TRITAN SSR24 2RS FM222 Mini Ball Bearing Stainless Steel 38mm SSR24 2RS
Item: AG4ZLWModel: SSR24 2RS FM222Cross Ref: 35JE48
7 In Stock
1 1/2"
Double Sealed
3399 lbf.
Ships within 2 days via
€305.94 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Miniature Ball Bearing |
| Abec Rating | 1 |
| Abec Tolerance Rating | 1 |
| Ball Material | Stainless Steel |
| Bearing Industry Number | R24 |
| Bearing Material | Stainless Steel |
| Bearing Type | Double Sealed |
| Bore Dia. | 1 1/2" |
| Bore Dia. Tolerance | -0.00045" to 0" |
| Bore Tolerance | -0.00045" to 0" |
| Cage Material | Stainless Steel |
| Cage Material Grade | Grade 304 |
| Closure | Double Sealed |
| Closure & Seal Type | Double Sealed, Contact Seal |
| Dynamic Load Capacity | 3780 lbs. |
| Dynamic Radial Load Capacity | 3399 lbf. |
| Flange Type | Non Flanged |
| For Environment | Caustic, Chemical, Food And Beverage, Pharmaceutical, Poultry |
| Included Retaining Ring | No |
| Industry Number | SSR24-2RS |
| Lubricant Material | High Quality Food Grade Grease |
| Lubrication | Grease |
| Max. Axial Load | 3780 lbf. |
| Max. Speed | 11000 RPM , 7700 RPM |
| Max. Temp. | 350°F |
| Min. Temp. | -40°F |
| Miniature Bearing | Yes |
| No. Of Rows | 1 |
| Outer Ring Width | 0.562" |
| Outside Dia. | 2 5/8" |
| Outside Dia. Tolerance | -0.0005" to 0" , -0.001" to +0.001" |
| Resistance Properties | Corrosion Resistant |
| Retaining Ring Groove | No |
| Ring Material | Stainless Steel |
| Seal Material | Rubber |
| Seal Type | Contact |
| Static Load Capacity | 2650 lbs. |
| Static Radial Load Capacity | 2307 lbf. |
| Temp. | -40°F to +350°F |
| Width | 0.562" |
Shipping Info:
| Ship weight (kg) | 0.18 |
| Ship height (cm) | 1.43 |
| Ship length (cm) | 6.67 |
| Ship width (cm) | 6.67 |
| HS code | 8482105052 |
Product Variants
| Model | bore dia. | bearing type | industry number | bore tolerance | outside dia. tolerance | ball material | outer ring width | dynamic radial load capacity | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| SS6001 | 12 mm | Open | SS6001 | -0.008 mm to 0 mm | -0.009 mm to 0 mm | Alloy, Steel | 8 mm | 1080 lbf. | €17.54 | |
| SS6002 | 15 mm | Open | SS6002 | -0.008 mm to 0 mm | -0.01 mm to +0.01 mm | Alloy, Steel | 9 mm | 1080 lbf. | €20.16 | |
| SS6003 | 17 mm | Open | SS6003 | -0.008 mm to 0 mm | -0.01 mm to +0.01 mm | Alloy, Steel | 10 mm | 1690 lbf. | €21.99 | |
| SS6000 ZZ FM222 | 10 mm | Double Shielded Ball | SS6000ZZ | -0.008 mm to 0 mm | -0.009 mm to 0 mm | Alloy, Steel | 8 mm | 1810 lbf. | €13.84 | |
| SS6001 ZZ FM222 | 12 mm | Double Shielded Ball | SS6001ZZ | -0.008 mm to 0 mm | -0.009 mm to 0 mm | Alloy, Steel | 8 mm | 1080 lbf. | €17.58 | |
| SS6002 ZZ FM222 | 15 mm | Double Shielded Ball | SS6002ZZ | -0.008 mm to 0 mm | -0.01 mm to +0.01 mm | - | - | - | €19.73 | |
| SS6003 ZZ FM222 | 17 mm | Double Shielded Ball | SS6003ZZ | -0.008 mm to 0 mm | -0.01 mm to +0.01 mm | Alloy, Steel | 10 mm | 1810 lbf. | €21.99 |
