WEG Tefc Foot Mount, Iec Tru Metric Three Phase General Purpose Motors
Filter
A
B
C
D
E
F
G
H
I
J
K
L
M| Style | Model | Voltage | Frequency | Service Factor | Hp | Full Load Amps | Nameplate Rpm | Frame | Ambient Temp. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 00158ET3EAL90LFF-W22 | 208-230/460/380-415V AC | 60 Hz | 1.25 | - | - | - | 90S/L | -20°C to +40°C | €695.56 | |
| B | .5509EP3EAL90L-W22 | 230/460/380-415V AC | 50 Hz | 1.15 | - | - | - | 90S/L | -20°C to +40°C | €830.38 | |
| C | 00236ET3EAL90L-W22 | 230/460/380-415V AC | 60 Hz | 1.25 | - | - | - | 90S/L | -20°C to +40°C | €901.98 | |
| B | .3718EP3EAL71-W22 | 230/460/380-415V AC | 60 Hz | 1.15 | - | - | - | 71 | -20°C to +40°C | €346.00 | |
| B | .1818EP3EAL63-W22 | 230/460/380-415V AC | 60 Hz | 1.15 | - | - | - | 63 | -20°C to +40°C | €318.55 | |
| B | .1812EP3EAL71-W22 | 230/460/380-415V AC | 50 Hz | 1.15 | - | - | - | 71 | -20°C to +40°C | €403.26 | |
| A | 00218ET3EAL100LFF-W2 | 230/460/380-415V AC | 60 Hz | 1.25 | - | - | - | 100L | -20°C to +40°C | €835.15 | |
| B | .1836EP3EAL63-W22 | 230/460/380-415V AC | 60 Hz | 1.15 | - | - | - | 63 | -20°C to +40°C | €334.07 | |
| B | .2518EP3EAL71-W22 | 230/460/380-415V AC | 50 Hz | 1.15 | - | - | - | 71 | -20°C to +40°C | €336.46 | |
| B | .3709EP3EAL90S-W22 | 230/460/380-415V AC | 50 Hz | - | - | - | - | 90S/L | -20°C to +40°C | €789.82 | |
| D | .3718EP3EAL71FF-W22 | 230/460/380-415V AC | 60 Hz | 1.15 | - | - | - | 71 | -20°C to +40°C | €405.64 | |
| B | .3736EP3EAL71-W22 | 230/460/380-415V AC | 50 Hz | - | - | - | - | 71 | -20°C to +40°C | €368.67 | |
| B | .5512EP3EAL80-W22 | 230/460/380-415V AC | 50 Hz | 1.15 | - | - | - | 80 | -20°C to +40°C | €483.19 | |
| D | .5518EP3EAL80FF-W22 | 230/460/380-415V AC | 60 Hz | 1.15 | - | - | - | 80 | -20°C to +40°C | €456.94 | |
| A | .7518ET3EAL90S/LFF-W | 230/460/380-415V AC | 60 Hz | 1.25 | - | - | - | 90S/L | -20°C to +40°C | €571.49 | |
| D | .5536EP3EAL71FF-W22 | 230/460/380-415V AC | 50 Hz | 1.15 | - | - | - | 71 | -20°C to +40°C | €436.68 | |
| C | 00318ET3EAL100L-W22 | 230/460/380-415V AC | 50 Hz | 1.25 | - | - | - | L100L | -20°C to +40°C | €801.76 | |
| E | 00736ET3EAL132S-W22 | 230/460/380-415V AC | 50 Hz | 1.25 | 10 hp | - | - | 132S | -20°C to +40°C | €1,541.46 | |
| E | 00412ET3EAL132M-W22 | 230/460/380-415V AC | 50 Hz | 1.25 | - | - | - | 132M | -20°C to +40°C | €1,496.12 | |
| E | 00418ET3EAL112M-W22 | 230/460/380-415V AC | 60 Hz | 1.25 | 5 1/2 hp | - | - | 112M | -20°C to +40°C | €810.09 | |
| B | .2536EP3EAL63-W22 | 230/460/380-415V AC | 50 Hz | 1.15 | - | - | - | 63 | -20°C to +40°C | €341.22 | |
| E | 00536ET3EAL132S-W22 | 230/460/380-415V AC | 60 Hz | - | - | - | - | 132S | -20°C to +40°C | €1,364.87 | |
| E | 00718ET3EAL132M-W22 | 230/460/380-415V AC | 50 Hz | 1.25 | - | - | - | 132M | -20°C to +40°C | €1,341.52 | |
| C | 00336ET3EAL100L-W22 | 230/460/380-415V AC | 60 Hz | 1.25 | - | - | - | 100L | -20°C to +40°C | €960.43 | |
| F | 18512ET3Y355M/L-W22 | 380-415/460V | 50 Hz | 1.15 | - | - | - | 355M/L | -20°C to +40°C | €50,263.09 | |
| G | 01112ET3Y160L-W22 | 380-415/460V | 60 Hz | 1 | 15 hp | 18.8A | 1180 RPM | 160L | 40°C | €5,328.38 | |
| F | 22018ET3Y315L-W22 | 380-415/460V | 60 Hz | 1.25 | 300 hp | - | - | 315L | -20°C to +40°C | €41,508.63 | |
| E | 00159ET3YAL112M-W22 | 380-415/460V | 60 Hz | 1.25 | - | - | - | 112M | -20°C to +40°C | €1,194.28 | |
| H | 01136ET3Y160MFF-W22 | 380-415/460V | 50 Hz | 1.25 | - | - | - | 160M | -20°C to +40°C | €2,565.22 | |
| I | 00409ET3Y160M-W22 | 380-415/460V | 50 Hz | 1.25 | 5 1/2 hp | - | - | 160M | -20°C to +40°C | €2,250.79 | |
| H | 01518ET3Y160LFF-W22 | 380-415/460V | 50 Hz | 1.25 | - | - | - | 160L | -20°C to +40°C | €2,583.71 | |
| J | 00736ET3YAL132SFF-W2 | 380-415/460V | 60 Hz | 1.25 | - | - | - | 132S | -20°C to +40°C | €1,635.71 | |
| K | 01118ET3Y160MFF-W22 | 380-415/460V | 60 Hz | 1.25 | - | - | - | 160M | -20°C to +40°C | €2,130.55 | |
| J | 00718ET3YAL132MFF-W2 | 380-415/460V | 50 Hz | 1.25 | - | - | - | 132M | -20°C to +40°C | €1,436.99 | |
| J | 00518ET3YAL132SFF-W2 | 380-415/460V | 60 Hz | 1.25 | - | - | - | 132S | -20°C to +40°C | €1,206.21 | |
| J | 00436ET3YAL112MFF-W2 | 380-415/460V | 60 Hz | 1.25 | 5 1/2 hp | - | - | 112M | -20°C to +40°C | €1,126.26 | |
| L | 00418ET3YAL112MFF-W2 | 380-415/460V | 50 Hz | 1.25 | - | - | - | 112M | -20°C to +40°C | €893.61 | |
| F | 18518ET3Y315S/M-W22 | 380-415/460V | 50 Hz | 1.25 | 250 hp | - | - | 315S/M | -20°C to +40°C | €30,067.81 | |
| J | 00412ET3YAL132MFF-W2 | 380-415/460V | 60 Hz | 1.25 | - | - | - | 132M | -20°C to +40°C | €1,590.37 | |
| M | 22036ET3Y315L-W22 | 380-415/460V | 60 Hz | - | 300 hp | - | - | 315L | -20°C to +40°C | €50,648.00 | |
| G | 00712ET3Y160M-W22 | 380-415/460V | 60 Hz | 1 | 10 hp | 13.8A | 1180 RPM | 160M | 40°C | €3,888.09 | |
| M | 13212ET3Y315S/M-W22 | 380-415/460V | 60 Hz | 1 | - | 214A | - | 315S/M | -20°C to +40°C | €29,374.75 | |
| G | 03736ET3Y200L-W22 | 380-415/460V | 50 Hz | 1 | 50 hp | 59.8A | 3570 RPM | 200L | 40°C | €9,249.47 | |
| F | 18536ET3Y315S/M-W22 | 380-415/460V | 60 Hz | - | 250 hp | - | - | 315S/M | -20°C to +40°C | €30,390.86 | |
| G | 01118ET3Y160M-W22 | 380-415/460V | 60 Hz | 1 | 15 hp | 18.2A | 1775 RPM | 160M | 40°C | €2,908.96 | |
| G | 01136ET3Y160M-W22 | 380-415/460V | 60 Hz | 1 | 15 hp | 17.9A | 3550 RPM | 160M | 40°C | €3,544.04 | |
| G | 01512ET3Y180L-W22 | 380-415/460V | 50 Hz | 1 | 20 hp | 24.7A | 1180 RPM | 180L | 40°C | €6,547.52 | |
| G | 04536ET3Y225S/M-W22 | 380-415/460V | 50 Hz | 1 | 60 hp | 69.9A | 3565 RPM | 225S/M | 40°C | €13,421.09 | |
| G | 01518ET3Y160L-W22 | 380-415/460V | 50 Hz | 1 | 20 hp | 25A | 1775 RPM | 160L | 40°C | €3,570.52 | |
| G | 04518ET3Y225S/M-W22 | 380-415/460V | 60 Hz | 1 | 60 hp | 69.9A | 1780 RPM | 225S/M | 40°C | €12,460.89 | |
| G | 03718ET3Y225S/M-W22 | 380-415/460V | 50 Hz | 1 | 50 hp | 58.5A | 1785 RPM | 225S/M | 40°C | €11,786.35 | |
| M | 05536ET3Y250S/M-W22 | 380-415/460V | 50 Hz | 1 | 75 hp | 80.3A | 3570 RPM | 250S/M | 40°C | €16,602.26 | |
| G | 03036ET3Y200L-W22 | 380-415/460V | 60 Hz | 1 | 40 hp | 47.1A | 3570 RPM | 200L | 40°C | €8,223.19 | |
| G | 03018ET3Y200L-W22 | 380-415/460V | 50 Hz | 1 | 40 hp | 49.4A | 1780 RPM | 200L | 40°C | €7,269.55 | |
| G | 02236ET3Y180M-W22 | 380-415/460V | 50/60 Hz | 1 | 30 hp | 34.7A | 3555 RPM | 180M | -20°C to +40°C | €5,887.88 | |
| G | 02218ET3Y180L-W22 | 380-415/460V | 50/60 Hz | 1 | 30 hp | 36A | 1775 RPM | 180L | 40°C | €5,437.06 | |
| G | 02212ET3Y200L-W22 | 380-415/460V | 50 Hz | 1 | 30 hp | 37.1A | 1180 RPM | 200L | 40°C | €8,301.60 | |
| G | 01836ET3Y160L-W22 | 380-415/460V | 50 Hz | 1 | 25 hp | 29.9A | 3550 RPM | 160L | 40°C | €4,932.41 | |
| G | 01818ET3Y180M-W22 | 380-415/460V | 50 Hz | 1 | 25 hp | 30.6A | 1775 RPM | 180M | 40°C | €4,533.56 | |
| G | 05518ET3Y250S/M-W22 | 380-415/460V | 50 Hz | 1 | 75 hp | 85.1A | 1785 RPM | 250S/M | 40°C | €15,107.11 | |
| G | 05512ET3Y280S/M-W22 | 380-415/460V | 50 Hz | 1 | 75 hp | 90.2A | 1190 RPM | 280S/M | 40°C | €22,967.39 |
