SEALMASTER TR 7YN 1410709000 Female Threaded With Male Stud Right Hand Rod End, Bore Diameter 0.4375 Inch
Get it by Tuesday, Aug 25
€42.23 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Ability To Relubricate | Yes |
| Across Wrench Flats | 5/8" |
| Axial Load | 535 |
| Ball Dia. | 0.812" |
| Ball Finish | Chrome Plated |
| Ball Flat Dia. | 0.586" |
| Ball Material | Alloy, Steel |
| Ball Width | 0.562" |
| Base Dia. | 3/4" |
| Bearing Insert Type | Rod End |
| Bore Dia. | 7/16" |
| Class | Precision |
| Configuration | Female |
| Construction | Three Piece Rod End With Y Stud And Zerk Fitting |
| Head Dia. | 1 1/8" |
| Housing Style | Female Rod End |
| Housing Width | 0.437" |
| Htc | 8483.30.8055 |
| Length To Center Of Ball | 1.81" |
| Lubrication | Zerk Fitting |
| Lubrication Method | Fitting |
| Lubrication Type | Grease |
| Max. Ambient Temp. | 350°F |
| Max. Static Radial Load | 5350 |
| Misalignment Angle B3 | 23.4° |
| Outer Material | Carbon Steel |
| Outer Material Property | Corrosion Resistant Plating |
| Product Selection Available Sw | No |
| Product Type | TR |
| Race Material | Carbon Steel |
| Race Material Property | Corrosion Resistant Plating |
| Series | Precision Series |
| Stud Length To Center Of Ball | 1.93" |
| Stud Length To Hex | 1.13" |
| Stud Thread Length | 1" |
| Thread Direction | RH |
| Thread Length | 1.031" |
| Thread Size | 7/16"-20 |
| Thread Type | UNF |
| Type | Female Rod End |
| Y Stud Material | Carbon Steel |
| Y Stud Material Property | Corrosion Resistant Plating |
| Zerk Fitting Sw | Yes |
Shipping Info:
| Ship weight (kg) | 0.13 |
| Ship height (cm) | 5.61 |
| Ship length (cm) | 6.05 |
| Ship width (cm) | 2.87 |
| Country of Origin | MX |
Product Variants
| Product | Model | Bore Dia. | Ball Dia. | Shank Thread Size | Static Radial Load Capacity | Head Width | Race Material | Type | Grade | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TRL 16N | 1" | 1 7/8" | - | - | - | Carbon Steel | Female Rod End | - | €195.62 | |
 |
TRL 12YN | 3/4" | - | - | - | - | Carbon Steel | - | - | €102.04 | |
 |
TRL 6Y | - | - | #3/8-24 | 4450 lbf. | - | - | - | Grade Precision | €29.62 | |
 |
TR 5 | 5/16" | 5/8" | - | - | - | Carbon Steel | Female Rod End | - | €19.40 | |
 |
TRL 8N | 1/2" | 0.937" | - | - | - | Carbon Steel | Female Rod End | - | €42.93 | |
 |
TR 12N | 3/4" | 1.312" | - | - | - | Carbon Steel | Female Rod End | - | €62.33 | |
 |
TR 4N | 1/4" | 1/2" | - | - | - | Carbon Steel | Female Rod End | - | €22.71 |
