EATON E49 Series Compact Metal Switches
Eaton E49 Series compact metal switches are compact electromechanical devices used in industrial applications such as packaging machines, conveyor systems and assembly lines for reliable & precise position sensing. They consist of a set of contacts that close or open depending on the position of the actuator and can be fitted into restricted spaces....Read more
Filter
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V| Style | Model | Height | Enclosure Material | Max. Amps | Min. Operating Temp. | Switch Type | Mounting Type | Actuator Type | Operating Voltage | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | E49S74 | 1 1/5" | Plastic | 1.5A At 24V DC | -22°F | - | Miniature DIN Rail | - | - | €128.90 | |
| B | E49S71 | 1 1/5" | Plastic | 1.5A At 24V DC | -22°F | - | Miniature DIN Rail | Top push | - | €109.88 | |
| C | E49S71CP7 | 1 1/5" | Plastic | 1.5A At 24V DC | -22°F | - | Miniature DIN Rail | Top push roller | - | €123.98 | |
| D | E49S74DP7 | 1 23/25" | Plastic | 1.5A At 24V DC | -22°F | - | Miniature DIN Rail | Rod lever | 400V | €108.46 | |
| E | E49S71AP7 | 1 23/25" | Plastic | 1.5A At 24V DC | -22°F | - | Miniature DIN Rail | Side Rotary | - | €126.58 | |
| F | E49S71DP7 | 1 23/25" | Plastic | 1.5A At 24V DC | -22°F | - | Miniature DIN Rail | Rod lever | 500V | €132.43 | |
| G | E49UP7 | 1.26" | Glass Reinforced Polyamide | - | -22°F | - | - | - | - | €43.89 | |
| H | E49CP7 | 1.34" | Glass Reinforced Polyamide | - | -22°F | - | - | - | - | €25.19 | |
| I | E49M11UP1Y2 | 1.58" | Die Cast Aluminum | 1.5A | 14°F | - | Standard DIN Rail | Adjustable roller lever | - | €437.22 | |
| J | E49M11BP1 | 1.58" | Die Cast Aluminum | 1.5A | 14°F | - | Standard DIN Rail | Top push | - | €269.27 | |
| K | E49M11AP1 | 1.58" | Die Cast Aluminum | 1.5A | 14°F | - | Standard DIN Rail | Roller lever | - | €244.33 | |
| L | E49M11DP1 | 1.58" | Die Cast Aluminum | 1.5A | 14°F | - | Standard DIN Rail | Rod lever | - | €257.90 | |
| M | E49M11CP1 | 1.58" | Die Cast Aluminum | 1.5A | 14°F | - | Standard DIN Rail | Top push roller | - | €232.71 | |
| N | E49M11UP1 | 1.58" | Die Cast Aluminum | 1.5A | 14°F | - | Standard DIN Rail | Adjustable roller lever | - | €257.90 | |
| O | E49M11VP1 | 1.58" | Die Cast Aluminum | 1.5A | 14°F | - | Standard DIN Rail | Wobble | - | €157.14 | |
| P | E49S71UP7 | 2.19" | Plastic | 1.5A At 24V DC | -22°F | - | Miniature DIN Rail | Adjustable side rotary lever | - | €133.75 | |
| Q | E49S74-A5 | 2.91" | Glass Reinforced Polyamide | 10A | -22°F | - | - | - | - | €107.03 | |
| R | E49S73 | 2.91" | Glass Reinforced Polyamide | 10A | -22°F | - | - | - | - | €83.49 | |
| S | E49S71-20 | 2.91" | Glass Reinforced Polyamide | 10A | -22°F | - | - | - | - | €68.08 | |
| Q | E49S71-A5 | 2.91" | Glass Reinforced Polyamide | 10A | -22°F | - | - | - | - | €96.33 | |
| Q | E49S73-A5 | 2.91" | Glass Reinforced Polyamide | 10A | -22°F | - | - | - | - | €107.03 | |
| Q | E49S71EP7-20 | 3.54" | Glass Reinforced Polyamide | 10A | -22°F | Offset roller lever | - | - | - | - | RFQ
|
| Q | E49S73EP7-A5 | 3.54" | Glass Reinforced Polyamide | 10A | -22°F | Offset roller lever | - | - | - | €125.60 | |
| R | E49S71EP7-R | 3.54" | Glass Reinforced Polyamide | 10A | -22°F | Offset roller lever | - | - | - | €135.79 | |
| Q | E49S71EP7-A5 | 3.54" | Glass Reinforced Polyamide | 10A | -22°F | Offset roller lever | - | - | - | €115.64 | |
| Q | E49S73EP7 | 3.54" | Glass Reinforced Polyamide | 10A | -22°F | Offset roller lever | - | - | - | €102.08 | |
| Q | E49S74EP7 | 3.54" | Glass Reinforced Polyamide | 10A | -22°F | Offset roller lever | - | - | - | €102.08 | |
| Q | E49S74EP7-A5 | 3.54" | Glass Reinforced Polyamide | 10A | -22°F | Offset roller lever | - | - | - | - | RFQ
|
| T | E49S71EP7 | 3.54" | Glass Reinforced Polyamide | 10A | -22°F | Offset roller lever | - | - | - | €103.26 | |
| Q | E49S73CP7 | 3.62" | Glass Reinforced Polyamide | 10A | -22°F | Top push roller | - | - | - | €97.78 | |
| R | E49S74CP7 | 3.62" | Glass Reinforced Polyamide | 10A | -22°F | Top push roller | - | - | - | €97.78 | |
| Q | E49S74CP7-A5 | 3.62" | Glass Reinforced Polyamide | 10A | -22°F | Top push roller | - | - | - | €122.75 | |
| Q | E49S73CP7-A5 | 3.62" | Glass Reinforced Polyamide | 10A | -22°F | Top push roller | - | - | - | €122.75 | |
| Q | E49S71CP7-20 | 3.62" | Glass Reinforced Polyamide | 10A | -22°F | Top push roller | - | - | - | €87.80 | |
| Q | E49S71CP7-A5 | 3.62" | Glass Reinforced Polyamide | 10A | -22°F | Top push roller | - | - | - | €110.62 | |
| Q | E49S73AP7 | 4 1/4" | Glass Reinforced Polyamide | 10A | -22°F | Side Rotary | - | - | - | €102.08 | |
| Q | E49S73AP7-A5 | 4 1/4" | Glass Reinforced Polyamide | 10A | -22°F | Side Rotary | - | - | - | €125.60 | |
| Q | E49S71AP7-A5 | 4 1/4" | Glass Reinforced Polyamide | 10A | -22°F | Side Rotary | - | - | - | - | RFQ
|
| Q | E49S71AP7-20 | 4 1/4" | Glass Reinforced Polyamide | 10A | -22°F | Side Rotary | - | - | - | - | RFQ
|
| Q | E49S74AP7-A5 | 4 1/4" | Glass Reinforced Polyamide | 10A | -22°F | Side Rotary | - | - | - | €125.60 | |
| Q | E49S74AP7 | 4 1/4" | Glass Reinforced Polyamide | 10A | -22°F | Side Rotary | - | - | - | - | RFQ
|
| R | E49M11CP2 | 4 13/25" | Die Cast Aluminum | 10A | -58°F | Top push roller | - | - | - | €208.88 | |
| Q | E49M11UP1Y1 | 5 3/25" | Die Cast Aluminum | 10A | -58°F | Adjustable Side Rotary | - | - | - | €241.96 | |
| U | E49M12UP2 | 5 3/25" | Die Cast Aluminum | 10A | -58°F | Adjustable Side Rotary | - | - | - | €264.56 | |
| D | E49S74UP7 | 5.61" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Side Rotary | - | - | - | €104.01 | |
| Q | E49S74UP7-A5 | 5.61" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Side Rotary | - | - | - | €130.58 | |
| Q | E49S73UP7-A5 | 5.61" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Side Rotary | - | - | - | €130.58 | |
| V | E49S71UP7-20 | 5.61" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Side Rotary | - | - | - | €150.16 | |
| R | E49S73UP7 | 5.61" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Side Rotary | - | - | - | €167.85 | |
| Q | E49S71UP7-A5 | 5.61" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Side Rotary | - | - | - | €121.30 | |
| Q | E49S71DP7-A5 | 6" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Rod lever | - | - | - | - | RFQ
|
| Q | E49S71DP7-20 | 6" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Rod lever | - | - | - | - | RFQ
|
| Q | E49S73DP7-A5 | 6" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Rod lever | - | - | - | €130.58 | |
| Q | E49S73DP7 | 6" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Rod lever | - | - | - | €108.46 | |
| Q | E49S74DP7-A5 | 6" | Glass Reinforced Polyamide | 10A | -22°F | Adjustable Rod lever | - | - | - | €130.58 | |
| R | E49M11XM1 | 8.02" | Die Cast Aluminum | 10A | -58°F | Wobble stick Cat whisker | - | - | - | €266.84 |
Working Mechanism
- Eaton E49 limit switch mechanism is triggered when the target object pushes or pulls the actuator, which could be an adjustable roller lever. This mechanism is composed of contacts that can either open or close depending on the actuator's position. This change in contact position can then be utilised to activate other devices, such as motor starters, relays or programmable logic controllers (PLCs).
Frequently Asked Questions
What is the maximum mechanical life of Eaton E49 Series compact metal switches?
They have a mechanical life of up to 10 million cycles.
How do I maintain Eaton E49 Series compact metal switches?
Eaton E49 Series compact metal switches have a low maintenance requirement. They can be checked for damage or wear and tear by conducting regular visual inspections to detect any signs of cracks or worn-out components. The switches can be cleaned with non-abrasive cleaners, using a soft brush or cloth to get rid of dust or debris that may impact their performance.
