BUSSMANN TB345-06 Barrier Terminal Block, 45A, 600V
Get it by Friday, Dec 19
€9.19 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Terminal Block |
| Amps | 45A |
| Contact Material | Brass |
| Height | 0.81" |
| Housing Material | Thermoplastic |
| Length | 4.37" |
| Max. Operating Temp. | 130°C |
| Max. Operating Temp. | 130 Deg. C |
| Max. Wire Size | 8 AWG |
| Min. Operating Temp. | -40°C |
| Min. Wire Size | 22 AWG |
| Mounting Angle | Straight |
| Mounting Position | Straight |
| Mounting Style | Panel |
| Number Of Positions | 6 |
| Number Of Positions | 6 Position |
| Number Of Rows | 2 Row |
| Number Of Rows | 2 |
| Packaging | Bulk |
| Pitch | 14/25" |
| Plating | Tin |
| Series | TB345 |
| Termination Style | Screw |
| Voltage | 600V AC |
| Width | 1.33" |
| Wire Size | 22 AWG to 8 AWG |
Shipping Info:
| Ship weight (kg) | 0.05 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
Product Variants
| Model | Amps | Max. Operating Temp. | Housing Material | Pitch | Min. Operating Temp. | Mounting Angle | Mounting Position | Plating | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TB345-07SP | 45A | 130°C | Thermoplastic | 14/25" | -40°C | Straight | Straight | Tin | 50 | €13.68 | |
| TB345-12L5 | 45A | 130°C | Thermoplastic | 14/25" | -40°C | Straight | Straight | Tin | 50 | €19.64 | |
| TB345-08 | 45A | 130°C | Thermoplastic | 14/25" | -40°C | Straight | Straight | Tin | 1 | €12.26 |
