WILKERSON SF2-04-SYV0 Pneumatic Filter Stainless Steel 1/2 Inch Npt 70 Cfm
Item: AC2HCPModel: SF2-04-SYV0Cross Ref: 2KEG9
7 In Stock
Ships within 2 days via
10.00% off
€896.00 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Compressed Air Filter |
| Air Inlet Size | 1/2" |
| Air Inlet Type | NPT |
| Air Outlet Size | 1/2" |
| Air Outlet Type | NPT |
| Body Material | Stainless Steel |
| Bowl Material | Stainless Steel |
| Bowl Size | 1.7 oz. |
| Bowl Size - Air Treatment | 1.7 oz. |
| Connection Style | Air Line |
| Depth | 2 1/2" |
| Drain Included | Yes |
| Drain Port Size | 1/8" NPT |
| Drain Type | Manual |
| Element Material | Polyethylene |
| Filter Bowl Capacity | 4 oz. |
| Filter Bowl Material | Stainless Steel |
| Filter Element Material | Polyethylene |
| Filter Media | Polyethylene |
| Filter Rating | 5 µm |
| Filter Type | Particulate |
| For Fluid Type | Water |
| For Substance Type | Particulate Contamination, Water |
| Gauge Included | No |
| Height | 5 9/16" |
| Max. Flow | 70 CFM |
| Max. Flow Rate | 70 CFM |
| Max. Incoming Pressure | 300 psi |
| Max. Operating Pressure | 300 psi |
| Max. Pressure | 300 psi |
| Max. Temp. | 180°F |
| Minimum Operating Temperature | 0°F |
| Number Of Air Inlets | 1 |
| Number Of Air Outlets | 1 |
| Overall Depth | 2 1/2" |
| Overall Height | 5 9/16" |
| Overall Width | 2 3/8" |
| Pressure Drop | 5 psid |
| Seal Material | Fluorocarbon |
| Series | SF2 Series |
| Size | Standard |
| Size - Air Treatment | Standard |
| System Location | Air Line |
| Weight | 1.9 lbs. |
| Width | 2 3/8" |
Shipping Info:
| Ship weight (kg) | 0.92 |
| Ship height (cm) | 14.13 |
| Ship length (cm) | 6.35 |
| Ship width (cm) | 6.03 |
| HS code | 8481100090 |
| Country of Origin | US |
Product Variants
| Product | Model | Air Inlet Size | Max. Flow Rate | Overall Width | Overall Height | Air Outlet Size | Size | Overall Depth | Filter Bowl Capacity | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
SF1-02-SYV0 | 1/4" | 23 CFM | 1 9/16" | 4" | 1/4" | Miniature | 1 9/16" | 1 oz. | €612.58 |
