LEESON 5KC35GNA488 CG382 Instant Reversing Motor, 0.25 HP, 1 Phase, 60 Hz, 115V, 1800 RPM
Get it by Tuesday, Aug 25
€ 34,99 Flat Shipping + VAT € 34,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
5.00% off
€611.29 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Instant Reverse Motor |
| Ambient Temp. | 40°C |
| Application | Garage/Gate Opener |
| Bearing Type | Ball |
| Conduit Box Location | Exterior |
| Duty Cycle | Continuous |
| Extended Thru Bolts | Yes |
| Frame | 48 |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 5.2A |
| Hp | 1/4 hp |
| Insulation Class | Class B |
| Length Less Shaft | 8 1/16" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Garage/Gate Opener |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Enclosure Design | Open Dripproof |
| Motor Frame Material | Steel |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.35 |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | CCW, CW |
| Motor Thermal Protection | None |
| Motor Type | Capacitor Start |
| Mounting | Base, Extended Studs |
| Mounting Type | Rigid Base |
| Nameplate Speed | 1725 RPM |
| No. Of Speed | 1 |
| No. Of Wires | 4 |
| Nominal Efficiency | 52.6% |
| Overall Length | 9 9/16" |
| Phase | 1 |
| Service Factor | 1.35 |
| Shaft Dia. | 1/2" |
| Speed | 1701-1800 RPM |
| Thermal Protection | None |
| Voltage | 115V AC |
Shipping Info:
| Ship weight (kg) | 6.3 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 32.08 |
| Ship width (cm) | 17.63 |
| HS code | 8501404040 |
| Country of Origin | MX |
Product Variants
| Product | Model | Hp | Mounting Type | Frame | Motor Enclosure Design | Duty Cycle | Frame Material | Motor Shaft Design | Service Factor | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
103460.00 | 1/2 hp | Cradle Base | 56 | Open Dripproof | Continuous | Steel | Keyed | 1 | €407.18 | |
 |
102021.00B | 1/2 hp | Round | S56C | Dripproof | Continuous | Rolled Steel | NEMA 56 | 1 | €1,521.64 | |
 |
111080.00 | - | - | - | - | - | - | - | - | €1,115.16 | |
 |
5KC46GN0251 | 1/2 hp | Rigid Base | 56 | Open Dripproof | Continuous | Steel | Keyed | 1.25 | €687.72 | |
 |
5KC46LN0252 | - | - | - | - | - | - | - | - | €799.46 | |
 |
103794.00 | 1/3 hp | Resilient Base | - | - | Intermittent | Rolled Steel | Keyed | - | €548.69 |
