SPEEDAIRE 22UX44 Air Motor 0.75 Hp 30 Cfm Flange Mounting
Item: AB7FMBModel: 22UX44
7 In Stock
Ships within 2 days via
10.00% off
€426.65 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Air Motor |
| Bearing Protection | Not Applicable |
| Cfm | 30 CFM |
| Color | Gray |
| Finish | Gray |
| Height | 6 3/5" |
| Housing Material | Aluminum, Cast Iron |
| Housing Material Finish | Painted |
| Hp | 93/100 hp |
| Includes | Muffler |
| Inlet Gender | Female |
| Keyway Length | 0.19" |
| Keyway Type | Flat Key |
| Length | 5.87" |
| Length Less Shaft | Not Applicable |
| Material | Aluminum, Cast Iron |
| Max. Air Flow | 30 CFM |
| Max. Air Pressure | 100 psi |
| Motor Design | Not Applicable |
| Motor Frame Material | Cast Iron |
| Mount Hole Center-to-center Length | Not Applicable |
| Mount Hole Center-to-center Width | Not Applicable |
| Mounting | Flange |
| Mounting Orientation | Any Angle |
| Mounting Type | Flange |
| No Load Speed | 3000 RPM |
| Output Power @ 25% Maximum Speed | Not Applicable |
| Output Power @ 50% Max. Speed | Not Applicable |
| Overall Height | 6 3/5" |
| Overall Length | 5 4/5" |
| Overall Width | 6 3/5" |
| Rotation | Reversible |
| Rpm @ Max. Torque | 300 |
| Rpm @ Max. Torque | 300 RPM |
| Shaft Dia. | 5/8" |
| Shaft Length | 2.06" |
| Shaft Material | Steel |
| Shaft Orientation | Inline |
| Starting Torque | Not Applicable |
| System Of Measurement | Inch |
| Temp. | 250°F |
| Type | Rotary Vane |
| Width | 6 3/5" |
Shipping Info:
| Ship weight (kg) | 4.32 |
| Ship height (cm) | 16.76 |
| Ship length (cm) | 14.73 |
| Ship width (cm) | 16.76 |
| HS code | 8412390040 |
| Country of Origin | CN |
Product Variants
| Product | Model | No Load Speed | Shaft Dia. | Shaft Length | Rotation | Housing Material | Torque @ Max Pressure | Max. Air Pressure | Cfm | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
22UX41 | Hub | Clockwise | 1 1/8" | 27 CFM | 9/20 hp | 6000 RPM | Cast Iron | Not Applicable | €294.69 | |
 |
22UX42 | Hub | Clockwise/Counter Clockwise | 1 1/8" | 27 CFM | 9/20 hp | 6000 RPM | Aluminum, Cast Iron | Not Applicable | €268.60 | |
 |
22UX43 | Hub | Counter Clockwise | 1 1/8" | 30 CFM | 93/100 hp | - | Aluminum, Cast Iron | Not Applicable | €364.55 | |
 |
22UX45 | Face | Clockwise/Counter Clockwise | 1 7/8" | 78 CFM | 1 7/10 hp | - | Aluminum, Cast Iron | Square | €415.28 | |
 |
22UX46 | Flange | Clockwise/Counter Clockwise | 2" | 78 CFM | 1 7/10 hp | - | Aluminum, Cast Iron | Square | €364.48 | |
 |
22UX47 | Foot | Clockwise/Counter Clockwise | 1 3/8" | 128 CFM | - | - | Aluminum, Cast Iron | Square | €495.90 | |
 |
22UX48 | Flange | Clockwise/Counter Clockwise | 2" | 128 CFM | - | - | Aluminum, Cast Iron | Square | €510.81 |
