LEESON LM22665 SRF4S1.5TC61Q40 Vector Motor | AJ2VUF SRF4S1.5TC61Q40

LEESON LM22665 SRF4S1.5TC61Q40 Speed Ratio Motor, 1.50 HP, 3 Phase, 60 Hz, 230/460V, 1800 RPM

Item: AJ2VUFModel: LM22665Cross Ref: 820J33 / SRF4S1.5TC61Q40
Check Availability
In Stock
HP

Get it by Tuesday, May 19

€862.20 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

Item Vector Motor
Ambient Temp. 40°C
Amps 2.5/5A
Assembly/box Mounting F1 Only
Code M
Curvepoint Locked Rotor
Design B, M
Design Code B
Drive End Bearing Size 205
Drive End Bearing Type Ball
Duty Cycle Continuous
Efficiency 78.5%
Efficiency @ 100% 78.5%
Electrical Type Squirrel Cage, Inverter Duty
Enclosure Type Tefc
Frame 56HC
Frame Length 8 3/5"
Frame Material Rolled Steel
Frame Size 56HC
Frame Suffix Hc
Frequency 60 Hz
Full Load Amps 2.5A
Grease Type Polyrex EM
Hazardous Location Not Available
Height 8 3/25"
Hp 1 1/2 hp
Insulation Class Class F
Inverter Load 4:1
Inverter Load Ratio 4:1
Inverter Load Type Constant
Inverter Type Not Available
Ip Code 43
Kw 1.1 kW
Length 16.38"
Load 0.75
Lubrication Standard
Max. Rpm 1800 RPM
Motor Enclosure Design Totally Enclosed Fan Cooled
Motor Mounting Type Rigid Base
Motor Orientation Horizontal
Motor Shaft Rotation Clockwise/Counter Clockwise
Motor Type Squirrel Cage Inverter Rated
Mounting Type Rigid
Nema Rating NEMA 56
No. Of Poles 4
No. Of Speeds 1
Opp. Drive End Bearing Size 203
Opp. Drive End Bearing Type Ball
Outline A-100109LN-806
Output Kw 1.1 kW
Overall Length 13 8/25"
Packaging B
Paint UNK
Phase 3
Power 1.12 kW
Power Factor 74.5
Protection No Protection
Resistance Main 10.6 ohms
Rotation Type Reversible
Rpm 1740 RPM
Service Factor 1
Service Factor Amps Not Available
Shaft Dia. 5/8"
Shaft Length 1 22/25"
Speed Range Not Available
Starting Method Inverter Only
Synchronous Rpm 1800 RPM
Thermal Protection Thermostat
Torque 17.8 lbs.-ft.
Torquepct 396
Type TS
Voltage 230/460V
Winding ZT4137

Shipping Info:

Ship weight (kg) 18.45
Ship height (cm)20.62
Ship length (cm)41.61
Ship width (cm)26.67
Country of OriginMX

Product Details:

    • Eff 100%: 78.5
    • Bearing OPE: 203
    • CC Number: EXEMPT
    • Bearing PE: 205
    • Winding: ZT4137
    • GROUP: 3
    • Paint: GRAY (POWDER)
