BUSSMANN BMM603-2C Fuse Block, Fits Midget Fuse Type, 2 Poles, 0 to 30 A, 600 VAC/DC
Item: CQ8BUEModel: BMM603-2CCross Ref: 49ZU08
7 In Stock
Ships within 2 days via
10.00% off
€67.22 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Fuse Block |
| Amp Range | 0-30A |
| Body Material | Thermoplastic |
| Compatible Fuse Series | BMM603 Series |
| Connector Type | Box Lug |
| Diameter | 13/32" |
| Features | Optional Cover And Indication |
| Fits Fuse Type | Midget |
| For Fuse Size | 1 1/2" x 13/32" Dia. |
| Fuse Block Design | Open |
| Fuse Block Style | Non Rejection |
| Fuse Current | 0-30A |
| Fuse Overall Diameter | 13/32" |
| Fuse Overall Length | 3" |
| Fuse Ul Class | Midget |
| Height | 1.3" |
| Housing Material | Thermoplastic |
| Length | 3" |
| Material | Thermoplastic |
| Mounting Style | Bolt-Down, Din Rail |
| Mounting Type | Bolt Down, DIN Rail |
| Number Of Poles | 2 |
| Standards | Ce, Csa Certified, Ul Listed |
| Visual Indication | Non Indicating |
| Voltage | 600V AC/DC |
| Voltage Rating | 600V AC/DC |
| Width | 1 3/5" |
| Wire Range | 2 AWG to 14 AWG |
Shipping Info:
| Ship height (cm) | 3.3 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 4.06 |
| Country of Origin | MX |
Product Variants
| Product | Model | Number Of Poles | Fuse Block Style | Voltage Rating | Voltage | Wire Range | Fuse Ul Class | Amp Range | Mounting Style | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
BMM603-1PQ | 1 | Nonrejection | 600V AC/300V DC | 600V AC/300V DC | 18 AWG to 10 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | €23.07 | |
|
BMM603-1SQ | 1 | Nonrejection | 600V AC/300V DC | 600V AC/300V DC | 18 AWG to 10 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | €17.30 | |
|
BMM603-3SQ | 3 | Nonrejection | 600V AC/300V DC | 600V AC/300V DC | 18 AWG to 10 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | €63.80 | |
|
BMM603-3PQ | 3 | Nonrejection | 600V AC/300V DC | 600V AC/300V DC | 18 AWG to 10 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | €50.16 | |
 |
BMM603-1C | 1 | Non Rejection | 600V AC/DC | 600V AC/DC | 14 AWG to 2 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | €37.86 | |
|
BMM603-2SQ | 2 | Non Rejection | - | 600V AC/DC | 18 AWG to 10 AWG | Midget | 0-30A | - | 1 | €30.29 | |
 |
BMM603-3C | 3 | Non Rejection | 600V AC/DC | 600V AC/DC | 14 AWG to 2 AWG | Midget | 0-30A | Bolt-Down, Din Rail | 1 | €126.79 |
