EATON C Series Electronic Engine Generator Molded Case Circuit Breakers


Eaton C-Series EG-frame moulded case circuit breakers protect devices from excessive current flows and prevent electrical damage. They are ideal for use with Eaton, Allen-Bradley, Rockwell Automation Enclosed Control, Switchboard and Westinghouse.

Filter
EATON LG3500T38A
EATON LG3600T38B
EATON NG3800B20C
EATON NG3120038B20D
StyleModelHeightAmpsTerminalsFrameProd LoadLineNo. Of PolesVoltagePrice
A
LG3500T38		5 12/25"500ALine And LoadLTA602LDTA602LD3600V AC€11,207.69
A
LG3500T38B20		5 12/25"500ALine And LoadLTA602LDTA602LD3600V AC€12,314.94
A
LG3450T38B20		5 12/25"450ALine And LoadLTA450LDTA450LD3600V AC-
RFQ
A
LG3450T38		5 12/25"450ALine And LoadLTA450LDTA450LD3600V AC€11,207.69
B
LG3600T38		5 12/25"600ALine And LoadLTA603LDTA603LD3600V AC-
RFQ
B
LG3600T38B20		5 12/25"600ALine And LoadLTA603LDTA603LD3600V AC€12,314.94
C
NG3800B20		9"800ALine And LoadN--3600V AC-
RFQ
C
NG31200		9"1200ALine And LoadN--3600V AC€18,284.31
C
NG3700B20		9"700ALine And LoadN--3600V AC€12,553.89
C
NG3900		9"900ALine And LoadN--3600V AC€15,688.38
C
NG3900S02		9"900ALine And LoadN--3600V AC€17,659.18
C
NG380038B20		9"800ALine And LoadN--3600V AC-
RFQ
C
NG3800		9"800ALine And LoadN--3600V AC€11,446.67
C
NG3800W		9"800AWithout TerminalsN--3600V AC€10,713.81
C
NG3700		9"700ALine And LoadN--3600V AC€12,725.58
C
NG31000		9"1000ALine And LoadN--3600V AC€15,688.38
C
NG370038B20		9"700ALine And LoadN--3600V AC-
RFQ
C
NG370038		9"700ALine And LoadN--3600V AC-
RFQ
C
NG3700W		9"700AWithout TerminalsN--3600V AC€10,272.11
C
NG31200S02		9"1200ALine And LoadN--3600V AC€20,272.47
C
NG3700WS03Z01		9"700ALine And LoadN--3600V AC€12,509.83
C
NG380038		9"800ALine And LoadN--3600V AC-
RFQ
C
NG31000W		9"1000AWithout TerminalsN--3600V AC€14,568.39
C
NG390038B20		16 1/2"900ALine And LoadN--3600V AC-
RFQ
C
NG390038		16 1/2"900ALine And LoadN--3600V AC-
RFQ
D
NG3120038B20		16 1/2"1200ALine And LoadN--3600V AC-
RFQ
C
NG3900B20		16 1/2"900ALine And LoadN--3600V AC-
RFQ
C
NG3120038		16 1/2"1200ALine And LoadN--3600V AC-
RFQ
C
NG31000B20		16 1/2"1000ALine And LoadN--3600V AC-
RFQ
C
NG3100038		16 1/2"1000ALine And LoadN--3600V AC-
RFQ
C
NG31200B20		16 1/2"1200ALine And LoadN--3600V AC-
RFQ
C
NG3100038B20		16 1/2"1000ALine And LoadN--3600V AC-
RFQ

Features

  • They feature a thermal-magnetic trip unit, providing both long-time and instantaneous current limiting protection.
  • These double-pole breakers with a 2-wiring configuration are highly sensitive to short-circuit occurrences and trips even if the current inrush occurs on one of the wires, thus reducing the risk of damage.
  • They come with an enhanced, easy-to-use interface, allowing the user to view and make adjustments to the trip unit settings.
  • They are integrated with line and load side terminals for easy installation with panelboards and load centres.

Standards and Approvals

  • UL

Frequently Asked Questions

What is a complete breaker?

The C-Series circuit breakers are complete breaker units comprising IEC, CL and CSA-rated L-frame, a thermal-magnetic trip unit, standard terminals (line/load) and metric mounting hardware.

What is the purpose of the Digitrip RMS 310 trip?

The Digitrip RMS 310 trip units utilise Eaton's microprocessor-based intelligence to provide true RMS sensing, permitting increased accuracy and reliable system protection. This unit is front-adjustable and has an optional local display of the current and cause of the trip.

What is an engine generator moulded case circuit breaker?

These circuit breakers are specifically designed for generators as well as portable & temporary power applications where lower interrupting currents are common. The patented trip units protect generator circuits from damaging current levels in a compact footprint.
