MARTIN SPROCKET 140E14H Sprocket, 140 Chain, 14 Teeth, 7.864 Inch Pitch Dia., 8.717 Inch O.D., Steel
Get it by Tuesday, Aug 25
€522.45 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Roller Chain Sprocket |
| Bore Type | Bushed |
| Bushing Part Number | E |
| Bushing Size | E |
| Bushing Type | Type E QD |
| Chain Number | 140 |
| Chain Pitch | 1 3/4" |
| Chain Size | #140 |
| Construction | Solid |
| Construction Type | Solid |
| For Chain Number | 140 |
| For Chain Pitch | 1 3/4" |
| Hardened Teeth | 1 |
| Hub Configuration | B |
| Hub Dia. | 6 1/4" |
| Hub Outside Dia. | 6 1/4" |
| Individually Packaged | No |
| Length Through Bore | 2 5/8" |
| Length Thru Bore | 1 5/8" |
| Material | Steel |
| Max. Bore Size | 3 5/16" |
| Min. Bore Size | 7/8" |
| No. Of Chain Rows | 1 |
| No. Of Teeth | 14 |
| Outside Dia. | 8.717" |
| Pitch | 1 3/4" |
| Pitch Dia. | 7.864" , 7.8644" |
| Single Strand Tooth Thickness | 0.924" |
| Storage Dimension Height | 1.62" |
| Storage Dimension Length | 8.717" |
| Storage Dimension Width | 8.717" |
| Type | QD Bushed Type B1 |
Shipping Info:
| Ship weight (kg) | 5.25 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 22.15 |
| Ship width (cm) | 22.15 |
| Country of Origin | US |
Product Variants
| Model | Pitch Dia. | No. Of Teeth | Length Through Bore | Hub Dia. | Storage Dimension Length | Storage Dimension Width | Hub Outside Dia. | Min. Bore Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 140SF11H | 6.2116" | 11 | 2 1/16" | 4.493" | 7.01" | 7.01" | 4 1/2" | 1/2" | €468.50 | |
| 140SF12H | 6.762" | 12 | 2 1/16" | 4 3/4" | 7.581" | 7.581" | 4 3/4" | 1/2" | €555.21 | |
| 140SF13H | 7 5/16" | 13 | 1 1/4" | 4 3/4" | 8.15" | 8.15" | 4 3/4" | 1/2" | €584.97 | |
| 140E15H | 8.417" | 15 | 2 5/8" | 6 1/4" | 9.283" | 9.283" | 6 1/4" | 7/8" | €551.98 | |
| 140E16H | 8.9702" | 16 | 1 5/8" | 6.26" | 9.848" | 9.848" | 6 1/4" | 7/8" | €588.69 | |
| 140E17H | 9.5238" | 17 | 1 5/8" | 6 1/4" | 10.412" | 10.412" | 6 1/4" | 7/8" | €653.27 | |
| 140E18H | 10.0778" | 18 | 1 5/8" | 6 1/4" | 10.975" | 10.975" | 6 1/4" | 7/8" | €685.28 |
