May 18
€206.92 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Amps | 3.3/6.6A |
| Application Type | Fan And Blower Motors, General Purpose HVAC Motors |
| Assembly/box Mounting | F1 Only |
| Code | L |
| Design Code | No |
| Drive End Bearing Size | 6203 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 81.8% |
| Electrical Type | Capacitor Start, Capacitor Run |
| Enclosure Type | ODP |
| Frame | 56 |
| Frame Length | 7 11/25" |
| Frame Material | Rolled Steel |
| Frame Size | 56 |
| Frequency | 60 Hz |
| Full Load Amps | 6.6/3.3A |
| Height | 10.63" |
| Hp | 3/4 hp |
| Insulation Class | Class B |
| Ip Code | IP22 |
| Kva Code | L |
| Kw | 0.56 kW |
| Length | 15.63" |
| Material | Rolled Steel |
| Motor Orientation | Horizontal |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Type | KD |
| Mounting Type | Resilient Base |
| Nema Design | L, N |
| Nema Rating | NEMA 56 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Opp. Drive End Bearing Size | 6203 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 0.56 kW |
| Overall Length | 13.21" |
| Packaging | F |
| Phase | 1 |
| Power Factor | 97.2 |
| Resistance Main | 1.9 ohms |
| Rotation Type | Selective CCW |
| Rpm | 1725 RPM |
| Service Factor | 1.25 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 22/25" |
| Special Features | Capacitor Start Motors |
| Starting Method | Across The Line |
| Thermal Protection | No Protection |
| Torque Rating | 48 lbs.-ft. |
| Variable Torque Speed Range | 10 |
| Voltage | 115/230V AC |
| Voltage Rating | 115/230V AC |
Shipping Info:
| Ship weight (kg) | 18 |
| Ship height (cm) | 27 |
| Ship length (cm) | 39.7 |
| Ship width (cm) | 19.38 |
| Country of Origin | MX |
Product Details:
- Supersedes Leeson - 100016.00
- Eff 100%: 81.8
- Bearing OPE: 6203
- CC Number: EXEMPT
- Bearing PE: 6203
- Nameplate: 10000417-001-001
- Winding: SS0053728
- GROUP: 3
- Paint: BLUE - LEESON (ENAMEL)
- S. F Amps: 8.0 / 4.0
Product Variants
| Product | Model | Voltage | Phase | Hp | Frequency | Full Load Amps | Mounting Type | Motor Type | Service Factor | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
E100025.00 | 115/230V AC | 1 | 1/2 hp | 60 Hz | 4.6/2.3A | Round, C Face Footless | Capacitor Start/Run | 1.25 | €802.83 | |
 |
E100116.00 | 115/230V AC | 1 | 33/100 hp | 60 Hz | 3.8/1.9A | Rigid Base | Capacitor Start/Run | 1.35 | €602.01 | |
 |
E100336.00 | 115/230V AC | 1 | 33/100 hp | 60 Hz | 3/1.5A | Rigid Base | Capacitor Start/Run | 1.35 | €89.10 | |
 |
E100337.00 | 115/230V AC | 1 | 1/2 hp | 60 Hz | 4.4/2.2A | Rigid Base | Capacitor Start/Run | 1.25 | €84.02 | |
 |
E100338.00 | 115/230V AC | 1 | 1/2 hp | 60 Hz | 4.6/2.3A | Rigid Base | Capacitor Start/Run | 1.25 | €541.17 | |
 |
E113700.00 | 115/230V AC | 1 | 1 1/2 hp | 60 Hz | 13/6.5A | C Face Footed Rigid Base | Capacitor Start/Run | 1.15 | €1,350.97 | |
 |
E114192.00 | 230/460V AC | 3 | 1 hp | 50/60 Hz | 3.2/1.6A | Resilient Base | TD | 1.25 | €853.80 |
