LEVITON 9550-P Angled Cable Mount Grounding Straight Blade Plug, 125 VAC, 50 A, 2 Poles, 3 Wires, Black

Item: CR9JDNModel: 9550-PCross Ref: 792U68

7 In Stock

Ships within 2 days via

~~€139.56~~

5.00% off

€132.58 /unit

This product can only be shipped in multiples of 10

Add To Cart

Request a Quote

Payment

Product Specifications:

Item	Straight Blade Plug
Ac Hp Ratings At Rated Voltage	2 hp
Amps	50A
Assembly Screws Finish	Zinc Plated
Assembly Screws Material	Steel
Blade Material	Brass
Blades/contacts	Solid Brass
Body Length	1.89"
Body Material	Super Tough Nylon
Color	Black
Cord Range	0.625" to 1.375"
Current Limiting	Full Rated Current
Current Rating	50A
Device Type	Power Device
Dielectric Voltage	Withstands 2000V Per UL498
Features	Angled
For Maximum Cable Diameter	1 3/8"
For Minimum Cable Diameter	5/8"
Grade	General Use
Grounding	Grounded , Grounding
Housing Color	Black
Housing Material	Super Tough Nylon
Hp	2 hp
Insulation Material	Nylon
Ip Rating	Not Rated
Max. Operating Temp.	60°C
Max. Wire Size	4 AWG
Maximum Operating Temperature	140°F
Min. Operating Temp.	-40°C
Min. Wire Size	10 AWG
Minimum Operating Temperature	-40°F
Nema Enclosure Rating	Not Rated
Nema Plug Configuration	5-50P
Nema Rating	NEMA WD-6
No. Of Wires	3
Number Of Blades	3
Number Of Poles	2
Operating Temp.	-40°C to +60°C
Phase	Single
Polarized	Yes
Resistance Properties	Chemical Resistant, Moisture Resistant, Shatter And Crack Resistant
Standards	Ansi C73, Csa C22.2 No. 42 File E152105, Nema Wd-6, Nom 057 Certified, Rohs Compliant, Ul 498 File E13399
Temp. Rise	Max. 30°C After 50 Cycles Ol At 150 Percent Rated Current
Terminal Accom.	Up to 4 AWG
Terminal Id	Brass Hot, Green Ground, Silver Neutral
Ul 94 Flammability Rating	V-2
Voltage	125V AC
Voltage Rating	125V AC
Wire Connection Type	Screw Terminals
Wire Gauge	10 AWG to 4 AWG
Wiring Style	Standard

Shipping Info:

Ship weight (kg)	0.3
Ship height (cm)	22.54
Ship length (cm)	27.62
Ship width (cm)	8.89
Country of Origin	MX

Product Variants

Model	Nema Plug Configuration	Amps	Voltage	Number Of Poles	Number Of Blades	Grounding	Hp	Nema Rating	Price
9151-N	10-20P	20A	125/250V AC	3	3	Non Grounded	2 hp	NEMA 10-20P	€143.78
9332-P	10-30P	30A	125V AC	3	3	Non Grounded	2 hp	NEMA WD-6	€73.86
9450-P	10-50P	50A	125/250V AC	3	3	Non Grounded	3 hp	NEMA 10-50P	€161.95
9432-P	14-30P	30A	125/250V AC	3	4	Grounded	2 hp	NEMA WD-6	€125.57
9452-P	14-50P	50A	125/250V AC	3	4	Grounded	3 hp	NEMA WD-6	€160.39
9462-P	14-60P	60A	125/250V AC	3	4	Grounded	3 1/2 hp	NEMA WD-6	€211.53
9530-P	5-30P	30A	125V AC	2	3	Grounded	2 hp	-	€101.18
