TRITAN UCP207-22 Pillow Block Bearing Ball 1-3/8 Bore
Item: AH7KAQModel: UCP207-22Cross Ref: 36UZ14
7 In Stock
Ships within 2 days via
10.00% off
€88.17 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Pillow Block Bearing |
| Base Height | 0.708" |
| Base Width | 1.889" |
| Bearing Housing Material Type | Cast Iron |
| Bearing Insert Material | Alloy Steel |
| Bearing Insert Type | Radial Ball |
| Bearing Material Grade | Grade 52100 |
| Bolt Size | 1/2" |
| Bore Dia. | 1 3/8" |
| Bore Diameter Tolerance | -0.0008" to +0.0008" |
| Bore Type | Cylindrical |
| Center Height | 1 11/64" |
| Closure | Double Sealed |
| Closure Type | Double Sealed |
| Dynamic Load Capacity | 5778 lbs. |
| Dynamic Radial Load Capacity | 5777 lbf. |
| Expansion Type | Fixed |
| Features | Anti-Rotation Device, Dual Heavy-Duty Slinger Type Contact Seals, Grease Fitting For Adding Lubricant, One-Piece Cast Iron Housing, Solid Base, Standard Duty Unit, Eccentric Locking Collar, Triple Lip Seals Available On Request, Wide Inner Ring Bearing |
| Finish | Painted |
| Grade | Grade 52100 |
| Housing Material | Cast Iron |
| Housing Material Finish | Painted |
| Insert Finish | Chrome Plated |
| Insert Material | Steel |
| Insert Type | Ball |
| Insert Type | Radial Ball |
| Lock Type | Set Screw |
| Lubricant Material | Grease |
| Lubrication | Shell Alvania RL2 Or Nlgi #2 Equivalent |
| Lubrication Openings | Grease Fitting |
| Maximum Temperature | 250°F |
| Minimum Temperature | -40°F |
| Mount Hole Center-to-center Length | 5" |
| Mount Hole Center-to-center Width | 5" |
| Mount Type | Bolt Through |
| Mounting Bolt Size | 1/2" |
| Mounting Hole Center To Center | 127 mm |
| Mounting Surface To Shaft Center | Two Bolt Base |
| Mounting Surface To Shaft Center Height | 1 11/64" |
| Number Of Bolts | 2 |
| Number Of Mounting Holes | 2 |
| Overall Height | 3.661" |
| Overall Length | 6.574" |
| Overall Width | 1.689" |
| Resistance Properties | Corrosion Resistant, Rust Resistant, Wear Resistant |
| Seal Material | Synthetic Rubber |
| Seal Type | Contact |
| Shaft Locking Type | Set Screw |
| Static Load Capacity | 3440 lbs. |
| Static Radial Load Capacity | 3439 lbf. |
| System Of Measurement | Inch |
| Temp. Range | -40°F to +250°F |
Shipping Info:
| Ship weight (kg) | 1.64 |
| Ship height (cm) | 9.3 |
| Ship length (cm) | 16.7 |
| Ship width (cm) | 4.29 |
| Country of Origin | CN |
Product Variants
| Model | Shaft Locking Type | Bore Dia. | Overall Length | Overall Width | Mount Hole Center-to-center Length | Mounting Bolt Size | Overall Height | Center Height | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| UCP201-8 (47MM) | Set Screw | 1/2" | 5" | 1.22" | 3 47/64" | M10 | 2 11/25" | 1 11/64" | €56.09 | |
| UCP202-10 (47MM) | Set Screw | 5/8" | 5" | 1.22" | 3 47/64" | M10 | 2 11/25" | 1 11/64" | €56.09 | |
| UCP202-10S (40MM) | Set Screw | 5/8" | 4.937" | 1.078" | 3 47/64" | M10 | 2.244" | 1 11/64" | €61.69 | |
| UCP204-12 | Set Screw | 3/4" | 5" | 1.22" | 3 47/64" | M10 | 2.559" | 1 19/64" | €67.87 | |
| UCP204-20MM | Set Screw | 20 mm | 127 mm | 31 mm | 95 mm | M10 | 65 mm | - | €53.83 | |
| UCP205-14 | Set Screw | 7/8" | 5.511" | 1.342" | 4 1/8" | M10 | 2.795" | 1 27/64" | €70.70 | |
| UCP205-15 | Set Screw | 0.938" | 5.511" | 1.342" | 4 1/8" | M10 | 2.795" | 1 27/64" | €61.77 |
