SEALMASTER SF-24T 705432 Mounted Cast Iron Four Bolt Flange Ball Bearing
Get it by Friday, Feb 27
€306.43 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Ability To Relubricate | Yes |
| Bearing Insert Finish | Black Oxide |
| Bearing Insert Material | Steel |
| Bearing Insert Material Grade | 52100 |
| Bearing Insert Type | Standard Duty |
| Bearing Type | Standard Duty |
| Bolt Size | 1/2" |
| Bolt Spacing | 4" |
| Bore Dia. | 1 1/2" |
| Bore Shape | Straight |
| Cage Type | Land Riding Retainer |
| Duty Series | Standard |
| Dynamic Load Capacity | 7340 lbs. |
| End Cap | No |
| Fixed Vs. Expansion | Fixed |
| Foot Height | 14/25" |
| Grade | Grade 52100 |
| Grease Fitting Thread Size | 1/4"-28 |
| Height | 5 1/2" |
| Housing Backside Inner Diameter | 3 1/2" |
| Housing Coating | Powder Coated |
| Housing Color | Black |
| Housing Construction | One Piece |
| Housing Material | Cast Iron |
| Housing Style | Flange Block |
| Htc | 8483.20.4040 |
| Inner Race Heat Treat Method | Zone Hardened |
| Inner Ring Outside Dia. | 2.07" |
| Inner Ring Outside Diameter | 2.07" |
| Inner-race Heat-treat Method | Zone Hardened |
| Insert | AR-2-18T |
| Length | 2.13" |
| Length Through Bore | 2" |
| Locking Collar Outside Diameter | 2 3/4" |
| Locking Device | Skwezloc Concentric |
| Lubricant | Lithium Complex NLGI 2 Grease |
| Lubrication Type | Lithium Complex NLGI 2 Grease |
| Max. Operating Temperature | 220°F |
| Max. Speed | 5850 RPM |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Overall Length | 5.13" |
| Overall Width | 5.13" |
| Pilot Configuration | No Pilot |
| Product Line | Sealmaster Gold Standard |
| Radial Clearance | Standard |
| Shaft Locking Type | Concentric |
| Shaft Size | 1 1/2" |
| Size Code | 2-19 |
| Static Load Rating | 4467 lbs. |
| Width | 5 1/2" |
Shipping Info:
| Ship weight (kg) | 2.41 |
| Ship height (cm) | 13.97 |
| Ship length (cm) | 5.41 |
| Ship width (cm) | 13.97 |
| Country of Origin | MX |
