LEESON 3 Phase General Purpose AC Motors, 56 Frame, TEFC, C-Face With Base
Filter
A
B
C
D| Style | Model | Nameplate Rpm | Hp | Full Load Amps | Mounting Type | Service Factor | Voltage | Frame Material | Motor Shaft Rotation | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 056T11F15542 | 1140 RPM | 3/4 hp | 3.1-3.3/1.6A | Universal | 1.15 | 208-230/460V | Rolled Steel | CCW | €1,301.79 | |
| B | 056T11F15539 | 1140 RPM | 1/3 hp | 1.9-2.2/1.1A | Universal | 1.15 | 208-230/460V | Rolled Steel | CCW | €844.29 | |
| C | 056T11F15544 | 1140 RPM | 1 hp | 3.8-3.8/1.9A | Bolt On Base | 1, 1.15 | 230/460/190/380V | Rolled Steel | CCW | €1,202.66 | |
| B | 056T11F15540 | 1140 RPM | 1/2 hp | 2-2.1/1.1A | Bolt On Base | 1, 1.15 | 230/460/190/380V | Rolled Steel | CCW | €988.12 | |
| C | 056T17F15947 | 1725 RPM | 2 hp | 2.4A | Bolt On Base | 1.15 | 575V | Rolled Steel | CCW | €1,190.61 | |
| C | 056T17F15952 | 1725 RPM | 1 hp | 1.3A | Bolt On Base | 1.15 | 575V | Rolled Steel | CCW/CW | €1,099.09 | |
| C | 056T17F15951 | 1725 RPM | 1 hp | 3.1-3.1/1.6A | Universal | 1.15 | 208-230/460V | Rolled Steel | CCW | €1,097.98 | |
| B | 056T17F15945 | 1725 RPM | 3/4 hp | 1.2A | Bolt On Base | 1.15 | 575V | Rolled Steel | CCW | €541.69 | |
| B | 056T17F15944 | 1725 RPM | 1/2 hp | 0.95A | Bolt On Base | 1.15 | 575V | Rolled Steel | CCW | €502.02 | |
| B | 056T17F15950 | 1725 RPM | 3/4 hp | 2.9-3/1.5A | Universal | 1.15 | 208-230/460V | Rolled Steel | Reversible | €541.69 | |
| B | 056T17F15948 | 1725 RPM | 1/2 hp | 2.3-2.4/1.2A | Universal | 1.15 | 208-230/460V | Rolled Steel | CCW | €738.74 | |
| B | 056T17F15949 | 1725 RPM | 1/3 hp | 1.8-1.6/0.8A | Universal | 1.15 | 208-230/460V | Rolled Steel | CCW | €690.43 | |
| C | 056T17F15954 | 1725 RPM | 1 1/2 hp | 4.6-4.7/2.3A | Universal | 1.15 | 208-230/460V | Rolled Steel | CCW | €770.33 | |
| C | 056T17F15953 | 1725 RPM | 2 hp | 6-6.2/3A | Bolt On Base | 1, 1.15 | 208-230/460/190/380V | Rolled Steel | CCW | €858.33 | |
| D | 056T17W99021 | 1760 RPM | 1 hp | 3.2/1.6A | Face | 1.15 | 230/460V AC | Steel | CW/CCW | €1,407.28 | |
| C | 056T34F15673 | 3450 RPM | 2 hp | 5.6-5/2.5A | Bolt On Base | 1, 1.15 | 230/460/190/380V | Rolled Steel | CCW | €843.91 | |
| C | 056T34F15675 | 3450 RPM | 3 hp | 8.2-7.6/3.8A | Universal | 1.15 | 208-230/460V AC | Rolled Steel | CCW | €1,512.77 | |
| C | 056T34F15676 | 3450 RPM | 3 hp | 3.1A | Bolt On Base | 1.15 | 575V | Rolled Steel | CCW | €1,512.77 | |
| B | 056T34F15667 | 3450 RPM | 1/2 hp | 2-2.2/1.1A | Universal | 1.15 | 208-230/460V | Rolled Steel | CCW | €569.81 | |
| B | 056T34F15680 | 3450 RPM | 1 hp | 3-3/1.5A | Bolt On Base | 1, 1.15 | 208-230/460/190/380V | Rolled Steel | CW/CCW | €574.86 | |
| B | 056T34F15669 | 3450 RPM | 3/4 hp | 3-3.2/1.6A | Bolt On Base | 1, 1.15 | 230/460/190/380V | Rolled Steel | CCW/CW | €753.77 | |
| B | 056T34F15679 | 3450 RPM | 1 hp | 1.1A | Bolt On Base | 1.15 | 575V | Rolled Steel | CCW | €574.86 | |
| C | 056T34F15672 | 3450 RPM | 1 1/2 hp | 1.6A | Bolt On Base | 1.15 | 575V | Rolled Steel | CCW | €630.40 | |
| C | 056T34F15671 | 3450 RPM | 1 1/2 hp | 4/2A | Universal | 1.15 | - | Rolled Steel | CW/CCW | €944.87 | |
| B | 056T34F15665 | 3450 RPM | 1/2 hp | 1.8/0.9A | Bolt On Base | 1, 1.15 | 230/460/190/380V | Rolled Steel | CCW | €502.73 |
