LEESON 120004.00 P145K17DB3K Single Phase Motor | AJ2REL P145K17DB3K

LEESON 120004.00 P145K17DB3K Air Compressor Motor, 1.50 HP, 1 Phase, 60 Hz, 115/230V, 1800 RPM

Item: AJ2RELModel: 120004.00Cross Ref: P145K17DB3K
Check Availability
In Stock
Nameplate rpm
HP

Get it by Monday, Aug 17

€915.58 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

Item General Purpose Motor
Ambient Temp. 40°C
Amps 17.2/8.6A
Assembly 42505
Code J
Design J, L
Design Code L
Drive End Bearing Size 6205
Drive End Bearing Type Ball
Duty Cycle Continuous
Efficiency 79%
Electrical Type Capacitor Start, Capacitor Run
Enclosure Type ODP
Frame G145T
Frame Length 7"
Frame Material Rolled Steel
Frame Type 145T
Frequency 60 Hz
Full Load Amps 17.2/8.6A
Grease Type Polyrex EM
Height 10 22/25"
Hp 1 1/2 hp
Insulation Class Class B
Ip Code IP22
Kva Code J
Kw 1.1 kW
Length 14 11/25"
Lubrication Polyrex EM
Max. Speed 1740 RPM
Motor Enclosure Design Dripproof
Motor Mounting Type Rigid Base
Motor Orientation Horizontal
Motor Shaft Rotation Selective Counter Clockwise
Motor Type Capacitor Start
Mounting Type Rigid Base
Nameplate Speed 1800 RPM
No. Of Poles 4
No. Of Speeds 1
Opp Drive End Bearing Size 6203
Opp. Drive End Bearing Type Ball
Output Kw 1.12 kW
Packaging B
Phase 1
Power 1.12 kW
Power Factor 73
Product Datasheet leeson-120004-00.pdf
Resistance Main 1.32 ohms
Service Factor 1.15
Shaft Dia. 7/8"
Shaft Length 2 1/4"
Shaft Type T
Speed 1700-1800 RPM
Starting Method Across The Line
Thermal Protection Manual
Type KD
Voltage 115/208-230V
Width 10 11/25"

Shipping Info:

Ship weight (kg) 19.35
Ship height (cm)27.64
Ship length (cm)36.68
Ship width (cm)26.52
Country of OriginUS

Product Details:

    • Eff 100%: 79
    • Bearing OPE: 6203
    • CC Number: EXEMPT
    • Bearing PE: 6205
    • Nameplate: 004004
    • Winding: K634119
    • GROUP: 3
    • Paint: VERIFY
    • S. F Amps: 19 / 9.5

Documentation:

Datasheet
