BROWNING 1043132 2BK110H V-Belt Sheave, Bushed, 2 Groove, Cast Iron, 10-3/4 in OD, 3/8 to 1-1/2 in Bore Dia, 10.2 in A/10.7 in B Pitch Dia
Get it by Tuesday, May 19
€244.62 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | V-Belt Sheave |
| Belt Series | 4L, A, 5L, B Series |
| Bore Dia. | 3/8" to 1 1/2" |
| Bore Type | Split Taper |
| Bushing Type | H |
| Face Width | 1 3/4" |
| Hub Projection | 5/32" |
| Keyway | Yes |
| Material | Cast Iron |
| Max. Pitch Dia. | 10 2/5" |
| Min. Pitch Dia. | 10" |
| Min. Plain Bore | No |
| No. Of Grooves | 2 |
| Outside Dia. | 10 3/4" |
| Overall Length | 1 29/32" |
| Pitch Dia. (a) | 10 1/5" |
| Pitch Dia. (b) | 10.7" |
| Series | BK Series |
| Suitable For Use With | Classical Gripbelt 4L/A And 5L/B Cross Section Belts |
| System Of Measurement | Imperial |
| Type | Type 3 |
Shipping Info:
| Ship weight (kg) | 5.67 |
| Ship height (cm) | 27.31 |
| Ship length (cm) | 4.85 |
| Ship width (cm) | 27.31 |
| Country of Origin | US |
Product Variants
| Product | Model | Outside Dia. | Bore Dia. | Bore Type | Overall Length | Type | Material | Face Width | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
1042977 | 3 3/4" | 3/8" to 1 1/2" | Split Taper | 2 7/32" | Type 1 | Cast Iron | 1 3/4" | €151.98 | |
 |
1043017 | 4 3/4" | 3/8" to 1 1/2" | Split Taper | 2 5/32" | Type 2 | Cast Iron | - | €145.60 | |
 |
1043116 | 8 3/4" | 3/8" to 1 1/2" | Split Taper | 1 29/32" | Type 3 | Cast Iron | 1 3/4" | €226.94 | |
 |
1033018 | 2 1/2" | 1/2" | Finished | 2 7/32" | Type 1 | Cast Iron | 1 3/4" | €241.18 | |
 |
1033372 | 3 3/4" | 1 3/8" | Finished | 2 7/32" | Type 1 | Cast Iron | 1 3/4" | €218.36 | |
 |
1043108 | 7 3/4" | 3/8" to 1 1/2" | Split Taper | 1 29/32" | Type 3 | Cast Iron | 1 3/4" | €222.77 | |
 |
1043090 | 6 3/4" | 3/8" to 1 1/2" | Split Taper | 1 29/32" | Type 3 | Cast Iron | 1 3/4" | €191.83 |
