WEG SSW070130T5SZ 10194176 Soft Starter, 130 A, 220-575V, IP00, 3 Frame
Get it by Friday, Aug 21
€2,334.51 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Starter |
| 230v Heavy Duty Hp | 30 hp, 40 hp |
| 230v Std. Duty Hp | 50 hp |
| 460v Heavy Duty Hp | 60 hp, 75 hp |
| 460v Std. Duty Hp | 100 hp |
| 575v Heavy Duty Hp | 75 hp, 100 hp |
| 575v Std. Duty Hp | 125 hp |
| Amps | 130A |
| Amps Limit | Yes |
| Amps Limitation Ramp | Programammable |
| Control Power Requirement | 110-240V AC |
| Controller Type | Basic |
| Direct On Line Start | Programmable Via Optional |
| Enclosure Rating | IP00 |
| Enclosure Type | Open, Enclosed |
| Environment | Panel Mount |
| Frame | 3 |
| Frame Size | 3 |
| Heavy Duty Amps | 94A |
| Input Voltage | 220-575V AC |
| Inside Delta (6 Leads) | No |
| Internally Bypassed | Yes |
| Ip Rating | Ip00, Ip20 |
| Modbus-rtu Rs-232 | Available With Optional |
| Modbus-rtu Rs-485 | Available With Optional |
| Modbus-rtu Usb | No |
| Mounting | Panel, Wall |
| No. Of Controlled Output Phases | 3 |
| No. Of Input Phase | 3 |
| No. Of Output Phases | 3 |
| Nominal Input Voltage | 220-240/440-480/575V AC |
| Nominal Output Voltage | 220-240/440-480/575V AC |
| Output Frequency | 50-60 Hz |
| Output Type | SCR |
| Parameterization Via Keypad | Available With Optional |
| Parameterization Via Software | Superdrive G2 |
| Parameterization Via Trimpots And Dip Switches | Yes |
| Phase | 3 |
| Power Supply | 220-575V |
| Pump Control | Programmable Via Optional |
| Sccr Rating | 65 kA |
| Series | SSW07 Series |
| Softplc Ladder Programming | No |
| Standard (3 Leads) | Yes |
| Standard Duty Amps | 130A |
| Starting Duty Cycle | AC-53b 3-30:1170 |
| Starting Regime (with Ventilation Kit) | AC-53b 3-30:330 |
| Starts Per Hour | 3 |
| Temp. | 0°C to 55°C |
| Torque Control | No |
| Trip Class | Class 5, Class 10, Class 20, Class 30 |
| Voltage Ramp | Yes |
| Voltage Ramp And Amps Limit | No |
Shipping Info:
| Ship weight (kg) | 7.09 |
| Ship height (cm) | 15.24 |
| Ship length (cm) | 15.24 |
| Ship width (cm) | 15.24 |
| Country of Origin | BR |
Product Variants
| Product | Model | Amps | Height | Frame | Amps Limitation Ramp | Starting Duty Cycle | Frame Size | 230v Std. Duty Hp | Heavy Duty Amps | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
SSW070412T5SH2Z | 412A | - | 4 | Programammable | AC-53b 3-30:330 | - | - | - | €5,682.71 | |
 |
SSW070085T5SZ | 85A | - | 2 | Programammable | AC-53b 3-30:1170 | 2 | 30 hp | 60A | - | RFQ
|
 |
SSW070061T5SZ | 61A | 8 1/5" | 2 | Programammable | AC-53b 3-30:1170 | 2 | 25 hp | 15A | €1,654.61 | |
 |
SSW070200T5SZ | 200A | - | 3 | Programammable | AC-53b 3-30:1170 | 3 | 75 hp | 125A | €3,515.29 | |
 |
SSW070024T5SZ | 24A | 6.38" | 1 | Programammable | AC-53b 3-30:330 | 1 | 7 1/2 hp | 20A | €1,813.68 | |
 |
SSW070045T5SZ | 13A | 8 1/5" | 2 | Programammable | AC-53b 3-30:1170 | 2 | 15 hp | 31A | €2,136.42 | |
 |
SSW070017T5SZ | 17A | - | 1 | Programammable | AC-53b 3-30:330 | 1 | 5 hp | 14A | €1,164.06 |
