LEESON 102021.00B M4P17DC53A Instant Reversing Motor, 0.50 HP, 1 Phase, 60 Hz, 115V, 1800 RPM
Get it by Tuesday, Jul 7
€ 24,99 Flat Shipping + VAT € 24,99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.
5.00% off
€1,445.56 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Motor |
| Ambient Temp. | 40°C |
| Amps | 6A |
| Assembly/box Mounting | F1 Only |
| Bearing Type | Ball |
| Bolt Circle Dia. | 3 1/2" |
| Conduit Box Position | F1 |
| Curvepoint | Locked Rotor |
| De Bearing Type | Ball |
| Design Code | No |
| Drive End Bearing Size | 6203 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 51% |
| Electrical Type | Permanent Split Capacitor |
| Enclosure Type | Drip Proof |
| Frame | S56C |
| Frame Material | Rolled Steel |
| Frame Prefix | S |
| Frame Size | S56C |
| Frame Suffix | C |
| Frequency | 60 Hz |
| Full Load Amps | 6A |
| Height | 10 22/25" |
| Hp | 1/2 hp |
| Ins. Class | Class F |
| Insulation Class | Class F |
| Ip Code | IP12 |
| Kva Code | B |
| Kw | 0.37 kW |
| Length | 14 11/25" |
| Load | 1.25 |
| Max. Ambient Temp. | 40°C |
| Motor Bearings | Ball |
| Motor Enclosure Design | Dripproof |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Orientation | Horizontal |
| Motor Service Factor | 1 |
| Motor Shaft Design | NEMA 56 |
| Motor Shaft Rotation | CCW |
| Motor Thermal Protection | Manual |
| Mounting Type | Round |
| Nameplate Speed | 1625 RPM |
| Nema Rating | NEMA 56 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| No. Of Wires | 3 |
| Nominal Efficiency | 51% |
| Opp Drive End Bearing Size | 6203 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 0.37 kW |
| Phase | 1 |
| Power Factor | 99 |
| Product Datasheet | leeson-102021-00b.pdf |
| Resistance Main | 1.57 ohms |
| Rotation Type | Selective CCW |
| Service Factor | 1 |
| Speed | 1625 RPM |
| Starting Method | Across The Line |
| Synchronous Speed | 1800 RPM |
| Thermal Protection | Manual |
| Torque | 47.6 lbs.-ft. |
| Torquepct | 198 |
| Voltage | 115V |
Shipping Info:
| Ship weight (kg) | 9.9 |
| Ship height (cm) | 27.64 |
| Ship length (cm) | 36.68 |
| Ship width (cm) | 26.52 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Hp | Frame | Motor Enclosure Design | Mounting Type | Service Factor | Frame Material | Overall Length | Nominal Efficiency | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KC35GNA488 | 1/4 hp | 48 | Open Dripproof | Rigid Base | 1.35 | Steel | 9 9/16" | 52.6% | €643.46 | |
 |
103460.00 | 1/2 hp | 56 | Open Dripproof | Cradle Base | 1 | Steel | 9 15/16" | 63% | €407.18 | |
 |
111080.00 | - | - | - | - | - | - | - | - | €1,115.16 | |
 |
5KC46GN0251 | 1/2 hp | 56 | Open Dripproof | Rigid Base | 1.25 | Steel | 10 3/4" | 52.5% | €687.72 | |
 |
5KC46LN0252 | - | - | - | - | - | - | - | - | €799.46 | |
 |
103794.00 | - | - | - | - | - | - | 10 13/16" | - | €548.69 |
