MACROMATIC TD-88126 Time Delay Relay, 10-10230 Hr, 12 VDC, 10A
Get it by Tuesday, Aug 18
€109.43 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Time Delay Relay |
| Adjustment Operator | Onboard |
| Contact | DPDT |
| Contact Rating | 10A |
| Contact Rating (a) | 10A |
| Contacts | DPDT |
| Dc Voltage | 12V DC |
| Family Series | Macromatic Relays, TD Series |
| Gross Weight | 0.27 lbs. |
| Max. Time | 999 hrs. |
| Multi-function | Yes |
| Output Amps | 10A |
| Series | TD Series |
| Status Indicator | LED |
| Termination | 11 Pin |
| Time Range Adjustment | Onboard |
| Timing Range | 0.5 Seconds - 10,230 Hours |
Shipping Info:
| Ship weight (kg) | 0.14 |
| Ship height (cm) | 6.1 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 4.32 |
| Country of Origin | US |
Product Variants
| Product | Model | Dc Voltage | Ac Voltage | Coil Voltage | Max. Time | Series | Mounting Type | Timer | Time Range 10 Hrs. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TD-88162 | 120V DC | 120V AC | 120V AC | 999 hrs. | - | - | - | - | €90.30 | |
 |
TD-88168 | 24V DC | 24V AC | 24V AC | 999 hrs. | - | - | - | - | €90.30 | |
 |
TD-88161 | - | 240V AC | 240V AC | 999 hrs. | - | - | - | - | €90.30 | |
 |
TD-88122 | 120V DC | 120V AC | - | 999 hrs. | TD-8 Series | Socketable | - | - | €109.43 | |
 |
TD-80221-40 | - | 240V AC | - | 102.3 sec. | TD-8 Series | Socket | - | - | €94.65 | |
 |
TD-80221-41 | - | 240V AC | - | 1023 sec. | TD-8 Series | Socket | 0 min. to 1 min., 0 min. to 2 min., 0 min. to 3 min., 0 min. to 5 min., 0 min. to 10 min. | - | €94.65 | |
 |
TD-80221-42 | - | 240V AC | - | 10230 sec. | TD-8 Series | Socket | 0 min. to 1 min., 0 min. to 2 min., 0 min. to 3 min., 0 min. to 5 min., 0 min. to 10 min., 0 min. to 15 min., 0 min. to 30 min., 0 min. to 60 min., 0 min. to 100 min. | - | €94.65 |
