SEALMASTER DRPBA 308-2 552286 Pillow Block Bearing, 2 Bolt, 3.5 Inch Bore, 4.5 Inch Base to Center Height
Get it by Thursday, Feb 26
€6,802.94 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Pillow Block Bearing |
| Ability To Relubricate | Yes |
| Base To Center Height | 4 1/2" |
| Base Width | 4 3/8" |
| Bearing Insert Finish | Uncoated |
| Bolt Center Max | 13.266" |
| Bolt Center Min | 10 7/8" |
| Bolt Size | 7/8" |
| Bore Dia. | 3 1/2" |
| Bore Shape | Straight |
| Centerline To Front Face | 2 1/2" |
| Collar Outer Dia. | 5.547" |
| Collar Outer Diameter | 5.547" |
| Duty Series | Standard |
| Duty/series | Standard Series |
| Dynamic Radial Load Capacity | 15320 lbs. |
| End Cap | No |
| Expansion | No |
| Foot Height | 2 1/4" |
| Grade | Grade 52100 |
| Grease Fitting Thread Size | 1/8" |
| Grease Fitting Thread Type | NPT |
| Height | 9.63" |
| Housing Color | Gray |
| Housing Construction | Split Two Piece |
| Housing Material | Cast Iron |
| Housing Style | Pillow Block |
| Htc | 8483.20.8080 |
| I.d. | 3 1/2" |
| Inner Race Heat Treat Method | Case Carburized Inner Ring |
| Inner Race Length | 4.188" |
| Insert Material | Steel |
| Insert Material Grade | 52100 |
| Insert Number | RCIA-308 |
| Internal Clearance | Standard |
| Length | 16 1/2" |
| Locking Device | Single Set Screw |
| Locking Type | Collar Mount |
| Lubrication Type | Lithium, EP, NLGI |
| Max. Speed | 1500 RPM |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Overall Height | 8 1/2" |
| Overall Length | 16" |
| Overall Width | 4.19" |
| Platform | RPB Series |
| Replaceable Insert | Yes |
| Retainer Material | Steel |
| Retainer Type | Steel |
| Seal Flinger | Yes |
| Series | DRPBA Series |
| Shaft Size | 3 1/2" |
| Width | 6 3/4" |
Shipping Info:
| Ship weight (kg) | 26.78 |
| Ship height (cm) | 17.15 |
| Ship length (cm) | 41.91 |
| Ship width (cm) | 24.46 |
| Country of Origin | US |
Product Variants
| Product | Model | Housing Type | Overall Length | Overall Width | Overall Height | Bore Dia. | Shaft Size | Seal Type | Max. Speed | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
DRPBA 115-2 | Two Bolt Pillow Block | - | - | - | - | 1 15/16" | Felt | - | €881.62 | |
 |
DRPBA 115-C2 | Two Bolt Pillow Block | - | - | - | - | 1 15/16" | Contact | - | €3,776.75 | |
 |
DRPBA 200-2 | Two Bolt Pillow Block | - | - | - | - | 2" | Felt | - | €3,776.75 | |
 |
DRPBA 200-C2 | Two Bolt Pillow Block | - | - | - | - | 2" | Contact | - | €881.62 | |
|
DRPBA 203-2 | - | 11" | 3.13" | 5 5/8" | 2 3/16" | 2 3/16" | - | 2500 RPM | €2,551.72 | |
 |
DRPBA 207-C2 | Two Bolt Pillow Block | - | - | - | - | 2 7/16" | Contact | - | €5,218.49 | |
 |
DRPBA 208-2 | Pillow Block, Two Bolt | 12" | 3.31" | 6 1/8" | - | 2 1/2" | Felt | 2000 RPM | €4,919.37 |
