ARO 666250-G22-C Double Diaphragm Pump Air Operated 2 Inch
Get it by Tuesday, Aug 25
5.00% off
€3,573.76 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Double Diaphragm Pump |
| Air Consumption | 140 SCFM |
| Air Inlet Size | 3/4" |
| Air Inlet Type | NPT |
| Air Pressure | 120 psi |
| Ball Material | Nitrile |
| Center Section Material | Aluminum |
| Check Seat Material | Buna N |
| Compatible Chemicals | Alcohol, Oil-Based Paint, Oils, Water |
| Connection Size | 2" |
| Connection Type | NPTF |
| Diaphragm Material | Buna N |
| Display Qty | 1 |
| Flow Rate @ 100 Psi | 178 GPM |
| Flow Rate @ 120 Psi | 196 GPM |
| Flow Rate @ 40 Psi | 130 GPM |
| Flow Rate @ 50 Psi | 148.5 GPM |
| Flow Rate @ 60 Psi | 159.6 GPM |
| Flow Rate @ 70 Psi | 167 GPM |
| Flow Rate @ 80 Psi | 172.5 GPM |
| Flow Rate @ 90 Psi | 175.8 GPM |
| Fluid Intake Connection | 2" Nptf |
| Fluid Outlet Connection | 2" Nptf |
| For Use With Potable Systems | No |
| Housing Material | Aluminum |
| Inlet Size | 3/4" |
| Manifold Connection | Single Port |
| Manifold Connection Type | NPT |
| Max. Discharge Pressure | 120 psi |
| Max. Flow Gpm | 172 |
| Max. Flow Rate | 196 GPM |
| Max. Head | 289 ft. |
| Max. Media Temp. | 180°F |
| Max. Operating Pressure | 120 psi |
| Max. Solid Dia. | 1/4" |
| Max. Viscosity | 50000 cPS |
| Media Discharge Location | Center |
| Media Intake Location | Center |
| Min. Media Temp. | 10°F |
| Mounting Hardware Material | Steel |
| Nameplate Voltage | N |
| Npshr | 35 ft. |
| Operation Type | Air Operated |
| Overall Height | 26 2/5" |
| Overall Length | 17.9" |
| Overall Width | 23 4/5" |
| Power Source | Air |
| Priming | Self Priming |
| Pump Assembly Type | Bolt |
| Self Priming | Yes |
| Self Priming Dry | 27 ft. |
| Self Priming Wet | 30 ft. |
| Self-priming Dry | 27 ft. |
| Self-priming Wet | 30 ft. |
| Series | 6662XX Series |
| Series Family | Pro |
| Valve Material | Buna N |
| Valve Type | Ball |
Shipping Info:
| Ship weight (kg) | 43.65 |
| Ship height (cm) | 67.06 |
| Ship length (cm) | 45.47 |
| Ship width (cm) | 60.45 |
| HS code | 8413500050 |
| Country of Origin | CN |
Product Variants
| Product | Model | Housing Material | Max. Flow Rate | Max. Media Temp. | Diaphragm Material | Overall Width | Wetted Material | Outlet Size | Max. Solid Dia. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
PD01P-HPS-PTT-A | Polypropylene | 5.4 GPM | 225°F | PTFE | 5 3/5" | - | - | 0.06" | €1,005.95 | |
 |
DAB05-PPUU-2-F | Polypropylene | 14.4 GPM | - | - | - | - | - | - | €1,569.43 | |
|
DAB05-PPAA-2-E | Polypropylene | 14.4 GPM | - | - | - | Polypropylene, Santoprene | - | - | €1,760.96 | |
|
DAB05-SSTT-2-H | Stainless Steel | 12 GPM | - | - | - | Stainless Steel, PTFE | 5/8" | - | €3,676.31 | |
|
DAB05-ASCC-2-G | Aluminum | 12 GPM | - | - | - | Aluminum, Hytrel | 1/2" | - | €1,946.83 | |
 |
666053-388 | Polypropylene | 13.1 GPM | 150°F | Polyurethane | 6 1/2" | - | - | 0.09" | €1,643.36 | |
 |
66605J-344 | Polypropylene | 13.1 GPM | 225°F | PTFE | 6 1/2" | - | - | 0.09" | €1,990.19 |
