LEESON 143TTDR16013 143TTDR16013AA / GT4103 Close Coupled Pump Motor, 1.50/1 HP, 3 Phase, 60/50 Hz, 230/460 and 190/380V, 3600 RPM
Item: AJ2NNNModel: 143TTDR16013Cross Ref: 52JA12 / 143TTDR16013AA / GT4103
In Stock
Get it by Monday, May 18
€227.02 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Close-Coupled Pump Motor |
| Ambient (c) | 40°C |
| Assembly | F1 Only |
| Bearing Type | Ball |
| Body Dia. | 6 1/2" |
| Bolt Circle Dia. | 5 7/8" |
| Cc Number | CC003A |
| Conduit Box Location | Exterior |
| Conduit Box Position | F1 |
| Duty Cycle | Continuous |
| Efficiency | 86.5% |
| Frame | 143JMV |
| Frame Material | Steel |
| Frame Type | 143JMV |
| Frequency | 60 Hz |
| Full Load Amps | 3.8/1.9A |
| Full Load Efficiency | 86.5% |
| Hp | 1 1/2 hp |
| Includes | Drip Cover |
| Insulation Class | Class F |
| Inverter Rated | Yes |
| Inverter Rating | 10:1 Variable Torque, 2:1 Constant Torque |
| Length Less Shaft | 10 11/16" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Pump |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Open Dripproof |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal, Vertical Shaft Down |
| Motor Mounting Type | Face |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Keyed Threaded |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Close-Coupled Pump |
| Motor Thermal Protection | None |
| Motor Type | Squirrel Cage Inverter Rated |
| Mounting Type | C Face, Footless |
| Nameplate Rpm | 3515 RPM |
| Nema Design | B |
| Nominal Efficiency | 86.5% |
| Number Of Speeds | 1 |
| Orientation | Horizontal, Shaft Down |
| Output Kw | 1.12 kW |
| Overall Length | 14 15/16" |
| Phase | 3 |
| Power | 1.12 kW |
| Rpm Range | 3001-3600 RPM |
| Shaft Dia. | 7/8" |
| Shaft Length | 4 1/4" |
| Usable @ 200v | No |
| Usable @ 208v | No |
Shipping Info:
| Ship weight (kg) | 19.8 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 50.5 |
| Ship width (cm) | 26.04 |
| HS code | 8501524000 |
| Country of Origin | MX |
Product Details:
- Starting Type: LINE OR INVERTER
- KVA Code: L
- Drive End Bearing: BALL
- IP Code: 22
- Opposite End Bearing: BALL
- Drive End Bearing Size: 6206
- Opposite End Bearing Size: 6203
- Inverter Speed Range: CONSTANT 2:1
Product Variants
| Product | Model | Hp | Nameplate Rpm | Motor Enclosure Design | Voltage | Frame | Motor Mounting Type | Rpm Range | Motor Design | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
145TTDR6013 | 3 hp | 3490 RPM | Open Dripproof | 230/460V AC | 145JM | Face, Base | 3001-3600 RPM | 3 Phase | €1,032.54 | |
 |
145TTDR6034 | 1 1/2 hp | 1755 RPM | Open Dripproof | 230/460V AC | 145JM | Face, Base | 1701-1800 RPM | 3 Phase | €787.73 | |
 |
145TTDR6036 | 2 hp | 1750 RPM | Open Dripproof | 230/460V AC | 145JM | Face, Base | 1701-1800 RPM | 3 Phase | €847.83 | |
 |
145TTDR16330 | 1 1/2 hp | 1755 RPM | Open Dripproof | 230/460V AC | 145JP | Face, Base | 1701-1800 RPM | 3 Phase | €787.73 | |
 |
143TTDR16042 | 1 hp | 1800 RPM | Dripproof | 200V AC | 143JMV | C Face Footless | - | - | €183.11 | |
 |
145TTDR16337 | 2 hp | 1800 RPM | Dripproof | 200V AC | 145JPV | Rigid Base | - | - | €265.76 | |
 |
145TTDR16302 | 3 hp | 3600 RPM | Dripproof | 575V AC | 145JMV | C Face Footless | - | - | €179.69 |
