SMITH BEARING HR-2-3/4-B Cam Follower Heavy Stud Hex Socket Unsealed
Item: AA3XHDModel: HR-2-3/4-BCross Ref: 11Y041
7 In Stock
2 3/4"
Open
Ships within 2 days via
€178.70 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Cam Follower |
| Bearing Material | Alloy Steel |
| Bearing Material Grade | AISI 52100 |
| Bearing Type | Needle Roller |
| Closure | Open |
| Drive Location | Stud |
| Drive Type | Hex Socket |
| Duty Type | Heavy |
| Dynamic Load Capacity | 15280 lbs. |
| Dynamic Radial Load Capacity | 15280 lbf. |
| Face Design | Hex Socket |
| Features | Rollers And Outer Races Are Identical To The Standard Cr Series, The Hex Head Heavy Stud Series Have A Larger Diameter Stud And Are Recommended For Applications With High Running Loads And/Or Heavy Shocks Where Deflection Should Be Held To A Minimum |
| Hex Drive Size | 1/2" |
| Max. Temp. | 250°F |
| Min. Temp. | -30°F |
| No. Of Bearings | 1 |
| Overall Length | 3 25/32" |
| Roller Dia. | 2 3/4" |
| Roller Head Type | Flat |
| Roller Material | Alloy, Steel |
| Roller Material Grade | Grade 52100 |
| Roller Width | 1 1/2" |
| Rolling Element Rows | 1 |
| Standards | ABMA |
| Static Load Capacity | 33000 lbs. |
| Static Radial Load Capacity | 33000 lbf. |
| Stud Dia. | 1 1/4" |
| Stud Length | 2 1/4" |
| Stud Material | Carbon Steel |
| Stud Thread Length | 1 1/8" |
| Stud Thread Size | 1 1/4"-12 |
| Stud Type | Concentric |
| System Of Measurement | Imperial |
| Thread Length | 1 1/8" |
| Thread Size | 13 |
| Type | Heavy Stud , Hex Socket Head |
Shipping Info:
| Ship weight (kg) | 1.44 |
| Ship height (cm) | 7.11 |
| Ship length (cm) | 11.43 |
| Ship width (cm) | 7.37 |
| HS code | 8482105060 |
| Country of Origin | US |
Product Variants
| Model | Roller Material | Closure | Roller Dia. | Roller Width | Bearing Type | Bearing Material | Stud Dia. | Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| HR-1/2-B | Alloy, Steel | Open | 1/2" | 3/8" | Needle Roller | Alloy Steel | 1/4" | Hex Socket Head | €38.05 | |
| HR-5/8-B | Alloy, Steel | Open | 5/8" | 7/16" | Needle Roller | Alloy Steel | 0.312" | Hex Socket Head | €36.27 | |
| HR-3/4-B | Alloy, Steel | Open | 3/4" | 1/2" | Needle Roller | Alloy Steel | 0.437" | Hex Socket Head | €35.98 | |
| HR-7/8-B | Alloy, Steel | Open | 7/8" | 1/2" | Needle Roller | Alloy Steel | 0.437" | Hex Socket Head | €37.30 | |
| HR-1-B | Alloy, Steel | Open | 1" | 5/8" | Needle Roller | Alloy Steel | 5/8" | Hex Socket Head | €43.75 | |
| HR-1-1/8-B | Alloy, Steel | Open | 1 1/8" | 5/8" | Needle Roller | Alloy Steel | 5/8" | Hex Socket Head | €43.93 | |
| HR-1-1/4-B | Alloy, Steel | Open | 1 1/4" | 3/4" | Needle Roller | Alloy Steel | 3/4" | Hex Socket Head | €53.07 |
