LEESON 5K49RN6429S K1510 Condenser Fan Motor, 1 HP, 3 Phase, 60 Hz, 575V, 1200 RPM
Get it by Monday, Dec 22
€745.76 /unit
This product can only be shipped in multiples of 10Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | HVAC Motor |
| Ambient (c) | 65°C |
| Ambient Temp. | 65°C |
| Bearing Type | Ball |
| Duty Cycle | Continuous |
| Enclosure Type | Dripproof |
| Frame | 56Z |
| Frequency | 60 Hz |
| Full Load Amps | 1.6A |
| Hp | 1 hp |
| Insulation Class | Class B |
| Max. Ambient Temp. | 65°C |
| Motor Enclosure Design | Dripproof |
| Motor Mounting Position | Vertical Shaft Up |
| Motor Mounting Type | C Face Footless |
| Motor Thermal Protection | Automatic |
| Motor Type | Three Phase |
| Nameplate Rpm | 1140 RPM |
| Number Of Speeds | 1 |
| Phase | 3 |
| Service Factor | 1 |
| Shaft Orientation | Vertical Shaft Up |
| Thermal Protection | Automatic |
| Voltage | 575V AC |
Shipping Info:
| Ship weight (kg) | 14.85 |
| Ship height (cm) | 24.13 |
| Ship length (cm) | 48.74 |
| Ship width (cm) | 27.79 |
| HS code | 8501516040 |
| Country of Origin | MX |
Product Details:
- Starting Type: Squirrel Cage Induction
- KVA Code: J
- Drive End Bearing: BALL
- Opposite End Bearing: BALL
- Drive End Bearing Size: 6203
- Opposite End Bearing Size: 6203
Product Variants
| Product | Model | Voltage | Hp | Motor Enclosure Design | Motor Mounting Type | Max. Ambient Temp. | Frame | Motor Thermal Protection | Nameplate Rpm | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
056T11O5303 | 200-230/460V AC | 1 1/2 hp | Open Air Over | Band, Stud | 70°C | 56Y | Auto | 1140 RPM | €599.97 | |
![]() |
056T11O5302 | 200-230/460V | 1 hp | Open Air Over | Band, Stud | 70°C | 56Y | Automatic | 1140 RPM | €688.79 | |
![]() |
056T8O5307 | 208-230/460V AC | 1 1/2 hp | Open Air Over | Band, Stud | 70°C | 56Y | Automatic | 850 RPM | €1,192.71 | |
![]() |
056T11O5304 | 200-230/460V AC | 2 hp | Open Air Over | Band, Stud | 70°C | 56Y | Automatic | 1140 RPM | €1,064.83 | |
![]() |
056T8O5302 | 200-230/460V AC | 1 hp | Open Air Over | Band, Stud | 70°C | - | Auto | - | €1,100.24 | |
![]() |
056T11O5300 | 200-230/460V AC | 1/2 hp | - | - | - | - | - | - | €767.00 | |
![]() |
5K38SN267S | 200-230/460V AC | 3/4 hp | ODP | C Face, Footless | - | 48Z | - | - | €138.51 |
