SQUARE D EDB34070SA Circuit Breaker Bolt On Edb 3pole 70a
Item: AF9HMRModel: EDB34070SACross Ref: 2JWU6
7 In Stock
Ships within 2 days via
10.00% off
€2,378.69 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Bolt On Circuit Breaker |
| Ac Voltage Rating | 277/480V AC |
| Amps | 70A |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Bolt On |
| Circuit Breaker Type | Shunt Trip |
| Compatible Panelboard/load Center Series | Series NF |
| Dc Voltage | Not Rated |
| Dc Voltage Rating | Not Rated |
| Depth | 4.05" |
| For Use With | Square D NF Panelboards |
| Frame Size | 125A/EDB |
| Length | 5.66" |
| Max. Air Rating | 18kA |
| Max. Air Rating | 18 kA At 277/480V AC |
| Max. Operating Temp. | 104°F |
| Max. Wire Size | 2 AWG |
| Min. Wire Size | 12 AWG, 14 AWG |
| Number Of Poles | 3 |
| Phase | Three |
| Terminal Connection | Lug |
| Terminal Connection Type | Lug |
| Width | 3 23/25" |
Shipping Info:
| Ship weight (kg) | 1.72 |
| Ship height (cm) | 10.29 |
| Ship length (cm) | 14.38 |
| Ship width (cm) | 9.96 |
| HS code | 8536200020 |
| Country of Origin | MX |
Product Variants
| Product | Model | Number Of Poles | Amps | Voltage | Trip Unit Rating | Min. Wire Size | Max. Air Rating | Phase | Dc Voltage Rating | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
EDB14025 | 1 | 25A | - | 875A | 12 AWG, 14 AWG | 18 kA At 120/240V AC | Single | Not Rated | €279.62 | |
 |
EDB14040SA | 1 | 40A | - | 1800A | 12 AWG, 14 AWG | 18 kA At 120/240V AC | Single | Not Rated | €1,498.30 | |
 |
EDB14050 | 1 | 50A | - | 1800A | 12 AWG, 14 AWG | 18 kA At 120/240V AC | Single | Not Rated | €272.08 | |
|
EDB14070 | 1 | 70A | - | 1800A | 12 AWG, 14 AWG | 18 kA At 120/240V AC | Single | Not Rated | €550.04 | |
 |
EDB14070SA | 1 | 70A | - | - | 14 AWG | 18 kA At 277/480V AC | Single | Not Rated | €1,775.91 | |
 |
EDB24015SA | 2 | 15A | - | 875A | 12 AWG, 14 AWG | 18 kA At 277/480V AC | Single | Not Rated | €2,118.92 | |
 |
EDB24025 | 2 | 25A | - | 875A | 12 AWG, 14 AWG | 18 kA At 277/480V AC | Single | Not Rated | €919.68 |
