SQUARE D BDL26100 Molded Case Circuit Breaker, 100A, 2 Poles
Item: CE6GYTModel: BDL26100Cross Ref: 482D24
7 In Stock
Ships within 2 days via
5.00% off
€863.62 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Circuit Breaker |
| Ac Voltage Rating | 525V AC |
| Actuator Type | Toggle |
| Ambient Air Temp. For Operation | -13°F to +158°F |
| Ambient Air Temp. For Storage | -58°F to +185°F |
| Amps | 100A |
| Awg Gauge | 6 AWG to 2/0 AWG, 14 AWG to 3/0 AWG |
| Breaking Capacity | 25 kA 208Y/120V AC 50/60 Hz UL 489, 25 kA 240V AC 50/60 Hz UL 489, 18 kA 480/277V AC 50/60 Hz UL 489, 18 kA 480V AC 50/60 Hz UL 489, 14 kA 600Y/347V AC 50/60 Hz UL 489, 10 kA 250V DC UL 489 |
| Breaking Capacity Code | D |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Application | HACR Rated |
| Circuit Breaker Mounting Style | Unit Mount |
| Circuit Breaker Type | Standard |
| Color | Gray |
| Component Type | Circuit Breaker |
| Connection Pitch | 1.06" |
| Continuous Amps Rating | 80% |
| Control Type | Toggle |
| Dc Voltage Rating | Not Rated |
| Depth | 3.1" , 3.15" |
| Device Application | Distribution |
| Electrical Connection | Everlink Lug, Line, Load |
| Electrical Durability | 10000 Cycles |
| For Use With | Electrical Distribution Equipment, Industrial Control Panels |
| Frame | 125A/BD |
| Frame Type | BDL |
| Height | 5 2/5" , 5.39" |
| Ik Degree Of Protection | IK07 |
| Instantaneous Trip | Fixed |
| Ip Degree Of Protection | IP40 |
| Line Rated Amps | 100A |
| Local Signalling | Presence Of Auxiliary Contacts Flag Green |
| Max. Air Rating | 25kA at 277/408V AC |
| Max. Air Rating | 25 kA At 277/408V AC |
| Max. Operating Temp. | 158 Deg. F |
| Max. Operating Temp. | 158°F |
| Maximum Wire Size | 2 AWG, 3 AWG |
| Mechanical Durability | 20000 Cycles |
| Min. Operating Temp. | -13°F |
| Min. Wire Size | 6 AWG, 14 AWG |
| Mounting Mode | Clip On 35 mm x 15 mm Symmetrical Din Rail, By Screws Plate |
| Mounting Style | Unit |
| Network Frequency | 50/60 Hz |
| No. Of 9 Mm Pitches | 6 |
| No. Of Poles | 2 |
| Number Of Poles | 2 |
| Number Of Slots | 2 |
| Operating Altitude | 0 ft. to 6561.68 ft. Without Derating, 5000m With Derating |
| Phase | 1 |
| Pollution Degree | 3 IEC 60947-1 |
| Power Wire Stripping Length | 0.8" |
| Quality Labels | ce.png |
| Quantity Per Set | Set of 1 |
| Rated Impulse Withstand Voltage | 8 kV |
| Rated Insulation Voltage | 800V |
| Rated Operational Voltage | 525V |
| Rated Service Breaking Capacity | 25 kA @ 220-240V AC @ 50/60 Hz, 14 kA @ 500-525V AC @ 50/60 Hz, 18 kA @ 380-415V AC @ 50/60 Hz, 18 kA @ 440V AC @ 50/60 Hz |
| Returnability | Yes |
| Series | BDL Series |
| Suitability For Isolation | Yes, IEC 60947-2 |
| Terminal Connection | Everlink Lug Both Ends |
| Terminal Connection Type | Everlink Lug Both Ends |
| Tightening Torque | 44.3 lbf.in. @ 0.004 sq. in. to 0.02 sq. in. @ 14 AWG to 4 AWG, 79.7 lbf.in. @ 0.04 sq. in. to 0.1 sq. in. @ 3 AWG to 3/0 AWG |
| Trip Type | Thermal Magnetic |
| Trip Unit Technology | Thermal-Magnetic |
| Utilisation Category | Category A |
| Voltage | 600V |
| Voltage Type | AC |
| Width | 2.1" |
Shipping Info:
| Ship weight (kg) | 0.94 |
| Ship height (cm) | 13.69 |
| Ship length (cm) | 8 |
| Ship width (cm) | 5.41 |
| Country of Origin | MX |
Product Details:
- Square D BDL26100 molded case circuit breaker designed for protecting heating and refrigeration equipment from overload and short-circuit conditions
- Instantaneous & long-time trip functions for responding against severe power surges at once while avoiding tripping on mild overloads
- Features an IP40 rated front cover and capable of operating in a temperature range of -13 to 158 degree F
- Line- and load-side lug terminals for accommodating 6 - 2 AWG fine stranded & 14 - 3 AWG rigid aluminium/copper wires
- Clip-on DIN rail mounting design for reducing the installation & rearrangement downtime
- Designed in compliance with NMX J-266, NEMA AB1, UL 489 and CSA C22.2 No 5 standards
Product Variants
| Model | Number Of Poles | Amps | Phase | Circuit Breaker Type | Ac Voltage Rating | Phase Connection | Frame Size | Voltage Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| BDL36070 | 3 | 70A | 3 | Standard | 525V AC | ABC | - | AC | €1,178.35 | |
| BDL36080 | 3 | 80A | 3 | Standard | 525V AC | ABC | - | AC | €1,178.35 | |
| BDL36090 | 3 | 90A | 3 | Standard | 525V AC | ABC | - | AC | €1,178.35 | |
| BDL36100 | 3 | 100A | 3 | Standard | 525V AC | ABC | - | AC | €1,178.35 | |
| BDL36060 | 3 | 60A | 3 | Standard | 525V AC | ABC | - | AC | €976.39 | |
| BDL36050 | 3 | 50A | 3 | Standard | 525V AC | ABC | - | AC | €976.39 | |
| BDL36040 | 3 | 40A | 3 | Standard | 525V AC | ABC | - | AC | €976.39 |
