DESTACO 035-150-290 Pnuematic Swing Cylinder, 50Mm, Left, 90-Deg, 106.17 mm x 59.94 mm Size
Item: ED2AAPModel: 035-150-290
In Stock
Get it by Thursday, Jul 16
€555.42 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Clamp |
| Accessories | 905519, 036-787-01, 036-787-02, 051-250-160 |
| Air Consumption Per Double Stroke @ 7 Psi | 0.023 cu. in. |
| Air Port Size | 1/8" |
| Air Port Type | NPT |
| Clamping Force @ 72 Psi | 69 lbf. |
| Cylinder Bore | 1.97" |
| Jam Nut | 051-250-160 |
| Length | 2 9/25" |
| Mounting | Threaded Body |
| Product Application | Clamping |
| Replacement Seal Kit | 905519 |
| Spindle Included | No |
| Stroke During Rotation | 0.63" |
| Swing Direction | Left Hand |
Shipping Info:
| Ship weight (kg) | 0.81 |
| Ship height (cm) | 10.62 |
| Ship length (cm) | 5.99 |
| Ship width (cm) | 5.99 |
Product Variants
| Product | Model | Swing Direction | Stroke | Rotating Stroke | Overall Height | Max. Vertical Clamp Stroke | Cylinder Bore | Max. Input Air Pressure | Max. Operating Temp. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
035-132-290 | Left | 1.13" | 14/25" | 117.3 mm | 14.5 mm | - | 100 psi | 176°F | €704.43 | |
 |
035-132-190 | Right | 1.13" | 14/25" | 117.3 mm | 14.5 mm | - | 100 psi | 176°F | €704.43 | |
 |
035-225-190 | Right | 1.05" | 0.54" | 81.7 mm | 13 mm | - | 100 psi | 176°F | €490.78 | |
 |
035-225-290 | - | 1.05" | 0.54" | - | - | 0.98" | - | - | €360.22 | |
 |
035-240-190 | - | 1.09" | 0.57" | - | - | - | - | - | €388.17 | |
 |
035-250-290 | - | 1.13" | 0.63" | - | - | - | - | - | €477.75 | |
 |
051-150-160 | - | - | - | - | - | - | - | - | - | RFQ
|
