LEESON 048A17O124 48A17O124E / X476 Fan and Blower Motor, 0.25 HP, 1 Phase, 60 Hz, 230V, 1800 RPM
Item: AJ2KYJModel: 048A17O124Cross Ref: 48A17O124E / X476
7 In Stock
Ships within 2 days via
€299.62 /unit
This product can only be shipped in multiples of 100Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | HVAC Motor |
| Ambient (c) | 40°C |
| Ambient Temp. | 40°C |
| Assembly | F1 Only |
| Conduit Box Position | F1 Only |
| Duty Cycle | Continuous |
| Efficiency | N/A % |
| Efficiency | Not Applicable |
| Enclosure Type | Open Air Over |
| Frame | 48Y |
| Frequency | 60 Hz |
| Full Load Amps | 1.8A |
| Hp | 1/4 hp |
| Insulation Class | Class B |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Open Air Over |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Resillient Ring |
| Motor Service Factor | 1 |
| Motor Shaft Rotation | Selective CCW |
| Motor Thermal Protection | Automatic |
| Motor Type | Permanent Split Capacitor |
| Mounting Type | Resilient Rings |
| Nameplate Rpm | 1625 RPM |
| Nema Design | No Design Code |
| Number Of Speeds | 1 |
| Phase | 1 |
| Power | 0.19 kW |
| Rpm | 1625 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1/2" |
| Shaft Length | 4.06" |
| Shaft Orientation | Horizontal |
| Thermal Protection | Automatic |
| Voltage | 230V AC |
Shipping Info:
| Ship weight (kg) | 4.5 |
| Ship height (cm) | 16.81 |
| Ship length (cm) | 28.09 |
| Ship width (cm) | 17.15 |
| HS code | 8501404040 |
| Country of Origin | MX |
Product Details:
- Starting Type: PSC 1 SPEED
- KVA Code: B
- Drive End Bearing: BALL
- IP Code: 10
- Opposite End Bearing: BALL
- Drive End Bearing Size: 6203
- Opposite End Bearing Size: 6203
Product Variants
| Product | Model | Hp | Full Load Amps | Motor Type | Service Factor | Voltage | Nameplate Rpm | Frame | Motor Shaft Rotation | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048S17D997 | 1/3 hp | 6.6A | Split Phase | 1 | 115V AC | - | 48 | Selective Counter Clockwise | €247.56 | |
 |
A009644.00 | 1 hp | 5.2A | PN | 1.1 | - | - | 56CZ | Fixed Counter Clockwise | €787.64 | |
 |
A099250.00 | 1/2 hp | 6/3A | Permanent Split Capacitor | 1.15 | 115/230V AC | 825 RPM | 48YZ | Selective Counter Clockwise | €777.05 | |
 |
M900195.00 | 1/4 hp | 5A | Split Phase | 1.35 | 115V | 1800 RPM | 48Z | Selective Counter Clockwise | €250.90 | |
 |
191868.00 | - | - | - | - | - | - | - | - | €678.57 | |
 |
M090602.00 | - | - | - | - | - | - | - | - | €831.09 | |
 |
048S17D7209 | - | - | - | - | - | - | - | - | €364.23 |
