DAYTON 43XH15 Blower with Drive Package, 208/230-460 V, 37 Inch Depth
840 RPM
Get it by Tuesday, Dec 23
10.00% off
€4,232.45 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Blower |
| Airflow @ 0.250 In Sp | 5175 CFM |
| Airflow @ 0.375 In Sp | 5010 CFM |
| Airflow @ 0.500 In Sp | 4855 CFM |
| Airflow @ 0.750 In Sp | 4560 CFM |
| Airflow @ 1.000 In Sp | 4255 CFM |
| Airflow @ 1.250 In Sp | 3925 CFM |
| Airflow @ 1.500 In Sp | 3525 CFM |
| Airflow @ 10.00 In Sp | Not Applicable |
| Airflow @ 11.00 In Sp | Not Applicable |
| Airflow @ 12.00 In Sp | Not Applicable |
| Airflow @ 13.00 In Sp | Not Applicable |
| Airflow @ 2.000 In Sp | Not Applicable |
| Airflow @ 2.500 In Sp | Not Applicable |
| Airflow @ 3.000 In Sp | Not Applicable |
| Airflow @ 3.500 In Sp | Not Applicable |
| Airflow @ 4.000 In Sp | Not Applicable |
| Airflow @ 4.500 In Sp | Not Applicable |
| Airflow @ 5.000 In Sp | Not Applicable |
| Airflow @ 6.000 In Sp | Not Applicable |
| Airflow @ 7.000 In Sp | Not Applicable |
| Airflow @ 8.000 In Sp | Not Applicable |
| Airflow @ 9.000 In Sp | Not Applicable |
| Amps | 8.3-7.8/3.9A |
| Assembled/unassembled | Unassembled |
| Assembly | Unassembled |
| Bearing Type | Ball |
| Dba @ 5 Feet | 70 dBA |
| Depth | 37" |
| Discharge Height | 17 3/4" |
| Discharge Width | 13" |
| Drive Package With Motor Included? | Yes |
| Drive Type | Belt Drive |
| Flange Size | Not Applicable |
| Frequency | 50/60 Hz |
| Height | 33 1/8" |
| Housing Color | Gray |
| Housing Depth | 37" |
| Housing Height | 33 1/8" |
| Housing Material | Steel |
| Housing Material Finish | Baked Enamel |
| Housing Width | 28 7/8" |
| Includes | Weatherproof Drive Cover |
| Includes Drive Package | Yes |
| Includes Motor | Yes |
| Inlet Dia. | 17 7/8" |
| Inlet Diameter | 17 7/8" |
| Manufacturer Warranty Length | 1 yr. Limited |
| Maximum Ambient Temperature | 104°F |
| Maximum Fan Speed | 840 RPM |
| Maximum Inlet Air Temperature | 250°F |
| Maximum Static Pressure | 1.5 in. wc |
| Motor Duty Class | Continuous |
| Motor Enclosure | Open Dripproof |
| Motor Frame Designation | 184T |
| Motor Horsepower | 3 hp |
| Motor Hp | 3 hp |
| Motor Insulation Class | Class B |
| Motor Speed | 1770 RPM |
| Motor Type | Rigid Base |
| Nameplate Voltage | 208-230/460V AC |
| No. Of Inlets | 1 |
| Number Of Speeds | 1 |
| Oem Replacement | No |
| Outlet Dia. | Not Applicable |
| Outlet Height | 17 3/4" |
| Outlet Shape | Rectangular |
| Outlet Type | Non Flanged |
| Outlet Width | 13" |
| Overall Depth | 37" |
| Overall Height | 33 1/8" |
| Overall Width | 28 7/8" |
| Phase | 3 |
| Rotation | CW |
| Shaft Dia. | 1 1/8" |
| Sound Level | 70 dBA @ 5 Ft. |
| Wheel Dia. | 16 1/2" |
| Wheel Material | Steel |
| Wheel Type | Forward Curved |
| Width | 28 7/8" |
Shipping Info:
| Ship weight (kg) | 136.94 |
| Ship height (cm) | 84.14 |
| Ship length (cm) | 93.98 |
| Ship width (cm) | 73.34 |
| Country of Origin | US |
Product Variants
| Product | Model | Height | Material | Finish | Wheel Material | Outlet Height | Outlet Width | Drive Type | Wheel Dia. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
1C791 | 15" | Steel | Baked Epoxy | Steel | 7 3/8" | 4 1/4" | Direct Drive | 6.312" | €449.46 | |
|
1C792 | 16" | Steel | Gray Polyester Epoxy | Steel | 8 1/4" | 5 3/8" | Direct Drive | 7 3/4" | €699.43 | |
 |
2C797 | 27" | Steel | Baked Polyester Epoxy | Steel | 13 1/4" | 9 5/8" | Belt Drive | 12 1/4" | €2,190.34 | |
 |
2C800 | 27" | Steel | Baked Polyester Epoxy | Steel | 13 1/4" | 9 5/8" | Belt Drive | 12 1/2" | €909.50 | |
|
2C889 | 18" | Steel | Gray Polyester Epoxy | Steel | 10 3/4" | 6 1/2" | Direct Drive | 9" | €690.83 | |
|
2C890 | 21" | Steel | Gray Polyester Epoxy | Steel | 11 3/4" | 8" | Direct Drive | 10 5/8" | €846.60 | |
|
3AXE8 | 18" | Steel | Baked Polyester Epoxy | Steel | 8 1/4" | 5 3/8" | Belt Drive | 7 3/4" | €1,903.43 |
