MARTIN SPROCKET 160BTB17H Sprocket, Taper, 160 Chain, 17 Teeth, 10.884 Inch Pitch Dia., 11.899 Inch O.D., Steel
Get it by Wednesday, Jul 15
€828.19 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Roller Chain Sprocket |
| Bore Dia. | 1.188" to 3.5" |
| Bore Type | Bushed |
| Bushing Part Number | 3535 |
| Bushing Type | TB 3535 |
| Chain Number | 160 |
| Chain Pitch | 2" |
| Chain Size | #160 |
| Construction | Welded |
| Construction Type | Welded |
| For Chain Number | 160 |
| For Chain Pitch | 2" |
| Hardened Teeth | 1 |
| Hub Configuration | B |
| Hub Dia. | 6 1/2" |
| Hub Outside Dia. | 6 1/2" |
| Individually Packaged | No |
| Length Through Bore | 3 1/2" |
| Length Thru Bore | 3 1/2" |
| Material | Steel |
| Min. Bore Size | 1 3/16" |
| No. Of Chain Rows | 1 |
| No. Of Teeth | 17 |
| Outside Dia. | 11.899" |
| Pitch | 2" |
| Pitch Dia. | 10.8844" |
| Single Strand Tooth Thickness | 1.156" |
| Storage Dimension Height | 3 1/2" |
| Storage Dimension Length | 11.899" |
| Storage Dimension Width | 11.899" |
| Type | Type B Single Strand Welded Bushed |
Shipping Info:
| Ship weight (kg) | 14.63 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 30.23 |
| Ship width (cm) | 30.23 |
| Country of Origin | US |
Product Variants
| Model | Pitch Dia. | Outside Dia. | Bore Dia. | Hub Dia. | Length Through Bore | Bushing Type | For Chain Number | For Chain Pitch | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 160BTB26H | 16.5925" | 17.671" | 1.188" to 3.5" | 6 1/2" | 3 1/2" | TB 3535 | 160 | 2" | €1,138.21 | |
| 160BTB11H | 7.0989" | 8.011" | 1/2" to 2 1/2" | 4 1/4" | 1 3/4" | TB 2517 | 160 | 2" | €667.08 | |
| 160BTB19H | 12.1511" | 13.185" | 1.188" to 3.5" | 6 1/2" | 3 1/2" | TB 3535 | 160 | 2" | €905.07 | |
| 160BTB21H | 13.419" | 14.469" | 1.188" to 3.5" | 6 1/2" | 3 1/2" | TB 3535 | 160 | 2" | €961.38 | |
| 160BTB13H | 8.3572" | 9.314" | 0.938" to 3" | 5 1/4" | 2" | TB 3020 | 160 | 2" | €630.14 | |
| 160BTB16H | 10.2517" | 11.255" | 1.188" to 3.5" | 6 1/2" | 3 1/2" | TB 3535 | 160 | 2" | €797.08 | |
| 160BTB12H | 7.7274" | 8.664" | 0.938" to 3" | 5 1/4" | 2" | TB 3020 | 160 | 2" | €584.01 |
