LEESON 110415.00 M6C34FC9H General Purpose Motor, 1 HP, 1 Phase, 60 Hz, 115/230V, 3600 RPM
Get it by Tuesday, Dec 23
10.00% off
€632.97 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Single Phase Motor |
| Ambient Temp. | 104°F |
| Amps | 12/6A |
| Bearing Type | Ball |
| Code | J |
| Conduit Box Position | F1 |
| Design Code | No |
| Drive End Bearing Size | 6203 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 70% |
| Electrical Type | Capacitor Start, Induction Run |
| Enclosure Type | Tefc |
| Frame | 56C |
| Frame Length | 6 1/2" |
| Frame Material | Rolled Steel |
| Frame Type | 56C |
| Frequency | 60 Hz |
| Full Load Amps | 12/6.2-6A |
| Grease Type | Polyrex EM |
| Height | 10 22/25" |
| Hp | 1 hp |
| Hz | 60 Hz |
| Ins. Class | Class B |
| Insulation Class | Class B |
| Ip Code | IP54 |
| Kva Code | J |
| Kw | 0.75 kW |
| Length | 14 11/25" |
| Lubrication | Polyrex EM |
| Max. Ambient Temp. | 104°F |
| Max. Rpm | 3450 RPM |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Face |
| Motor Orientation | Horizontal |
| Motor Service Factor | 1.15 |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Shaft Rotation | CCW |
| Motor Thermal Protection | Manual |
| Motor Type | Capacitor Start |
| Mounting Type | Face |
| Nameplate Rpm | 3450 RPM |
| Nema Design | N |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 70% |
| Opp. Drive End Bearing Size | 6203 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 0.75 kW |
| Overall Length | 12" |
| Packaging | B |
| Phase | 1 |
| Power Factor | 76 |
| Resistance Main | 1.92 ohms |
| Rpm | 3400-3600 RPM |
| Rpm Range | 3001-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 22/25" |
| Shaft Type | NEMA 56 |
| Standards | Csa, Ul |
| Starting Method | Across The Line |
| Thermal Protection | Manual |
| Type | CF |
| Usable @ 208v | Yes |
| Voltage | 115/208-230V |
| Weight | 31 lbs. |
| Width | 10 11/25" |
Shipping Info:
| Ship weight (kg) | 13.95 |
| Ship height (cm) | 27.64 |
| Ship length (cm) | 36.68 |
| Ship width (cm) | 26.52 |
| Country of Origin | US |
Product Details:
- Eff 100%: 70
- Bearing OPE: 6203
- CC Number: EXEMPT
- Bearing PE: 6203
- Nameplate: 993500
- Winding: C632211
- GROUP: 3
- Paint: BLUE - LEESON (ENAMEL)
- S. F Amps: 13.6 / 7-6.8
Product Variants
| Product | Model | Voltage | Hp | Full Load Amps | Mounting Type | Service Factor | Nameplate Rpm | Motor Type | Frame | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
101765.00 | 115/208-230V | 1/4 hp | 5.4/2.4-2.7A | C Face, Footless | 1.15 | 1800 RPM | Capacitor Start | 48CZ | €678.46 | |
 |
101766.00 | 115/208-230V | 33/100 hp | 6.6/2.9-3.3A | Face | 1.15 | 1725 RPM | Capacitor Start | S56C | €416.65 | |
 |
102864.00 | 115/208-230V | 1/2 hp | 7/3.4-3.5A | Face | 1.15 | 3450 RPM | Capacitor Start | S56C | €417.09 | |
 |
102865.00 | 115/208-230V | 1/2 hp | 8/3.8-4A | C Face, Footless | 1.15 | - | - | 56C | €821.61 | |
 |
102868.00 | 115/208-230V | 1/4 hp | 4.6/2.4-2.3A | C Face, Footless | 1.15 | 1800 RPM | Capacitor Start | S56C | €432.70 | |
 |
102869.00 | 115/208-230V | 33/100 hp | 5.2/2.6A | C Face, Footless | 1.15 | 1800 RPM | - | S56C | €489.02 | |
 |
102872.00 | 115/208-230V | 1/2 hp | 7/3.4-3.5A | C Face, Footless | 1.15 | 3600 RPM | Capacitor Start | S56C | €688.06 |
