GRAINGER 06Q103N04038 Mini Ball Valve, 3/8 Inch Pipe, 3/8 Inch Tube, Reduced, 1000 PSI, 32 Deg to 320 Deg. F | CQ2LPP 796AE7

GRAINGER 06Q103N04038 Mini Ball Valve, 3/8 Inch Pipe, 3/8 Inch Tube, Reduced, 1000 PSI, 32 Deg to 320 Deg. F

Item: CQ2LPPModel: 06Q103N04038Cross Ref: 796AE7
7 In Stock

Ships within 2 days via

€28.27
10.00% off
€25.44 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

Item Mini Ball Valve
3-a Compliance Not Rated
Ball Material Stainless Steel
Ball Material Grade Grade 316
Ball Port Style Standard Port
Body Material Stainless Steel
Body Seal Material PTFE
Body Style Two Way
Connection Gender - Side 1 Male
Connection Gender - Side 2 Female
Connection Size - Side 1 3/8"
Connection Size - Side 2 3/8"
Connection Type FNPT x MNPT
Connection Type - Side 1 NPT
Connection Type - Side 2 NPT
Features Inspection: Api598, Lost Wax Precision Casting, Sanitary Design
For Media Combustible Gases, Water
Handle Locking Lever
Handle - Locking Locking
Handle Color Yellow
Handle Height 1.04"
Handle Length 0.83"
Handle Material Stainless Steel
Handle Material Grade Grade 303
Handle Type Lever
Hose I.d. 0.286"
Max. Media Temperature 320°F
Max. Pressure 1000 psi
Max. Pressure (combustible Gas) Not Rated
Max. Pressure (cwp) 1000 psi
Max. Steam Pressure 1000 psi
Media Temperature Range 32°F to 320°F
Min. Media Temperature 32°F
Nominal Valve Size 3/8"
Overall Length 1.57"
Pipe Size 3/8"
Port Reduced
Seal Material RPTFE
Seat Material PCTFE, PTFE, RPTFE
Standards Ad2000-Wo
Stem Grade Grade 316
Stem Material Stainless Steel
Stem Type Blowout Resistant
Temp. Range +32°F to +320°F
Tube Size 3/8"
Valve Body Style Straight
Valve Construction One-Piece
Valve Series Q101N04 Series
Valve Structure One Piece
Vented Ball Valve Non Vented

Shipping Info:

Ship weight (kg) 0.37
Ship height (cm)2.54
Ship length (cm)2.54
Ship width (cm)2.54

Product Variants

ProductModelConnection TypeSeat MaterialMax. PressureStem MaterialBody MaterialSeal MaterialHandleOverall LengthPrice
GRAINGER 06Q031B04112 Ball Valve, 1 1/2 Inch Pipe, 1 1/2 Inch Tube, 1000 PSI, 32-320 Deg F, Weld | CQ2LJY 796AC0 06Q031B04112Butt Weld x Butt WeldPCTFE, PTFE, RPTFE1000 psiStainless SteelStainless SteelRPTFELocking Lever4.45"€207.71
GRAINGER 1PYV5 Ball Valve, 1 1/2 Inch Pipe, 1 1/2 Inch Tube, 600 PSI | CQ2LJZ 107-827-CLFNPT x FNPTPTFE600 psi-BrassPTFELocking Lever7.58"€106.04
GRAINGER SSV-150 Ball Valve, 1 1/2 Inch Pipe, 1, 500 PSI CWP, 0-400 Deg F | CQ2LKA 20K959 SSV-150FNPT x FNPTPTFE1500 psiStainless SteelStainless SteelPTFELocking Lever7.19"€346.54
GRAINGER SSV-150NLH Ball Valve, 1 1/2 Inch Pipe, 1, 500 PSI CWP, 0-400 Deg F, Lever Handle | CQ2LKB 20K951 SSV-150NLHFNPT x FNPTPTFE1500 psiStainless SteelStainless SteelPTFELever7.19"€331.21
GRAINGER G-F600-150 Ball Valve, 1 1/2 Inch Pipe, 600 PSI CWP, 0-350 Deg F, Lever Handle, Brass | CQ2LKD 20K914 G-F600-150FNPT x FNPTPTFE600 psiBrassBrassPTFELever8.23"€120.65
GRAINGER G-F600-150LH Ball Valve, 1 1/2 Inch Pipe, 600 PSI CWP, 0-350 Deg F, Locking Lever Handle | CQ2LKE 20K886 G-F600-150LHFNPT x FNPTPTFE600 psiBrassBrassPTFELocking Lever4 4/25"€108.08
GRAINGER 06Q031B04114 Ball Valve, 1 1/4 Inch Pipe, 1 1/4 Inch Tube, 1000 PSI, 32-320 Deg F, Weld | CQ2LKF 796AA9 06Q031B04114Butt Weld x Butt WeldPCTFE, PTFE, RPTFE1000 psiStainless SteelStainless SteelRPTFELocking Lever3.82"€148.49
