BROWNING 730019 FBE920X 1 3/16 Four Bolt Flange Tapered Roller Bearing, Double Collar Mount Lock, Mounted, Cast Iron
Item: BE8MHYModel: 730019Cross Ref: FBE920X 1 3/16
7 In Stock
1 3/16"
Ships within 2 days via
€742.07 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Roller Bearing |
| Bolt Center To Center Length | 2 7/8" |
| Bolt Circle Dia. | 4 1/16" |
| Bolt Spacing | 2 7/8" |
| Bore Dia. | 1 3/16" |
| Dynamic Load Capacity | 2975 lbs. |
| Expansion Type | Non-Expansion |
| Finish | Uncoated |
| Flange Mounting Type | 4 Bolt |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Housing Style | 4 Bolt Square Flange Block |
| Length Through Bore | 2.781" |
| Locking Device | Double Set Screw Collar |
| Material | Cast Iron |
| Max. Speed | 3500 RPM |
| Mounting | Yes |
| Mounting Bolts | 3/8" |
| Mounting Method | Concentric Collar |
| No. Of Mounting Holes | 4 |
| Nominal Bolt Circle Dia | 4.1" |
| Number Of Rows | 2 |
| Other Features | Has Flinger |
| Overall Depth | 2 27/32" |
| Overall Dia. | 3 3/4" |
| Overall Height | 3 3/4" |
| Overall Length | 3 3/4" |
| Pilot Configuration | No Pilot |
| Product Type | Non-Expansion Round/Straight Bore |
| Relubricatable | Yes |
| Rolling Element | Tapered Roller Bearing |
| Seal Material | Rubber |
| Seal Type | Contact |
| Series | FBE920 Series |
| System Of Measurement | Imperial |
| Temp. Range | -20°F to +200°F |
| Temp. Rating | -20°F to +200°F |
| Weight | 2.096 Kg |
Shipping Info:
| Ship weight (kg) | 2.08 |
| Ship height (cm) | 8.89 |
| Ship length (cm) | 13.97 |
| Ship width (cm) | 13.67 |
Product Variants
| Product | Model | Bore Dia. | Overall Height | Overall Length | Max. Speed | Bolt Circle Dia. | Locking Device | Bolt Center To Center Length | Material | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
730032 | 3" | 7 3/4" | 7 3/4" | 1500 RPM | 8 31/64" | Double Set Screw Collar | 6" | Cast Iron | €894.03 | |
 |
730034 | 3 7/16" | 9 1/4" | 9 1/4" | 1000 RPM | 9 29/32" | Double Set Screw Collar | 7" | Cast Iron | €1,380.00 | |
 |
730031 | 2 15/16" | 7 3/4" | 7 3/4" | 1500 RPM | 8 31/64" | Double Set Screw Collar | 6" | Cast Iron | €836.76 | |
 |
730035 | 3 1/2" | 9 1/4" | 9 1/4" | 1000 RPM | 9 29/32" | Double Set Screw Collar | 7" | Cast Iron | €1,640.49 | |
 |
730026 | 2" | 5 5/8" | 5 5/8" | 2000 RPM | 6 3/16" | Double Set Screw Collar | 4 3/8" | Cast Iron | €529.26 | |
 |
730025 | 1 15/16" | 5 5/8" | 5 5/8" | 2000 RPM | 6 3/16" | Double Set Screw Collar | 4 3/8" | Cast Iron | €548.63 | |
 |
730028 | 2 7/16" | 6 7/8" | 6 7/8" | 1750 RPM | 7 39/64" | Double Set Screw Collar | 5 3/8" | Cast Iron | €574.14 |
