Power Meters And Analyzers

Eaton IQ 250 Series meters are used for measuring electrical parameters, such as voltage, power factor, current, frequency and active / reactive / apparent power with a sampling rate of 400 samples per cycle. These units track energy over time to allow users to identify trends, patterns and anomalies in energy consumption. They have built-in communication functionalities like Modbus to enable seamless integration with energy management systems, data loggers or building automation systems. These meters include internal memory or external storage option to log and store energy data for future reference. They have an ultra-compact design that allows easy installation in machine control panels, panelboard & switchboard mains and feeders. Selected models are integrated with a large, bright red, three-line LED display for easily reading data even if the meter is installed at a height or distance.

EATON IQ 260 Series meters provide real-time measurement and display of electrical data, including voltage, current, power factor, energy usage and demand, ensuring accurate monitoring and analysis with a high sampling rate. They offer ANSI C12.20 accuracy for precise power utilisation and quality assessment, along with KYZ test pulse self-certification capabilities to verify meter accuracy. These meters also offer optional data logging for historical data preservation, standard Modbus RTU communications, and the flexibility to integrate into Eaton's Power Xpert Architecture for a comprehensive system-level view. They can be operated at temperatures ranging from -20 to 70 degrees C.
