LEESON 145TTTN16630 E652A / 145TTTN16630AA Severe Duty Motor, 1.50 HP, 3 Phase, 60 Hz, 460V, 1800 RPM
Get it by Wednesday, Dec 24
10.00% off
€824.89 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Severe Duty Motor |
| Base Type | Rigid Base |
| Bearing Type | Ball |
| Cc Number | CC003A |
| Duty Cycle | Continuous |
| Enclosure Type | Totally Enclosed Non Ventilated |
| Frame | 145T |
| Frame Material | Cast Iron |
| Frequency | 60 Hz |
| Full Load Amps | 2.3A |
| Hazardous Location Class | 1 A, B, C, D |
| Hazardous Location Division | DIVISION 2 |
| Hp | 1 1/2 hp |
| Insulation Class | Class F |
| Inverter Rated | Yes |
| Length Less Shaft | 8 7/8" |
| Manufacturers Warranty Length | 1 yr. |
| Max. Ambient Temp. | 40°C |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Frame Material | Cast Iron |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Nameplate Rpm | 1755 RPM |
| Nominal Efficiency | 86.5% |
| Number | CC003A |
| Number Of Speeds | 1 |
| Overall Length | 11 7/16" |
| Phase | 3 |
| Rpm Group | 1701-1800 RPM |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 7/8" |
| Shaft Length | 2 9/16" |
| Standards | Ce, Csa, Ul Recognized |
| Usable @ 208v | No |
| Voltage | 460V AC |
| Warranty | 1 yr. |
| Weight | 65 lbs. |
Shipping Info:
| Ship weight (kg) | 29.25 |
| Ship height (cm) | 23.83 |
| Ship length (cm) | 40.18 |
| Ship width (cm) | 31.9 |
| Country of Origin | MX |
Product Details:
- Supersedes Marathon - E652 / 145TTTN6526
Product Variants
| Product | Model | Voltage | Hp | Frame | Motor Design | Nameplate Rpm | Shaft Length | Full Load Amps | Overall Length | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
143TTTN6563 | 230/460V AC | 1 hp | 143T | 3 Phase | 1735 RPM | 2 9/16" | 3/1.5A | 10 7/16" | €818.60 | |
 |
145TTTN16629 | 460V AC | 2 hp | 145T | 3 Phase | 1740 RPM | 2 9/16" | 3A | 11 7/16" | €1,166.04 | |
 |
145TTTN16628 | 230/460V AC | 2 hp | 145T | 3 Phase | - | 2 1/4" | 3/6A | - | €928.49 |
