IFM IG0328 Cylindrical Proximity Sensor, 20 To 250VAC/Dc, 2 Wire, 5 mm
Item: CR4LHWModel: IG0328Cross Ref: 35T353
7 In Stock
Ships within 2 days via
€168.11 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Cylindrical Proximity Sensor |
| Ac Supply Voltage | 20-250V AC |
| Basic Proximity Sensor Case Material | Metal |
| Body Material | Pbt, Stainless Steel |
| Body Stainless Steel Grade | Grade 316L |
| Cable Length | 2m |
| Dc Supply Voltage Rating | 20-250V DC |
| Display Qty | 1 |
| Electrical Connection | Bare Wire |
| Electrical Installation Type | Prewired Cable |
| Housing | Threaded Type |
| Included | (2) Lock Nuts |
| Included Indicator Lights | Indicator Lights Included |
| Ip Rating | IP67 |
| Length | 98 mm |
| Max. Detecting Distance | 5 mm |
| Max. Load Amps | 250/100 mA |
| Max. Operating Temp. | 176°F |
| Max. Output Circuit Voltage | 6V DC |
| Min. Operating Temp. | -13°F |
| Mounting | Flush Mountable |
| No. Of Wires | 2 |
| Nominal Sensor Dia. | M18 Threaded |
| Operating Temp. | -13°F to +158°F |
| Output Circuit | 2 Wire AC/DC |
| Output Circuit Amps-max. | 250 mA |
| Output Circuit Contact Form | No |
| Output Circuit Type | Ac, DC-Type |
| Output Mode | No |
| Overall Height | 80 mm |
| Overload Protection | No |
| Proximity Sensing Method | Inductive |
| Proximity Sensor Dia. | 18 mm |
| Proximity Sensor Electrical Connection | Cable |
| Proximity Sensor Output Circuit Type | Two Wire |
| Reverse Polarity Protection | No |
| Sensing Face Shielding | Shielded |
| Sensing Method | Inductive |
| Sensor Body Style | Cylindrical |
| Sensor Cable Length | 2m |
| Sensor Dia. | 18 mm |
| Shielded/unshielded | Shielded |
| Short-circuit Proof | No |
| Supply Voltage | 20-250V AC/20-250V DC |
Shipping Info:
| Ship weight (kg) | 0.15 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
Product Variants
| Product | Model | Included | Max. Detecting Distance | Output Mode | Proximity Sensor Dia. | Proximity Sensing Method | Supply Voltage | Sensor Dia. | Electrical Connection | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
IIS229 | (2) Lock Nuts | 22 mm | No | 30 mm | Inductive | 10-30V DC | 30 mm | M12 | €106.07 | |
 |
IIS244 | (2) Lock Nuts | 15 mm | No | 30 mm | Inductive | 10-30V DC | 30 mm | Bare Wire | €108.46 | |
 |
IIS228 | (2) Lock Nuts | 15 mm | No | 30 mm | Inductive | 10-30V DC | 30 mm | M12 | €105.10 | |
 |
IIS248 | (2) Lock Nuts | 15 mm | NC | 30 mm | Inductive | 10-30V DC | 30 mm | M12 | €139.23 | |
|
IIS235 | (2) Lock Nuts | 15 mm | NC | 30 mm | Inductive | 10-30V DC | 30 mm | M12 | €139.20 | |
|
IIS237 | (2) Lock Nuts | 22 mm | NC | 30 mm | Inductive | 10-30V DC | 30 mm | M12 | €105.04 | |
 |
IIS249 | (2) Lock Nuts | 22 mm | NC | 30 mm | Inductive | 10-30V DC | 30 mm | M12 | €139.23 |
