SEALMASTER MPD-24 Pillow Block Ball Bearing Unit, 2-Bolt Base, 1-1/2 Inch Bore
Get it by Friday, Aug 28
€421.96 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Base To Bore Centerline | 2 5/16" |
| Base Width | 2 5/8" |
| Bearing Type | Two Bolt Pillow Block |
| Bolt Size | 5/8" |
| Bore Dia. | 1 1/2" |
| Bore Type | Round, Straight |
| Duty Type | Medium Duty |
| Expansion Type | Non-Expansion Bearing (Fixed) |
| Family Series | Sealmaster Bearings, MPD Series |
| Housing Material | Cast Iron |
| Insert Material | 52100 Steel, Black Oxide |
| Locking Device | Double Set Screw |
| Max. Operating Temp. | 220°F |
| Max. Speed | 5300 RPM |
| Misalignment Angle | -2° to +2° |
| Misalignment Type | Static Only |
| Mounting Type | 2 Bolt Base |
| Overall Height | 4 9/16" |
| Overall Length | 8 3/4" |
| Overall Width | 2 3/8" |
| Replacement Bearing | 3-18D |
| Seal Type | Standard Felt Seal |
| Series | MPD Series |
| Shaft Dia. | 1 1/2" |
| Static Radial Load Capacity | 5139 lbf. |
| Type Of Bearing | Ball Bearing |
Shipping Info:
| Ship weight (kg) | 4.14 |
| Ship height (cm) | 11.59 |
| Ship length (cm) | 22.23 |
| Ship width (cm) | 6.03 |
Product Variants
| Product | Model | Bore Dia. | Overall Height | Bolt Size | Base Width | Overall Width | Seal Type | Dynamic Load Capacity | Base To Center Height | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MPD-35 CXU | 2 3/16" | 5.63" | 3/4" | 3.13" | 3.13" | Felt Labyrinth Seal | 11789 lbs. | 2 3/4" | €642.29 | |
 |
MPD-39 CXU | 2 7/16" | 6 1/4" | 3/4" | 3 1/4" | 3 1/2" | - | 13971 lbs. | 3" | €902.33 | |
 |
MPD-55 | 3 7/16" | 8 1/4" | 7/8" | 4.38" | - | - | 21566 lbs. | 4" | €2,364.12 | |
 |
MPD-35 | 2 3/16" | 5.63" | 3/4" | 3.13" | 3.13" | Felt Labyrinth Seal | 11789 lbs. | 2 3/4" | €642.29 | |
 |
MPD-23 | 1 7/16" | 4.19" | 1/2" | 2 1/4" | 2.31" | Felt Labyrinth Seal | 7340 lbs. | 2 1/8" | €380.62 | |
 |
MPD-32 | 2" | 5.09" | 5/8" | 2 22/25" | 2 22/25" | Felt Labyrinth Seal | 9752 lbs. | 2 1/2" | €610.30 | |
|
MPD-40 | 2 1/2" | 6 1/4" | 3/4" | 3 1/4" | 3 1/2" | - | 13971 lbs. | 3" | €1,029.47 |
