GROVE GEAR GR8424075.00 GR-DXMQ842-200-L1-140 Helical Reducer, 200:1 Ratio, 1.875 Inch Output Diameter, Cast Iron
Get it by Wednesday, Aug 26
€2,986.37 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Reducer |
| A | 6.13 |
| Aj | 5.88 |
| B | 10.25 |
| Be | 0.38" |
| Bf | 0.41 |
| C | 11.38" |
| Ce | 2.87 |
| Center Distance | 4 1/4" |
| D | 4.44 |
| Frame | 140TC |
| Gear Type | Helical, Worm |
| Housing Construction | Cast Iron |
| Housing Material | Cast Iron |
| I | 6.1" |
| Input Hp | 2.099 hp |
| Input Quill Dia. | 7/8" |
| Input Speed | 1750 RPM |
| Input Style | C Face Quill |
| J | 8 1/2" |
| K | 4 1/4" |
| Key Way Size | 3/16" x 3/32" |
| Max. Input Hp | 2.099 hp |
| Mounting Type | Base |
| N | 8.12 |
| No. Of Gear Reductions | 2 |
| O | 4 1/2" |
| Output Dia. | 1 22/25" |
| Output Hp | 1.449 hp |
| Output Key Size | 1/2" x 3" |
| Output Shaft | Shaft |
| Output Shaft Assembly Code | DXMQ-L |
| Output Shaft Orientation | L2 |
| Output Speed | 8.5 RPM |
| Output Style | Solid Shaft |
| Output Torque | 10775 lbs.-in. |
| Product Line | GR Series - Ironman Worm Gear Reducers |
| Reducer | Worm - Right Angle |
| Reducer Style | L2 |
| Series | GR Series |
| Series Style | GR-DXMQ |
| Series Type | Cast Iron 800 Worm Gear Reducers |
| T | 1.875 |
| Tap Depth | 1" |
| Tap Size | 5/8"-11 |
| Thread Type | Coarse |
Shipping Info:
| Ship weight (kg) | 85.95 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
Product Variants
| Product | Model | Output Torque | Output Speed | Output Dia. | Input Dia. | Output Hp | Max. Input Hp | Gear Type | Output Shaft | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
GR8420315.00 | 5042 lbs.-in. | 175 RPM | 1 7/8" | 1 1/8" | 14 hp | 14 93/100 hp | Worm | Solid Shaft | €4,104.01 | |
 |
GR8420541.23 | 6092 lbs.-in. | 87 RPM | 1.438" | 1 1/4" | 8.458 hp | 9.462 hp | Worm | Hollow Bore | €5,089.13 | |
|
GR8424034.00 | - | - | - | - | - | - | - | - | €4,193.11 | RFQ
|
|
GR8425888.00 | - | - | - | - | - | - | - | - | €2,412.37 | RFQ
|
 |
GR8420605.23 | 6170 lbs.-in. | 35 RPM | 1.438" | 1 1/8" | 3.426 hp | 4.389 hp | Worm | Hollow Bore | €5,089.13 | |
|
GR8420181.00 | 3209 lbs.-in. | 350 RPM | 1 7/8" | 1 1/4" | - | - | Worm | Solid Shaft | €2,216.39 | |
|
GR8424151.00 | - | - | - | - | - | - | - | - | €4,193.11 | RFQ
|
