SCHNEIDER ELECTRIC LC1D40ABD Contactor IEC 24VDC 3P 40A
Item: AG7DUMModel: LC1D40ABDCross Ref: 5NHC4
7 In Stock
Ships within 2 days via
5.00% off
€497.17 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Contactor |
| Action Type | Non Reversing |
| Application | Motor Control, Resistive Load |
| Auxiliary Contacts Included | 1NO/1NC |
| Coil Voltage | 24V DC |
| Contactor Style | IEC |
| Contactor Type | IEC |
| Depth | 4 18/25" , 4.61" |
| Electrical Operating Durability | 1500000, 700000 |
| Embedded Surge Suppressor | Yes |
| Enclosure Nema Rating | No Enclosure |
| Enclosure Type | Open |
| Features | Built-In Bi-Directional Peak Limiting Diode Suppressor |
| Frequency | 50/60 Hz |
| Full Load Amps-inductive | 40A |
| Full Load Amps-resistive | 60A |
| Height | 2.17" , 4 4/5" |
| Hp @ 1 Ph-240v | 5 hp |
| Hp @ 1 Phase-120v | 3 hp |
| Hp @ 1 Phase-230v | 5 hp |
| Hp @ 1 Phase-240v | 5 hp |
| Hp @ 3 Ph-480v | 30 hp |
| Hp @ 3 Phase-208v | 10 hp |
| Hp @ 3 Phase-230v | 10 hp |
| Hp @ 3 Phase-240v | 10 hp |
| Hp @ 3 Phase-480v | 30 hp |
| Hp @ 3 Phase-575v | 30 hp |
| Hp @ 3 Phase-600v | 30 hp |
| Impulse Withstand Voltage | 6 kV |
| Included | Everlink Power Connections |
| Included Auxiliary Contacts | Yes |
| Included Protective Cover | Yes |
| Integrated Surge Suppression | Yes |
| Ip Rating | IP20 |
| Main Power Pole Contact Form | 3NO |
| Max. Operating Temp. | 140°F |
| Max. Voltage | 690V AC |
| Mechanical Operating Durability | 10000000 |
| Min. Operating Temp. | -40°F |
| Mounts On | Plate, Rail |
| No. Of Auxillary Contacts | 2 |
| No. Of Normally Open Main Contacts | 3 |
| No. Of Poles | 3 |
| Nominal Coil Voltage @ 60hz | 24V DC |
| Non-overlap Time | 1.5 ms |
| Overall Depth | 4.72" |
| Overall Height | 4 4/5" |
| Overall Width | 2.17" |
| Phase | 3 |
| Product Datasheet | schneider-electric-lc1d40abd.pdf |
| Resistance Properties | Fire Resistant, Insulation Resistant |
| Reversible | No |
| Reversing Capability | Non Reversing |
| Series | Tesys Deca |
| Terminal Connection Type | Screw Clamp Terminals |
| Width | 2.17" |
| Wire Termination Type | Screw Clamp |
Shipping Info:
| Ship weight (kg) | 1 |
| Ship height (cm) | 12.19 |
| Ship length (cm) | 11.99 |
| Ship width (cm) | 5.51 |
| HS code | 8536490065 |
| Country of Origin | FR |
Documentation:
Product Variants
| Product | Model | Coil Voltage | Height | Frequency | Full Load Amps-resistive | Full Load Amps-inductive | Hp @ 3 Phase-208v | Hp @ 3 Phase-600v | Hp @ 1 Phase-120v | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
LC1D80B7 | 24V AC | 5" | 50/60 Hz | 125A | 80A | 30 hp | 60 hp | 7 1/2 hp | €566.38 | |
|
LC1D80G7 | 120V AC | 5" | 50/60 Hz | 125A | 80A | 30 hp | 60 hp | 7 1/2 hp | €542.87 | |
|
LC1D80L6 | 208V AC | 5" | 60 Hz | 125A | 80A | 30 hp | 60 hp | 7 1/2 hp | €566.38 | |
|
LC1D80U7 | 240V AC | 5" | 50/60 Hz | 125A | 80A | 30 hp | 60 hp | 7 1/2 hp | €566.38 | |
 |
LC1D09B7 | 24V AC | 3.03" | 50/60 Hz | 20A | 9A | 2 hp | 7 1/2 hp | 1/3 hp | €86.02 | |
 |
LC1D09G7 | 120V AC | 3.03" | 50/60 Hz | 20A | 9A | 2 hp | 7 1/2 hp | 1/3 hp | €86.02 | |
|
LC1D09LE7 | 208V AC | 3.03" | 50/60 Hz | 20A | 9A | 2 hp | 7 1/2 hp | 1/3 hp | €102.76 |
