BUSSMANN BSPD48RJ45 Surge Protection Device Type 2 10ka 1p
Item: AF6QMZModel: BSPD48RJ45Cross Ref: 20AZ51
7 In Stock
Ships within 2 days via
10.00% off
€415.44 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Surge Protection Device |
| Amps | 1A |
| Basic Material | Metallic |
| Color | Gray |
| Depth | 1.42" |
| Enclosure Material | Die Cast Zinc |
| Enclosure Rating | IP20 |
| Filter Type | Nonfiltering |
| Filtering | No |
| Ip Rating | 20 |
| Length | 2.99" |
| Max. Continuing Operating Voltage | 48V DC |
| Max. Continuing Operating Voltage | 48 |
| Max. Operating Temp. | 176°F |
| Max. Surge Current Per Mode | 10 kA |
| Max. Surge Current Per Mode | 10kA |
| Max. Surge Current Per Phase | 10kA |
| Max. Surge Current Per Phase | 10 kA |
| Min. Operating Temp. | -40°F |
| Modes Of Protection | L-G, L-L |
| Modes Of Protection | L G, L L |
| Modular | Yes |
| Mounting Style | DIN Rail |
| Nominal Discharge Amps | 48 kA |
| Nominal Discharge Current | 48 kA |
| Nominal Discharge Current | 150A |
| Number Of Poles | 1 |
| Number Of Wires | 2 |
| Phase | 1 |
| Standards | En 61643-21, Iec 61643-21 |
| System Connection | Series |
| Voltage | 48V DC |
| Voltage Protection Rating | 190V (L-L), 600V (L-G) |
| Voltage Protection Rating | 190 |
| Width | 3/4" |
| Wire | 2 |
| Wire Gauge | 28 AWG to 12 AWG |
Shipping Info:
| Ship weight (kg) | 0.11 |
| Ship height (cm) | 3.81 |
| Ship length (cm) | 6.35 |
| Ship width (cm) | 8.38 |
| HS code | 8536308000 |
| Country of Origin | DE |
Product Variants
| Product | Model | Voltage | Number Of Poles | Number Of Wires | Max. Surge Current Per Phase | Nominal Discharge Current | Voltage Protection Rating | Enclosure Material | Max. Continuing Operating Voltage | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
BSPD24DING | 24V DC | 4 | 4 | 2.5 kA | 10 kA | 102V (L-L), 66V (L-G) | Polyamide | 33V DC | €541.87 | |
|
BSPD5DINLHF | 5V DC | 4 | 4 | 2.5 kA | 10 kA | 25V (L-L), 550V (L-G) | Polyamide | 6V DC | €566.84 |
